Summary of Contents for Xiaomi Dual-mode Wireless Mouse 2
- Page 1 Dual-mode Wireless Mouse 2 User Manual...
-
Page 2: Product Overview
Product Overview Read this manual carefully before use, and retain it for future reference. Middle Button Scroll Wheel Right Button Left Button Forward Button On/O Backward Button Switch Indicator Dongle Battery Compartment... -
Page 3: Package Contents
Package Contents Dongle Mouse (in the battery compartment) User Manual Warranty Notice Note: Illustrations of product and accessories in the user manual are for reference purposes only. Actual product and functions may vary due to product enhancements. -
Page 4: How To Use
How to Use The mouse can be connected to computer via 2.4 GHz mode or Bluetooth mode. Connecting to computer via 2.4 GHz mode 1. Open the battery compartment cover as illustrated. 2. Take out the dongle and plug it into a USB port on the computer. - Page 5 4. When there is a pop-up on your computer to notify you 3. Install the AA battery properly as illustrated, and toggle the on/o switch to the 2.4 GHz mode to turn that the mouse is ready for use, you can close the battery on the mouse.
- Page 6 Connecting to computer via Bluetooth mode 1. Open the battery compartment cover to install the AA battery into the mouse, and toggle the on/o switch to Bluetooth mode. The mouse enters the Bluetooth pairing mode, and the indicator of the mouse starts blinking quickly, indicating that the mouse is waiting for a Bluetooth connection, which will last 3 minutes.
- Page 7 2. In the Windows operating system, right-click the Bluetooth 3. When there is a pop-up on your computer to notify icon in the toolbar and click "Add a Bluetooth device" to open you that the mouse is ready for use, you can start using the "Bluetooth and other devices"...
-
Page 8: Indicator Descriptions
Indicator Descriptions Indicator Status Mouse Status Blinks white slowly Reconnecting to the device Blinks white quickly Searching and pairing the device via Bluetooth White Reconnected/paired successfully Blinks orange slowly Low battery level. Note: Replace the battery as soon as possible. -
Page 9: Battery Safety & Warnings
Battery Safety & Warnings Only use the battery approved by the manufacturer. lf you think the battery may have been swallowed or Replacing with an incorrect battery type may invalidate may stay in any part of your or someone else's body, the battery safety protection and cause a re, or even an seek medical attention immediately. - Page 10 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Xiaomi lnc. is under license. Other trademarks and trade names are those of their respective owners.
-
Page 11: Speci Cations
Speci cations Name: Xiaomi Dual-mode Wireless Mouse 2 Connectivity: 2.4 GHz wireless connection Model: XMSMSB01YM (Mouse) Connectivity: Bluetooth Low Energy connection Model: XMJSQ01 (Dongle) Rated Input: 1.5 V 50 mA Compatible with: Windows 7 or above Net Weight: Approx. 62 g (excluding the battery) Compatible with: macOS 10.13 or above... -
Page 12: Regulatory Compliance Information
Regulatory Compliance Information EU Declaration of Conformity Hereby, Beijing Yueme Technology Co., Ltd. declares that the radio equipment type XMSMSB01YM (Mouse)/XMJSQ01 (Dongle) is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.mi.com/global/- service/support/declaration.html WEEE Disposal and Recycling Information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive... - Page 13 Manufactured for: Xiaomi Communications Co., Ltd. Manufactured by: Beijing Yueme Technology Co., Ltd. (a Mi Ecosystem company) Address: Room C608, Building No. B-2, Zhongguancun Dongsheng Science and Technology Address: Park · Phase I, No. 66, Xixiaokou Road, Haidian District, Beijing, China For further information, please go to www.mi.com...
- Page 14 Importer: Beryko s.r.o. Pod Vinicemi 931/2, 301 00 Plzeň www.beryko.cz EU REP. Xiaomi Technology Netherlands B.V. Prinses Beatrixlaan 582, 2595BM, The Hague, The Netherlands contact@support.mi.com 386-00705-002...
