- Page 1 Installation Manual Multimedia Interface for Mercedes Benz NTG5.5 & NTG6.0 W177-Y19-HLI car-solutions.com support@car-solutions.com...
-
Page 2: Revision History
Revision History 2024.11 : remove sprinter 7inch monitor from compatibility car-solutions.com support@car-solutions.com... -
Page 3: Specification
Specification E-Class 8.4"/12.3" 2016~ Compatibility: S-Class 12.3" 2018~ Sprinter 10" 2019~ C class 7”/10" 2019~ A Class 7”/10" 2019~ Support Multi-Touch Function • Support rear PDC PIP screen mode • Not available on sprinter 7inch monitor • Interface Input / Output specification: Input: LVDS x1 A/V x2... - Page 4 Components LCD DUAL FAKRA Power Cable MAIN BOARD HLCDCA0058 HPOWER0279 QCPASS1534 AV CABLE UART CABLE MULTI CABLE HAVCAB0056 HTOUCH0031 HARETC0240 REAR CABLE BUTTON CABLE IR CABLE HARETC0002 HARETC0001 HIRCAB0002 REMOTE CTRL. REMOTE0001 car-solutions.com support@car-solutions.com...
- Page 5 Components Power/CAN Jack by Jack NTG6.0 NTG6.0 Jog/Gear CAN HPOWER0272 Power/CAN Jack by Jack NTG5.5 NTG5.5 Gear CAN NTG5.5 Jog CAN HARETC0388 HARETC0389 car-solutions.com support@car-solutions.com...
- Page 6 Components with Options HDMI 720P 2Ports SUB [Optional] HD2P-SUB HD2P-SUB Cable QCPASS1547 HARETC0365 HDMI Cable UART Cable*2 HTOUCH0031 HARETC0367 car-solutions.com support@car-solutions.com...
- Page 7 HD2P Connection HD2P-SUB Cable HDMI Cable T/S OUT T/S OUT car-solutions.com T/S OUT Pin #2 (middle) is used for touch data transmission (UART-TX) support@car-solutions.com...
-
Page 8: Cable Connection
Cable Connection PWR/CAN: Connect provided power/CAN cable AV: Connect A/V cable MULTI: Connect Multi cable T/S OUT: Connect UART 3P cable, Pin #2 (middle) used for touch data transmission [UART-TX] HD SUB: for HD2P Option Board connection LVDS-IN: LVDS Input (QROIX) T/S IN: for Capacitive touch panel connection OEM IN: Connect the OEM LCD cable coming from the OEM monitor OEM OUT: Connect one end of the supplied LCD cable and the other... -
Page 9: Dip Switch Settings
DIP Switch Settings * ON : DOWN / OFF : UP Please make sure to disconnect the power cable of the interface and reconnect the power cable again to apply the dip switch changes. FUNCTION Dip S/W SELECT OFF : LVDS MODE LVDS ON : LVDS MODE SKIP OFF : AV1 MODE... -
Page 10: Factory Settings
Factory Settings Long Press: Access to the Factory Menu OK Short Press: Selection or Mode Change Long Press: Factory Reset ▲ Short Press: Moving Upward ▼ Short Press: Moving Downward MENU Short Press: Back PIP Short Press: Split Screen (RCAM/HDMI/AV) PAS TYPE : PAS OFF IMAGE PAS SETUP... - Page 11 Factory Settings CAR MODEL : SPRINTER IMAGE PARK LVDS MODEL : QROIX-HD FUNC HD1 MODEL : NONE UTIL HD2 MODEL : NONE INFO FUNCTION CAR MODEL: Select for touch and CAN (SPRINTR / E-CLASS / V-CLASS / CLS) LVDS MODEL: Car-play, Navigation Model Setting (SE-CP HD : 960 x 540, SE-CP 800 x 480) HD1 / HD2 MODEL: See below chart Default...
- Page 12 Factory Settings RESET ALL : NO IMAGE AUDIO OUT : DEFAULT PARK AV1 IR : SE TV FUNC AV2 IR : NOT USED UTIL CAP TOUCH : SE 12.3” INFO MODE KEY : BACK UTIL FACTORY RESET: Factory mode reset (YES/NO) AUDIO OUT: Select audio channel transmitted through AUX (Default / AV1 / AV2 / HD1 / HD2) AV1/AV2 IR: Able to control UI remote by touch...
- Page 13 LCD IN/OUT connection_ NTG6.0 * NTG6.0 10inch Monitor Disconnect the OEM LVDS cable from the backside of head unit and connect it to the female connector of supplied LVDS Fakra cable Connect the male connector of supplied LVDS cable to the backside of monitor OEM LCD Cable...
- Page 14 LCD IN/OUT connection_ NTG5.5 LCD DUAL FAKRA HLCDCA0058 * NTG5.5 10inch / 12.3inch monitor 1. Disconnect the OEM LVDS cable from the backside of head unit and connect it to the female connector of supplied LVDS Fakra cable 2. Connect the male connector of supplied LVDS cable to the backside of monitor car-solutions.com support@car-solutions.com...
