Numark MIXSTREAM PRO User Manual page 30

Connections
Display
Power
Dimensions
(width x depth x height)
Weight
Specifications are subject to change without notice.
Audio Outputs
Audio Inputs
Other
Full color LED-backlit display with touch interface
7" / 178 mm (diagonal)
Connection: DC, Center Positive
Voltage: 12.0 V 3.0 A
22.3" x 11.2" x 2.9"
566 x 284 x 74 mm
8.11 lbs. / 3.68 kg
2 XLR outputs (main left/right, balanced)
1 RCA output pair (main left/right,
unbalanced)
1 1/4" (6.35 mm) stereo output (headphones)
1 1/8" (3.5 mm) stereo output (headphones)
1 1/4" (6.35 mm) microphone input
2 USB port (for USB drives)
1 USB port (to computer)
1 SD card slot
1 power adapter input
30
