Fortinet FortiSwitch-AX3660S Hardware Instruction Manual

Fortinet FortiSwitch-AX3660S Hardware Instruction Manual

Hide thumbs Also See for FortiSwitch-AX3660S:

Advertisement

Quick Links

Download this manual
FortiSwitch-AX3660S
Hardware Instruction Manual
AX36S-H003X
Reading and storing this manual
・ Before you use the equipment, carefully read the manual and make sure that you understand all safety
precautions.
・ After reading the manual, keep it in a convenient place for easy reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FortiSwitch-AX3660S and is the answer not in the manual?

Questions and answers

Related Manuals for Fortinet FortiSwitch-AX3660S

Summary of Contents for Fortinet FortiSwitch-AX3660S

  • Page 1 FortiSwitch-AX3660S Hardware Instruction Manual AX36S-H003X Reading and storing this manual ・ Before you use the equipment, carefully read the manual and make sure that you understand all safety precautions. ・ After reading the manual, keep it in a convenient place for easy reference.
  • Page 2 ■ Relevant products This manual contains information on the FortiSwitch-AX3660S series. ◼ Precautions in exporting When you export this product, please follow the necessary procedures after confirming the regulations of the Foreign Exchange and Foreign Trade Control Law and the export-related laws and regulations of foreign countries such as the U.S.
  • Page 3 Preface ■ About this manual This manual describes how to handle the hardware of Fortinet's FortiSwitch-AX3660S series, a layer 3 switch that supports Gigabit Ethernet. Before you operate the equipment, carefully read the manual and make sure that you understand all instructions and cautionary notes. After reading the manual, keep it in a convenient place for easy reference.
  • Page 4 ■ Reading sequence of the FortiSwitch-AX3660S series manuals When you want to know the basic Quick Start Guide settings from unpacking the device to initial installation Hardware Instruction Manual When you want to check the hardware equipment conditions When you want to know how to...
  • Page 5 ■ Abbreviations American Wire Gauge Electronic Industries Alliance International Organization for Standardization Japanese Industrial Standards Local Area Network Light Emitting Diode Medium Dependent Interface MDI-X Medium Dependent Interface crossover Power over Ethernet Power Supply QSFP+ Quad Small Form factor Pluggable Plus QSFP28 28Gbps Quad Small Form factor Pluggable RJ-45...
  • Page 6 Safety and Regulatory Information / Informations sur la sécurité et la réglementation Regulatory Compliances / Conformités réglementaires Emissions / Émissions EN IEC 61000-3-2:2019/A1:2021 CNS15936,105 Class A AS/NZS CISPR 32:2015 Amd1:2020 VCCI-CISPR 32:2016 Class A Immunity / Immunité EN 55035:2017/A11:2020 IEC 61000-4-2/3/4/5/6/8/11 Safety / Sécurité...
  • Page 7 Warning Avertissement When selecting a fiber SFP/SFP+/QSFP+/ Lors de la sélection d'un périphérique fibre QSFP28 device, considering safety, please SFP/SFP+/QSFP+/QSFP28, compte tenu de la make sure that it can function at a sécurité, assurez-vous qu'il peut fonctionner à une temperature that is not less than the température qui n'est pas inférieure à...
  • Page 8 Les spécifications minimales pour le cordon Canada flexible cord are: flexible sont : ● For FortiSwitch-AX3660S-24T4X ● Pour FortiSwitch-AX3660S-24T4X - No. 18 AWG - not longer than 4.5 - No. 18 AWG - pas plus de 4,5 mètres, Type meters, Type SJE, SJT, or ST...
  • Page 9 The mains cord must comply with norme IEC 60227 (désignation 60227 IEC 52). IEC 60227 (designation 60227 IEC 52). Europe / The supply plug must comply with La fiche d'alimentation doit être conforme à CEE7/7 (“SCHUKO”). L'Europe CEE7/7 ("SCHUKO"). The mains cord must comply with Le cordon d'alimentation doit être conforme à...