- Page 15 LCD IN/OUT connection_ NTG5.5 LCD DUAL FAKRA HLCDCA0058 * NTG5.5 7” / 8.4” please modify the pin location of provided LVDS cable, otherwise, screen display will be black. Swap location #1 and #2 both in male terminal and female terminal. swap swap car-solutions.com...
- Page 16 Power/CAN connection_ NTG6.0 1. Disconnect the OEM power cable from the backside of the command 2. Connect the OEM cable to the supplied female CAN connector 3. Connect the supplied male CAN connector to the backside of the monitor 4. Connect supplied CAN cable to the supplied power cable and connect it to the Interface ❸...
- Page 17 Power/CAN connection_ NTG5.5 3) Take away the black 2) Remove the black 1) Find a bunch of connector connector cover cables behind the head unit 4) Connect the OEM 5) Put the black 6) Connect the male connector to the female connector cover to the connector to the bunch connector of supplied...
- Page 18 Power/CAN connection_ NTG5.5 7) Please unplug marked original connector and connect it to the supplied Jog CAN female connector. Plug in supplied Jog CAN male connector to the marked place. Connect supplied Jog CAN cable and Gear CAN cable NTG5.5 Gear CAN NTG5.5 Jog CAN HARETC0388 HARETC0389...
- Page 19 OEM Button Use * Press high lighted OEM button for 3 seconds long to mode switch NTG5.5 NTG6.0 car-solutions.com support@car-solutions.com...
- Page 20 OEM Button Use_ NTG6.0 * Please short press 360 camera button in the external mode to switch OEM 360 camera screen. And short press again this button to switch back to previous mode. car-solutions.com support@car-solutions.com...
- Page 21 OEM Button Use_ NTG6.0 1. Switch to OEM in Rear Camera Mode : Short press below high lighted button in Ext. rear camera mode to switch OEM screen 2. DVD, DTV OSD Control : Slide arrow button right and left for DTV and DVD channel up(+) and down(-) ❷...
- Page 22 HD/AV Screen Ratio Change_ NTG6.0 Please press high lighted button for 3secs long to change screen display ratio. [HDMI / AV Mode] Full screen display mode 4:3 ratio screen display mode car-solutions.com support@car-solutions.com...
- Page 23 Rear Camera Split Screen Please press original Jog Dial Return or Navi button for 3secs long Or short press remote control PIP button to change rear camera split screen mode. Ext. Rear Camera Full Screen PDC (L) <- This OEM PDC screen is a little bigger (W205 2020) * Added on FW240206 PDC (L)
- Page 24 Rear Camera Demo_ ML 10inch car-solutions.com support@car-solutions.com...
- Page 25 Rear Camera Demo_ A Class 7inch car-solutions.com support@car-solutions.com...
- Page 26 QROIX Demo car-solutions.com support@car-solutions.com...
- Page 27 QROIX Connection by LVDS Input HDMI Cable Factory Settings -> FUNC -> LVDS MODEL : QROIX • car-solutions.com QROIX power and audio cable connect to the car. • support@car-solutions.com...
- Page 28 QDISPLAY Connection by LVDS Input HDMI Cable LVDS OUT Factory Settings -> FUNC -> LVDS MODEL : SE-CP • car-solutions.com QDISPLAY power and audio cable connect to the car. • support@car-solutions.com...
- Page 29 Control QROIX by OEM Button NTG5.5 NTG6.0 Button Operation Function Rotation Mouse Function Push Select/Confirm Touch Pad 2 Point Page Up/Down Drag Up / Down BACK Short press Back to previous page HOME Short press Back to main launcher Short press Show recent apps to make split screen car-solutions.com support@car-solutions.com...
- Page 30 Control QDISPLAY by OEM Button * These functions can be used when NAVI MODEL selected as QDISPLAY or SE-CP. Return button short press : selection Home button long press : si-ri Wheel up/down : Next/Previous track Wheel left/right : Moving left/right Wheel up long press: Home Menu Wheel down long press : Going to the bottom menu on Android Auto...
- Page 31 IF Power Cable Drawing Connect provided power wire pin#1 to car ACC. When CAN error shows on instrument, plz • pull out gear CAN wire (P1 #7 and #8) and set Dip #9 ON to use both gear and jog •...
- Page 32 NTG6.0 Gear / Jog CAN Cable Drawing car-solutions.com support@car-solutions.com...
- Page 33 NTG5.5 Gear CAN Cable Drawing car-solutions.com support@car-solutions.com...
- Page 34 NTG5.5 Jog CAN Cable Drawing car-solutions.com support@car-solutions.com...
- Page 35 AV Cable Drawing car-solutions.com support@car-solutions.com...
- Page 36 Multi Cable Drawing car-solutions.com support@car-solutions.com...
