- Page 1 Instructions P5120 200 MHz Passive High-Voltage Probe 071-1463-00 www.tektronix.com *P071146300* 071146300 www.valuetronics.com...
- Page 2 Copyright © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Specifications and price change privileges reserved. Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077 TEKTRONIX and TEK, TEKPROBE are registered trademarks of Tektronix, Inc.
- Page 3 Tektronix, shipping charges prepaid and with a copy of Customer proof of purchase. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.
- Page 4 WARRANTY (Continued) P5120 Probe THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
-
Page 5: Table Of Contents
........P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 6 ......Figure 14: P5120 replaceable parts ..... .
-
Page 7: General Safety Summary
Do Not Operate in an Explosive Atmosphere. To avoid injury or fire hazard, do not operate this product in an explosive atmosphere. Keep Probe Surface Clean and Dry. To avoid electric shock and erroneous readings, keep probe surface clean and dry. P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 8 WARNING indicates an injury hazard not immediately accessible as you read the marking. CAUTION indicates a hazard to property including the product. Symbols on the Product. These symbols may appear on the product: P5120 High-Voltage Probe Instructions www.valuetronics.com...
- Page 9 Overvoltage Category. Overvoltage categories are defined as follows: CAT III: Distribution level mains, fixed installation CAT II: Local level mains, appliances, portable equipment CAT I: Signal level, special equipment or parts of equipment, telecommunication, electronics P5120 High-Voltage Probe Instructions www.valuetronics.com...
- Page 10 General Safety Summary P5120 High-Voltage Probe Instructions www.valuetronics.com...
-
Page 11: Contacting Tektronix
This phone number is toll free in North America. After office hours, please leave a voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix web site for a list of offices. P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 12 Contacting Tektronix P5120 High-Voltage Probe Instructions www.valuetronics.com viii...
-
Page 13: Features And Accessories
Features and Accessories The P5120 is a passive high-voltage probe designed for use with TPS2000 series instruments. The probe features a floating reference and is ideal for measuring and troubleshooting power supplies and high-voltage devices. The probe provides 20X attenuation of signals up to 1000 V and derated performance up to 200 MHz. - Page 14 Features and Accessories P5120 features and standard accessories (Cont.) Compensation Box - - The compensation box contains low- and high-frequency compensation adjustments. The high-frequency adjust- ments are accessible by removing the compensation box cover. Refer to Adjustment Procedures on page 7.
- Page 15 The hook tip will firmly hold the conductor under test. Reference Leads - - The P5120 probe comes with a long and a short, floatable reference lead. Both reference leads connect to a removable crocodile clip.
- Page 16 Reference WARNING. Do not connect the Probe-to-BNC Adapter to a floating or high-voltage source. The BNC adapter is only rated to 500 V (DC + peak AC) with the probe reference connected to earth ground. P5120 High-Voltage Probe Instructions www.valuetronics.com...
-
Page 17: Operating Basics
Maximum Nondestructive Input Voltage The P5120 probe is designed to be used in a high voltage environ- ment; however, the voltage input rating of the probe starts to decrease at about 2 to 3 MHz. Please refer to the Specifications section of these instructions for the maximum input voltage and frequency derating information. -
Page 18: Probe Loading
Refer to Figure 12 on page 21 for a graph of frequency versus input impedance. The probe has virtually no loading effect on sources with relatively low impedance and low frequency. P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 19: Adjustment Procedures
Adjustment Procedures The low-frequency (LF) compensation of the P5120 probe must be checked every time the probe is connected to a different oscilloscope input. The high-frequency (HF) compensation should be checked if the probe was repaired or fails to meet rated bandwidth specifications. -
Page 20: Hf Compensation
<1 ns 1 MHz 1 Vpp Figure 5: Signal source characteristics for HF compensation To access the HF adjustments of the probe, you must open the cover of the compensation box using the procedure that follows. P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 21 Perform the following procedure to open the compensation box. 1. Insert the flat blade of small screwdriver (A) into the location shown in Figure 6. Insert the blade until it stops against the back of the tab. P5120 High-Voltage Probe Instructions www.valuetronics.com...
