Roger PR402DR-SET Installation Manual
Access control system
Hide thumbs
Also See for PR402DR-SET:
- Installation manual (5 pages) ,
- Installation manual (5 pages) ,
- Installation manual (2 pages)
Related Manuals for Roger PR402DR-SET
Summary of Contents for Roger PR402DR-SET
- Page 1 Roger Access Control System PR402DR-SET Installation Manual Product version: v2.1 Firmware version: - Document version: Rev. A...
- Page 2 1. P URPOSE The PR402DR-SET is designed to control single door in RACS 4 system. The door can be read-in or read-in/out type when equipped with PRT series readers (RACS CLK/DTA), Wiegand interface readers or Magstripe interface readers. The kit includes PR402DR-BRD access controller and ME- 40-24V metal box with power supply 24VDC/50W.
- Page 3 PR402DR-SET v2.1 Installation Manual.docx 2025-04-22 Fig. 2 The view of the PR402DR-SET interior with the power supply installed Note Installation may only be carried out by a qualified person holding the appropriate permits and authorizations to connect to and work on the 230 VAC mains network.
- Page 4 PR402DR-SET v2.1 Installation Manual.docx 2025-04-22 Fig. 3 Forming a loop for securing wires inside the enclosure Fig. 4 Forming cutouts for routing cables from the bottom or top panel of the enclosure 3. P RELIMINARY ONFIGURATION Preliminary configuration requires addressing of the controller on RS485 bus in range of 00-99. All controllers on this bus must have unique addresses.
-
Page 5: Memory Reset
PR402DR-SET v2.1 Installation Manual.docx 2025-04-22 4. C PR M ONFIGURATION WITH ASTER PROGRAM Configuration with PR Master enables to define the logic of controller including users and access rights. More information is given in PR Master manual. The communication with controller requires connection to computer via communication interface (e.g. - Page 6 PR402DR-SET v2.1 Installation Manual.docx 2025-04-22 8. N OTES AND ECOMMENDATIONS The following section presents various possible controller operation scenarios along with key cabling guidelines. Adhering to these recommendations will ensure correct and trouble-free system operation from the very first startup.
- Page 7 ID=0 address. If two PRT readers are connected to the controller for the purpose of read-in/out door then one of the readers must be addressed as ID=1 according to its manual. 2. Pre-programmed EM125kHz MASTER proximity card is included with PR402DR-SET. It can be used at PRT reader to open door.
-
Page 8: Ordering Information
PR402DR-SET v2.1 Installation Manual.docx 2025-04-22 NO2, COM2, NC2 Relay (REL2) 230V/5A DC/AC Table 2. PR402DR-BRD LED indicators Name Description AC supply Various signaling functions Door unlock Current arming mode LINK RS-485 data transmission indicator Table 3. Technical specification Power voltage 230VAC, 50/60Hz (-15%÷+10%) - Page 9 Weight of the equipment is specified in the document. Roger Sp. z o. o. sp. k. 82-400 Gościszewo 59 Tel.: +48 55 272 0132...
