Clara Bed - Twin
Assembly Instructions
NO ADDITIONAL TOOLS REQUIRED
WARNINGS:
Do not throw away packing materials and carton until after assembly.
Ensure all parts are present prior to assembly.
Contact customer service immediately if parts are missing.
Assemble all parts on a clean smooth surface.
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight.
Do not place over heat or air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills with a clean white cloth, do not rub.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED:
(A) SIDE RAIL
x2
(E) CENTER LEGS
x3
(I) ALLEN KEY
[4 MM]
x1
10.3.2024
(B) FOOTBOARD
x2
(F) SLATS
x1
(J) ALLEN KEY
[5 MM]
x1
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO,
Inc. All rights reserved, including all applicable copyright, design and patent rights.
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
URBAN OUTFITTERS
(C) CENTER SUPPORT
x1
(G) ) BOLT
[M8 X 25MM]
x8
13.5"
(D) LEGS
x4
(H) BOLT
[M6 X 16MM]
x2
Page 1 of 4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for URBAN OUTFITTERS Clara Bed - Twin
Summary of Contents for URBAN OUTFITTERS Clara Bed - Twin
- Page 1 (I) ALLEN KEY (J) ALLEN KEY [4 MM] [5 MM] EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights. 10.3.2024 Page 1 of 4 Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
- Page 2 With help, lay all the parts over onto a clean smooth surface. Screw legs (E) clockwise into the center support (C). Do not over-tighten STEP 2 Screw legs (D) clockwise into the end boards (B). EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights. 10.3.2024 Page 2 of 4 Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
- Page 3 Ensure the side rails (A) are seated on the bolts (G) then, tighten the bolts (G) with Allen key (J). EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
- Page 4 With help, lay the slats (F) on the bed frame. Ensure the slats interlock the slat blocks on either end of the center support (C) as shown. Adjust the levelers in legs (E) as necessary to complete the assembly. EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