-
Page 22: Figure 6: Opening The Compensation Box
After opening the compensation box, perform the following procedure to compensate the probe for high frequencies. 1. Connect a 50 Ω feedthrough termination to the positive-going FAST RISE output of the calibration generator. See Figure 7. P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 23: Figure 7: Hf Compensation Setup
6. Set the oscilloscope averaging to 4. 7. Set the oscilloscope to 5.0 ns/div Adjust the oscilloscope as necessary to view the leading edge of the waveform. 8. Locate the HF1, HF2, and HF3 adjustments. See Figure 8. P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 24: Figure 8: Hf Compensation Adjustments
See Figure 9. Because all adjustments interact, readjust HF1, HF2, and HF3 as necessary to achieve the best compromise between the fastest rise time and minimum aberrations. (50 ns) (20 ns) (10 ns) Aberrations Figure 9: HF compensation regions of fast rise signal P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 25 Adjustment Procedures 11. After compensating the HF, carefully slide the cover back until the tab latches securely into place. P5120 High-Voltage Probe Instructions www.valuetronics.com...
- Page 26 Adjustment Procedures P5120 High-Voltage Probe Instructions www.valuetronics.com...
-
Page 27: Performance Verification
Performance Verification Use the procedure in this section to verify that the P5120 probe meets the warranted bandwidth specification highlighted with boldface type in the Specifications section on page 19. The steps of this procedure must be performed in the order given using a TPS2000 series instrument and other equipment that meets the minimum requirements listed in Table 1. -
Page 28: Figure 10: Bandwidth Test Setup
6. Note that the frequency is greater than 200 MHz for the TPS2024 and 100 MHz for the TPS2012 and 2014. If not, repeat the HF compensation to achieve a faster risetime. P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 29: Maintenance
Maintenance This section contains information necessary for the maintenance and repair of the P5120 probe. NOTE. The P5120 probe has no replaceable components. Accessory parts may be ordered as indicated in the replaceable parts list. Cleaning Instructions Clean the probe using a soft cloth dampened with a mild detergent and water solution. -
Page 30: Preparation For Shipment
2. Put the probe into a plastic bag or wrap to protect it from dampness in transit. 3. Place the probe into the box and stabilize it with light packing material. 4. Seal the carton with shipping tape. P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 31: Specifications
Specifications that are not warranted are typical (Tables 3 and 4) and are provided as general information for your convenience. The specifications apply to a P5120 probe installed on a Tektronix TPS2000 series oscilloscope. The instrument must have a warm-up period of at least 20 minutes and be in an environment that does not exceed the limits described in Table 5. -
Page 32: Figure 11: Maximum Voltage Derating Curves
P5120 Voltage derating 1,000 V 600 V Category I & II 300 V Category III 100 V 10 V Frequency (Hz) b. Probe reference to earth ground Figure 11: Maximum voltage derating curves (V , DC coupled) P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 33: Figure 12: Typical Input Impedance
Probe connected to instrument and properly compensated. Checked at 1 MHz P5120 Impedance 10 MΩ 5 MΩ 1 MΩ 100 kΩ 10 kΩ 1 kΩ 100 Ω 10 Ω 1 Ω Frequency (Hz) Figure 12: Typical input impedance P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 34: Figure 13: Typical Input Phase
- - 10 - - 20 - - 30 - - 40 - - 50 - - 60 - - 70 - - 80 - - 90 - - 100 Frequency (Hz) Figure 13: Typical input phase P5120 High-Voltage Probe Instructions www.valuetronics.com... -
Page 35: Table 4: Typical Mechanical Characteristics
High: 55 °C to 71 °C (131 °F to 160 °F), 60% RH Low: 0 °C to 30 °C (32 °F to 86 °F), ≤ 90% RH Transportation Tektronix Standard 062-0937-00 Revision C Altitude Operating: 4,600 m (15,092 ft) Nonoperating:... - Page 36 Specifications P5120 High-Voltage Probe Instructions www.valuetronics.com...
-
Page 37: Replaceable Parts
Replaceable Parts Standard accessories Optional accessories Figure 14: P5120 replaceable parts P5120 High-Voltage Probe Instructions www.valuetronics.com... - Page 38 Replaceable Parts P5120 High- - Voltage Probe Instructions www.valuetronics.com...
- Page 39 Replaceable Parts P5120 High-Voltage Probe Instructions www.valuetronics.com...
- Page 40 Replaceable Parts P5120 High-Voltage Probe Instructions www.valuetronics.com...
