URBAN OUTFITTERS MARINA MEDIA Assembly Instructions

Advertisement

Quick Links

MARINA MEDIA
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED: NONE
WARNINGS:
At least two people recommended for assembly
Do not throw away packing materials and carton until after assembly.
Ensure all parts are present prior to assembly.
Contact customer service immediately if parts are missing
Assemble all parts on a clean smooth surface
Do not drag the shelf while moving.
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight.
Do not place overheat or air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills with a clean white cloth, do not rub.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
A-L) Metal Front Frame
D) Second Shelf
H) Metal Ball x4
04.12.2024
A-R) Metal Back Frame
E) Third Shelf
I) Allen Key
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,Inc.
All rights reserved, including all applicable copyright, design and patent rights.
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
URBAN OUTFITTERS
B) Cross Rail x8
F) Bottom Shelf
C) Top Shelf
G) Bolt [M5x10mm] x16
Page 1 of 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the MARINA MEDIA and is the answer not in the manual?

Questions and answers

Summary of Contents for URBAN OUTFITTERS MARINA MEDIA

  • Page 1 F) Bottom Shelf G) Bolt [M5x10mm] x16 H) Metal Ball x4 I) Allen Key EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,Inc. All rights reserved, including all applicable copyright, design and patent rights. Page 1 of 3 04.12.2024...
  • Page 2 R). Align metal back frame (A-R) with cross rails (B). Insert bolts (G) and partially tighten with Allen key (I). Once all bolts are inserted and partially tightened, fully tighten the bolts. EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,Inc. All rights reserved, including all applicable copyright, design and patent rights.
  • Page 3 STEP 3 Carefully place the shelves (C)(D)(E)(F) on the partially assembled media unit, as shown, to complete assembly. EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,Inc. All rights reserved, including all applicable copyright, design and patent rights. Page 3 of 3 04.12.2024...