  • Page 10: Safety Information

    Safety Information Safety precautions are indicated by the headings shown below. These headings show a combination of safety warning symbols with headings such as "Warning", "Caution", and "Notification". This is a safety alert symbol. It is used to bring attention to potential hazards that may cause personal injury.
  • Page 11 Safety Information (continued) Warning ■ If anything seems wrong, immediately turn off the power. If smoke or an unusual smell is emanating from the Switch, or if liquid is spilled into the Switch or a foreign object falls into the Switch, immediately turn off the Switch as described below. Continuing operation could result in a fire or electric shock.
  • Page 12 Safety Information (continued) Warning ■ Do not repair, modify, or disassemble the Switch. Do not repair, modify, or disassemble the Switch. Doing so could result in an electric shock, fire, or burns. The power unit in particular contains many high-voltage components, and touching them would be dangerous.
  • Page 13 Safety Information (continued) Safety Information (continued) Warning ■ Connecting and disconnecting a DC power cable must be performed by a trained technician or maintenance personnel. Connecting or disconnecting a DC power cable to or from a power facility must be performed by a trained technician or maintenance personnel.
  • Page 14 Safety Information (continued) Safety Information (continued) Warning Warning ■ Be careful of poor contact and tracking of the power plug. If the power plug is not used as follows, it may overheat due to tracking or poor contact, resulting in a fire. ●...
  • Page 15 Safety Information (continued) Warning ■ Do not use an air duster near a flame. When cleaning the optical connectors, do not use an air duster that contains flammable gas near a flame. Doing so could result in a fire. ■ Storage of packing plastic bags Keep the packaging bag for the Switch out of reach of small children.
  • Page 16 Safety Information (continued) Caution ■ Keep the Switch out of reach of children. The Switch is not suitable for use where children may be present. ■ Do not install the Switch in a dusty or humid location. Do not install the Switch in a dusty or humid location. Doing so could result in a fire or electric shock.
  • Page 17 Safety Information (continued) Caution ■ When moving the Switch, do not hold the handle on the power supply unit, fan unit. When moving the Switch, do not hold the handle or lock lever on the power supply unit or fan unit.
  • Page 18 Safety Information (continued) Caution ■ Do not touch the FN-TRAN-GC, FN-TRAN-SFP+ZR, or FN-TRAN-QSFP28 when they are in motion, or immediately after they have been powered down. The temperature during operation of FN-TRAN-GC, FN-TRAN-SFP+ZR, or FN-TRAN-QSFP28 could should be no higher than 65℃ Do not touch the Unit while it is operating or immediately after it stops.
  • Page 19 Safety Information (continued) Notification ■ Check the usage environment of the Switch. Installation conditions must be met for the usage environment of the Switch. For example, if the Switch is exposed to direct sunlight or near a heating appliance such as a stove, the internal temperature will rise and may cause the Switch to malfunction.
  • Page 20 Safety Information (continued) Notification ■ After removing a power supply unit, attach a blank panel. Attach a blank panel to a slot in which a power supply unit is not installed. If you use the Switch without attaching the blank panel, airflow inside the Switch cannot be maintained. If airflow is not maintained, the temperature inside the Switch rises, resulting in a failure.
  • Page 21 Safety Information (continued) Safety Information (continued) Safety Information (continued) Notification ■ Protect the Switch when using a fuming liquid. Before using a fuming liquid such as a pesticide, completely wrap the Switch with a plastic sheet or similar protection. If the fuming liquid enters the Switch, this may cause a Switch failure.

  • Page 22: Table Of Contents

    Table of Contents Preface Safety and Regulatory Information Safety-1 Safety Information Safety-5 Overview of the Switch Switch main body 1.1.1 FortiSwitch-AX3660S-24T4X 1.1.2 FortiSwitch-AX3660S-24T4XW 1.1.3 FortiSwitch-AX3660S-48T4XW 1.1.4 FortiSwitch-AX3660S-24S8XW 1.1.5 FortiSwitch-AX3660S-48XT4QW 1.1.6 FortiSwitch-AX3660S-48X4QW 1.1.7 Accessories Power supply unit (PS) 1.2.1 FS-AXF2430-PSA06 / FS-AXF2430-PSA06R 1.2.2...
  • Page 23 Cooling conditions 2.8.1 Airflow 2.8.2 Cooling conditions 2.8.3 Cooling conditions for rack mounting Device noise Preparation of Interface Cables and Terminal Interface cable list Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T 3.2.2 Ethernet 100BASE-TX/1000BASE-T/10GBASE-T 3.2.3 Ethernet 1000BASE-X 3.2.4 Ethernet 10GBASE-R 3.2.5 Ethernet 40GBASE-R 3.2.6 Ethernet 100GBASE-R...
  • Page 24 Turning the power on and off 4.10 Subsequent operations Adding and Replacing a Power Supply Unit Necessary tools Read the following before you begin Adding and replacing a power supply unit Replacing a Fan Unit Appendix Appendix A Cleaning the optical connector Appendix B Physical specifications for the network Interface...

