- Page 1 P5100A & P5150 High Voltage Probes Performance Verification and Adjustments Technical Reference *P077053002* 077-0530-02...
- Page 3 P5100A & P5150 High Voltage Probes Performance Verification and Adjustments Technical Reference Revision A www.tektronix.com 077-0530-02...
- Page 4 Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
- Page 5 Warranty Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product.
-
Page 7: Table Of Contents
P5100A Performance Verification............ - Page 8 Table of Contents P5100A & P5150 High Voltage Probes Technical Reference...
-
Page 9: General Safety Summary
Do not operate in an explosive atmosphere. Keep product surfaces clean and dry. Provide proper ventilation. Refer to the manual's installation instructions for details on installing the product so it has proper ventilation. P5100A & P5150 High Voltage Probes Technical Reference... - Page 10 DANGER indicates an injury hazard immediately accessible as you read the marking. WARNING indicates an injury hazard not immediately accessible as you read the marking. CAUTION indicates a hazard to property including the product. The following symbol(s) may appear on the product: P5100A & P5150 High Voltage Probes Technical Reference...
-
Page 11: Service Safety Summary
Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components. To avoid electric shock, do not touch exposed connections. P5100A & P5150 High Voltage Probes Technical Reference... -
Page 12: Preface
Preface Preface This manual contains procedures for checking the P5100A probe performance and for making adjustments to achieve the warranted specifications. The P5150 probe section describes adjustment procedures only. WARNING. The procedures included in this manual are for use by qualified service personnel only. -
Page 13: P5100A Performance Verification
003-1433-xx Screwdriver Flat blade Knife Razor edge Nine digit part numbers (xxx-xxxx-xx) are Tektronix part numbers Required for adjustment procedures only Test Setup 1. Turn on the oscilloscope. 2. Connect the probe to any channel (1–4) of the oscilloscope. 3. Turn on the generators and let the probe and test equipment warm up for 20 minutes. -
Page 14: System Dc Attenuation Accuracy Check
For example, if you measured 50.13 mV, then the CF = 50/50.13 = 0.997. The correction factor will be used in step 14 of this procedure to calculate the corrected amplitude, V corr P5100A & P5150 High Voltage Probes Technical Reference... - Page 15 If your probe does not meet the specification, service-level adjustments (DC gain and high-frequency compensation) may be required. (See page 5, P5100A Adjustments.) The procedures to make adjustments and to optimize the bandwidth and high frequency response must be done by a qualified service technician.
-
Page 16: Test Record
Table 2: P5100A probe test record Probe Model Number: P5100A Certificate Number: Probe Serial Number: RH %: Temperature: Technician: Date of Calibration: Probe test Minimum Incoming Outgoing Maximum System DC Attenuation 4.912 V 5.088 V Accuracy P5100A & P5150 High Voltage Probes Technical Reference... -
Page 17: P5100A Adjustments
2. Separate the covers by inserting a thin flat-blade screwdriver into the one of the slots on the side of the compensation box. The slots are hidden beneath the labels. Figure 4: Separate the covers P5100A & P5150 High Voltage Probes Technical Reference... - Page 18 The five adjustments that you will likely need to access are available through the openings in the metal shield. If you need to access the sixth adjustment (fine LF comp), you must slide the metal shield away from the connector end of the probe. Figure 6: P5100A probe adjustment locations P5100A & P5150 High Voltage Probes Technical Reference...
-
Page 19: Dc Gain And High Frequency (Hf) Compensation
To perform the high-frequency compensation adjustment you will need a signal source that has all of the following characteristics: Fast rise output with rise time ≤500 ps Output properly terminated The Picosecond Labs 2600C Pulse Generator output meets these requirements when properly terminated. P5100A & P5150 High Voltage Probes Technical Reference... - Page 20 5. Adjust the DC gain (R9) to a probe output level of 5 V, ±0.088 V, as displayed on the oscilloscope. 6. Record the output level in the outgoing column of the System DC Attenuation Accuracy check in the test record. P5100A & P5150 High Voltage Probes Technical Reference...
- Page 21 Use C2 for a coarse LF adjust and use C116 to get a consistent roll up or roll off. Finally, go back and use C2 one last time to flatten the overall response. 2. Proceed to the High Frequency (HF) Adjustment. (See page 10.) P5100A & P5150 High Voltage Probes Technical Reference...
- Page 22 2. Set the output level of the pulse generator to 5 volts (20 dB) and the pulse width to 100 ns. 3. Set the oscilloscope to: vertical to 1 V/division horizontal to 4 ns/division averaging to 64 input impedance to 1 MΩ 4. Adjust the HF response as follows: P5100A & P5150 High Voltage Probes Technical Reference...
- Page 23 Adjust R2 for the last ~5 ns. If the overshoot is too great, then adjust R2 to roll off the front corner and readjust R3 followed by R1. The procedure is done when the 3 adjustments have been optimized for the best overall response. 5. Reassemble the probe. (See page 12, Reassemble the Probe.) P5100A & P5150 High Voltage Probes Technical Reference...
-
Page 24: Reassemble The Probe
As you seat the cover onto the connector end of the probe, pull out the connector to allow the cover to clear the connector and to engage with the bottom cover. Figure 12: Install the top cover 5. Recheck that the probe functions properly. End of procedure. P5100A & P5150 High Voltage Probes Technical Reference... -
Page 25: P5150 Adjustments
Nine digit part numbers (xxx-xxxx-xx) are Tektronix part numbers P5150 probes are intended for use with oscilloscopes that have isolated (floating) inputs. The Tektronix TPS2024B and THS3024 oscilloscopes are the highest bandwidth floating-input oscilloscopes currently available. If you do not have access to one of these oscilloscopes, use the recommended ground-referenced model. - Page 26 Use C2 for a coarse LF adjust and use C116 to get a consistent roll up or roll off. Finally, go back and use C2 one last time to flatten the overall response. 2. Proceed to the High Frequency (HF) Adjustment. (See page 15, High Frequency (HF) Adjustment.) P5100A & P5150 High Voltage Probes Technical Reference...
- Page 27 P5150 Adjustments High Frequency (HF) Adjustment 1. Connect the probe and equipment as shown in the High Frequency (HF) Adjustment setup for the P5100A probe. (See Figure 9 on page 10.) 2. Set the oscilloscope horizontal to 4 ns/div. (Adjust the oscilloscope as necessary to view the leading edge of the waveform.)