  • Page 25: Overview Of The Switch

    Overview of the Switch This chapter describes an overview of each device that comprises the Switch. 1.1 Switch main body 1.2 Power supply unit (PS) 1.3 Fan Unit (FAN) 1.4 Transceiver 1.5 Direct attach cable...

  • Page 26: Switch Main Body

    Switch main body The FortiSwitch-AX3660S Series offers three levels of gigabit switches optimal for a wide variety of scenarios. These include network switches for large-scale facilities—developed to achieve guaranteed networks—which bring the reliability and performance of basic router switches to a compact format;...

  • Page 27: Fortiswitch-Ax3660S-24T4X

    1.1.1 FortiSwitch-AX3660S-24T4X FortiSwitch-AX3660S-24T4X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 24 ports • SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots • QSFP+ slots (stackable only): 2 slots • Console port (RJ-45): 1 port • Management port (10BASE-T/100BASE-TX): 1 port •...

  • Page 28: Front Panel

    Unit will no malfunction and continue to cool the switch. However, if one of the fans does break, replace the switch promptly. (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-24T4X supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-3...
  • Page 29 Table 1-2 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 30 Name Type Status Description brightness (12) QSFP+ LED: Indicates the operating Green Regular A link has been established. Green/ status of QSFP+ slots orange/ (stacked only). Blinking Regular A link is established, and frames green are being sent or received. Orange Regular Line failure detection.

  • Page 31: Fortiswitch-Ax3660S-24T4Xw

    1.1.2 FortiSwitch-AX3660S-24T4XW FortiSwitch-AX3660S-24T4XW has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 24 ports • SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots • QSFP+ slots (stackable only): 2 slots • Console port (RJ-45): 1 port • Management port (10BASE-T/100BASE-TX): 1 port •...
  • Page 32 (2) Fan unit (FAN) slot (3) Power supply unit slot 2 (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-24T4XW supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-6...
  • Page 33 Table 1-3 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 34 Name Type Status Description brightness (12) QSFP+ LED: Indicates the operating Green Regular A link has been established. Green/ status of QSFP+ slots orange/ (stacked only). Blinking Regular A link is established, and frames green are being sent or received. Orange Regular Line failure detection.

  • Page 35: Fortiswitch-Ax3660S-48T4Xw

    1.1.3 FortiSwitch-AX3660S-48T4XW FortiSwitch-AX3660S-48T4XW has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 48 ports • SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots • QSFP+ slots (stackable only): 2 slots • Console port (RJ-45): 1 port • Management port (10BASE-T/100BASE-TX): 1 port •...
  • Page 36 (2) Fan unit (FAN) slot (3) Power supply unit slot 2 (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-48T4XW supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-9...
  • Page 37 Table 1-4 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 38 Name Type Status Description brightness (12) QSFP+ LED: Indicates the operating Green Regular A link has been established. Green/ status of QSFP+ slots orange/ (stacked only). Blinking Regular A link is established, and frames green are being sent or received. Orange Regular Line failure detection.

  • Page 39: Fortiswitch-Ax3660S-24S8Xw

    1.1.4 FortiSwitch-AX3660S-24S8XW FortiSwitch-AX3660S-24S8XW has the following hardware specifications. • SFP slot (1000BASE-X): 24 slots • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 12 ports • SFP+ slot (10GBASE-R or 1000BASE-X): 8 slots • QSFP+ slots (stackable only): 2 slots • Console port (RJ-45): 1 port •...
  • Page 40 (2) Fan unit (FAN) slot (3) Power supply unit slot 2 (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-24S8XW supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-12...
  • Page 41 Table 1-5 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 42 Name Type Status Description brightness (12) QSFP+ LED: Indicates the operating Green Regular A link has been established. Green/ status of QSFP+ slots orange/ (stacked only). Blinking Regular A link is established, and frames green are being sent or received. Orange Regular Line failure detection.

  • Page 43: Fortiswitch-Ax3660S-48Xt4Qw

    1.1.5 FortiSwitch-AX3660S-48XT4QW FortiSwitch-AX3660S-48XT4QW has the following hardware specifications. • Ethernet 100BASE-TX/1000BASE-T/10GBASE-T port: 44 ports • SFP+ slot: 4 slots • QSFP28 slots: 4 slots • Console port (RJ-45): 1 port • Management port (10BASE-T/100BASE-TX): 1 port • Memory card slot: 1 slot •...
  • Page 44 (2) Fan unit (FAN) slot (3) Power supply unit slot 2 (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-48XT4QW supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-15...
  • Page 45 Table 1-6 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 46 Name Type Status Description brightness (12) QSFP28 LED: Indicates the operating Green Regular A link has been established. Green/ status of QSFP28 slots orange/ (stacked only). Blinking Regular A link is established, and frames green are being sent or received. Orange Regular Line failure detection.

  • Page 47: Fortiswitch-Ax3660S-48X4Qw

    1.1.6 FortiSwitch-AX3660S-48X4QW FortiSwitch-AX3660S-48X4QW has the following hardware specifications. • SFP+ slot: 48 slots • QSFP28 slots: 4 slots • Console port (RJ-45): 1 port • Management port (10BASE-T/100BASE-TX): 1 port • Memory card slot: 1 slot • Power supply unit slot: 2 slots •...
  • Page 48 (2) Fan unit (FAN) slot (3) Power supply unit slot 2 (2) Front panel The layout of the front panel is shown below. The FortiSwitch-AX3660S-48X4QW supports LED brightness control function (power saving reduced brightness mode, lights off mode). Figure 1-18...
  • Page 49 Table 1-7 LED indications, switche, and connectors Name Type Status Description brightness LED: Indicates the power supply Green Regular Power is on. － Green status. Power is off or the power supply failed. LED: Indicates the status of the Green Regular Available for operation Green/...
  • Page 50 Name Type Status Description brightness (12) ・Stacking activated: LED: Indicates stackable switch Green Regular Green status or Sync-E status. Operates as master switch. ・Stacking not activated: Sync-E activated and synched with external clock. － ・Stacking activated: Switch is on initial status or operating as backup switch.

  • Page 51: Accessories

    1.1.7 Accessories The following items are included as accessories with the Switch when shipped from the factory. Table 1-8 Switch accessories Model Non-detac Replacea Item name Quantity Remarks hed power ble power supply supply models models ○ ○ Before using the "device" The series name is written in place of "device".

  • Page 52: Rack Mounting Brackets

    (4) Rack mounting brackets The brackets are used when mounting the Switch in a 19-inch cabinet rack. Figure 1-19 Rack mounting brackets (1) Rack mounting bracket (L) (2) Rack mounting bracket (R) (5) Screws The screws are used to attach the rack mounting brackets to the Switch. Figure 1-20 Screws (6) Rubber feet...

  • Page 53: Cable Clamp

    (7) Cable Clamp Used to prevent the AC power cables from coming out during use of AC power unit. Figure 1-22 Cable Clamp (8) Dummy memory card When you are not using the memory cards, place a dummy card in the Unit’s memory card slot in place of the memory card.

  • Page 54: Blank Panel

    (10) Blank panel Where only one power supply unit is used in a replaceable power supply unit models, the blank panel is used instead of a power supply unit. Figure 1-25 Blank panel The blank panel is installed in the Switch when shipped. Non-detached power NOTE supply model are not fitted with blank panels.

  • Page 55: Power Supply Unit (Ps)

    Note the following regarding compatibility between the Switch and the power supply unit. Table 1-9 Compatibility of the Switch and power supply unit Compatibility of power supply unit Model name AC power supply DC power supply FortiSwitch-AX3660S-24T4XW FortiSwitch-AX3660S-48T4XW FS-AXF2430-PSA06 *1, FortiSwitch-AX3660S-24S8XW FS-AXF2430-PSD06 *1 FS-AXF2430-PSA06R FortiSwitch-AX3660S-48XT4QW...

  • Page 56: Fs-Axf2430-Psa06 / Fs-Axf2430-Psa06R

    1.2.1 FS-AXF2430-PSA06 / FS-AXF2430-PSA06R FS-AXF2430-PSA06 and FS-AXF2430-PSA06R are AC power supply unit used in power source-replaceable models, and supports 100 to 240 V AC power supplies. The FS-AXF2430-PSA06 feature front intake and back vent airflow, while the FS-AXF2430-PSA06R accommodates back intake and front vent airflow. Figure 1-26 External view (1) LED...

  • Page 57: Fs-Axf2430-Psd06

    1.2.2 FS-AXF2430-PSD06 FS-AXF2430-PSD06 is DC power supply unit used in power source-replaceable models, and supports -48 to -60 V DC power supplies. The FS-AXF2430-PSD06 accommodates front intake and back vent airflow. Figure 1-27 External view (1) LED (2) DC power connector (3) Handle color: FS-AXF2430-PSD06=red (4) Lever (5) Ground terminal...

  • Page 58: Power Supply Unit Accessories

    1.2.3 Power supply unit accessories The following items are included as accessories with the power supply unit when shipped from the factory. Table 1-12 Power supply unit accessories Item name Quantity Remarks Packing list Safety Guide AC power cable Comes with FS-AXF2430-PSA06 and FS-AXF2430-PSA06R Grounding cable Comes with FS-AXF2430-PSD06...

  • Page 59: Grounding Cable

    (4) Grounding cable Grounding cable. It is used for FS-AXF2430-PSD06. This grounding cable is included with the FS-AXF2430-PSD06. Figure 1-29 Grounding cable No power cable is included with the FS-AXF2430-PSD06. When using Warning FS-AXF2430-PSD06, use the power cable with specifications defined by ours. Using another cable could result in a fire or electric shock.
  • Page 60 (6) DC power connector extraction tool This is a DC power connector extraction tool, used to remove the DC power connector from the FS-AXF2430-PSD06 power connector. Figure 1-31 DC power connector extraction tool (7) How to use the DC power connector extraction tool Note the following precautions in handling the DC power connector extraction tool.

  • Page 61: Fan Unit (Fan)

    Note the following regarding compatibility between the Switch and the fan unit. Table 1-13 Compatibility of the Switch and fan unit Compatibility of fan unit Model name AC power supply DC power supply FortiSwitch-AX3660S-24T4XW FortiSwitch-AX3660S-48T4XW FS-AXF2430-FAN04, FortiSwitch-AX3660S-24S8XW FS-AXF2430-FAN04 FS-AXF2430-FAN04R FortiSwitch-AX3660S-48X4QW FortiSwitch-AX3660S-48XT4QW Ensure that the power source system and fan unit air flows are the same.

  • Page 62: Fs-Axf2430-Fan04 / Fs-Axf2430-Fan04R

    1.3.1 FS-AXF2430-FAN04 / FS-AXF2430-FAN04R FS-AXF2430-FAN04 and FS-AXF2430-FAN04R are fan unit used in power source-replaceable models. The FS-AXF2430-FAN04 feature front intake and back vent airflow, while the FS-AXF2430-FAN04R accommodates back intake and front vent airflow. The fan unit are used with the fan unit slots on the Switch regardless of the number of power supply unit.

  • Page 63: Fan Unit Accessories

    1.3.2 Fan unit accessories The following items are included as accessories with the fan unit when shipped from the factory. Table 1-15 Fan unit accessories Item name Quantity Remarks Packing list Safety Guide (1) Packing list Items that are included with the power supply unit when shipped from the factory are listed. (2) Safety Guide This guide provides important information for ensuring safe use of the Switch.

  • Page 64: Transceiver

    Transceiver For transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual" or "FortiSwitch AX3660S Series Datasheet".

  • Page 65: Direct Attach Cable

    Direct attach cable The direct attach cable is an interface cable with transceiver-shaped ends. For direct attach cable supported by the Switch, see "FortiSwitch AX3660S Series Datasheet". Do not attach any labels to connectors. Attaching a label to a location that interferes with heat dissipation or the Notification cable latch mechanism could cause a malfunction of the direct attach cable or cause damage to the Switch.

  • Page 66: Preparation For Installation

    Preparation for Installation This chapter describes the environmental conditions and preparation required to install the Switch. Before you begin preparation for Switch installation, carefully read this chapter and make sure that you understand all instructions and cautionary notes. 2.1 Installation conditions 2.2 Power facility 2.3 Consideration for electrical noise 2.4 Leakage current...

  • Page 67: Installation Conditions

    Installation conditions for the Switch are as follows. An installation environment must satisfy these conditions. Table 2-1 General installation conditions for the Switch (1/4) Model name Item FortiSwitch-AX3660S-24T4X Dimensions (W x D x H) 445 x 380 x 43 mm Weight 6.0 kg or less 100 - 240 V ～...
  • Page 68 Table 2-2 General installation conditions for the Switch (2/4) Model name FortiSwitch-AX3660S-24T4XW FortiSwitch-AX3660S-48T4XW Item FS-AXF2430-PSA06/ FS-AXF2430-PSD06 FS-AXF2430-PSA06/ FS-AXF2430-PSD06 FS-AXF2430-PSA06R Installed FS-AXF2430-PSA06R Installed Installed Installed Dimensions (W x D x H) 445 x 450 x 43 mm 445 x 450 x 43 mm Weight 10.0 kg or less...
  • Page 69 Table 2-3 General installation conditions for the Switch (3/4) Model name FortiSwitch-AX3660S-24S8XW FortiSwitch-AX3660S-48X4QW Item FS-AXF2430-PSA06/ FS-AXF2430-PSD06 FS-AXF2430-PSA06/ FS-AXF2430-PSD06 FS-AXF2430-PSA06R Installed FS-AXF2430-PSA06R Installed Installed Installed Dimensions (W x D x H) 445 x 450 x 43 mm 445 x 480 x 43 mm Weight 10.0 kg or less...
  • Page 70 Table 2-4 General installation conditions for the Switch (4/4) Model name FortiSwitch-AX3660S-48XT4QW Item FS-AXF2430-PSA06/ FS-AXF2430-PSD06 FS-AXF2430-PSA06R Installed Installed Dimensions (W x D x H) 445 x 480 x 43 mm Weight 11.0 kg or less ⎓ 100 - 240 V ～...

  • Page 71: Power Facility

    Power facility 2.2.1 AC power facility (1) Outlet Use the OUTLET one that meets the specifications of your country. Installation and removal of the unit must be carried out by qualified personnel Warning only. Always use a grounded power outlet. Using the Switch without grounding could Warning result in an electric shock as well as failures due to electrical noise.
  • Page 72 Table 2-5 Inrush current Model Current Current Time (peak value) (peak value) for 100V AC for 200V AC FortiSwitch-AX3660S-24T4X 50 A 50 A No more than 10 ms FortiSwitch-AX3660S-24T4XW 25 A 25 A FortiSwitch-AX3660S-48T4XW FortiSwitch-AX3660S-24S8XW FortiSwitch-AX3660S-48XT4QW FortiSwitch-AX3660S-48X4QW Turning on the Switch causes inrush current.

  • Page 73: Dc Power Facility

    2.2.2 DC power facility When using DC power, use an electric shock risk-free power facility for which the Warning primary side and the secondary side are insulated. Using a power facility that is not insulated could result in an electric shock. (1) DC power cable No power cable is included with the Switch.
  • Page 74 Figure 2-1 Grounding cable specifications (power facility side) (1) Grounding (green/yellow) Table 2-7 Grounding cable specifications Model Cable specifications Number of AWG No cores FS-AXF2430-PSD06 Be sure to connect the grounding cable for grounding. Using the Switch without Warning grounding could result in an electric shock as well as failures due to electrical noise.
  • Page 75 When using a UPS or CVCF, please take the above into consideration. Table 2-8 Inrush current Model Current (peak Time value) FortiSwitch-AX3660S-24T4XW 40 A No more than 10 ms FortiSwitch-AX3660S-48T4XW FortiSwitch-AX3660S-24S8XW FortiSwitch-AX3660S-48XT4QW FortiSwitch-AX3660S-48X4QW Turning on the Switch causes inrush current.

  • Page 76: Consideration For Electrical Noise

    Consideration for electrical noise Electrical noise generated by other equipment may cause a Switch failure. Please develop the power facility plan to observe the following points. ⚫ Do not connect a device (such as an air conditioner) whose power is repeatedly turned on and off by a relay, micro-switch, etc., to the branch circuit of the power supply used for the Switch.

  • Page 77: Leakage Current

    Leakage current The Switch is equipped with a noise filter to prevent failure caused by electrical noise. As a result, leakage current flows through the safety ground wire (class D grounding). A maximum leakage current of 1 mA flows per device, so if you are required to install an earth leakage breaker under the Fire Services Act and other laws, take this into consideration.

  • Page 78: Environmental Requirements

    Environmental requirements (1) Dust The Switch uses cooling fans, so do not install it in a humid or dusty place. The dust conditions for the Switch are as follows. ➢ Suspended particulate concentration: 0.15 mg/m or less (JIS Z 8813, General Requirements for Measuring Methods for Suspended Particulate Matter Concentration in Air) Do not install the Switch in a location near a printer or in a location with a lot of...
  • Page 79 In particular, optical fiber cables should be protected by metal covers, etc., with a bending radius of at least 100 mm in the major axis direction and at least 50 mm in the minor axis direction. In addition, the optical fiber cable that accommodates the required number of optical fiber cores must have a structure that can protect the cable itself from mechanical stress such as repeated bending, tensile tension, compression, and ironing during installation, and stress from the installation environment.

  • Page 80: Installation Location

    Installation location Use the Switch indoors. Also, make sure that all interface cables to be connected Warning to the Switch are indoor-wired. If connecting a cable that is laid outdoors, ensure that lightning protection measures have been taken before connection. The Switch can be used installed on a table or mounted in a 19-inch cabinet rack.
  • Page 81 (2) 19-inch cabinet rack When mounting the Switch in a rack, use a rack that satisfies the conditions in the table below. Table 2-10 Rack conditions Item Conditions Rack standard EIA standard compliant 19-inch cabinet rack For ventilation, the cabinet rack should secure a space of at least 50 Space for ventilation mm between rack structures such as rack posts, side plates, and the ventilation slots of the Switch.

  • Page 82: Maintenance Area

    Maintenance area Secure the following space as the maintenance area for the Switch. (1) Maintenance area for installation on a table Figure 2-2 Maintenance area for installation on a table Switch Front (Unit: mm) (2) Maintenance area for rack mounting Figure 2-3 Maintenance area for rack mounting 1000...

  • Page 83: Cooling Conditions

    Figure 2-4 Airflow of FortiSwitch-AX3660S-24T4X, FortiSwitch-AX3660S-24T4XW, FortiSwitch-AX3660S-48T4XW, and FortiSwitch-AX3660S-24S8XW (front intake / back exhaust) Exhaust Intake (2) FortiSwitch-AX3660S-24T4XW, FortiSwitch-AX3660S-48T4XW, and FortiSwitch-AX3660S-24S8XW (back intake / front exhaust) Figure 2-5 Airflow of FortiSwitch-AX3660S-24T4XW, FortiSwitch-AX3660S-48T4XW, and FortiSwitch-AX3660S-24S8XW (back intake / front exhaust) Intake Exhaust...
  • Page 84 (3) FortiSwitch-AX3660S-48XT4QW, and FortiSwitch-AX3660S-48X4QW (front intake / back exhaust) Figure 2-6 Airflow of FortiSwitch-AX3660S-48XT4QW, and FortiSwitch-AX3660S-48X4QW (front intake / back exhaust) Exhaust Intake Intake Intake (4) FortiSwitch-AX3660S-48XT4QW, and FortiSwitch-AX3660S-48X4QW (back intake / front exhaust) Figure 2-7 Airflow of FortiSwitch-AX3660S-48XT4QW, and FortiSwitch-AX3660S-48X4QW...

  • Page 85: Cooling Conditions

    2.8.2 Cooling conditions Secure a space of at least 50 mm from each side of the Switch to ensure air flow. Do not obstruct the ventilation slots of the Switch. Doing so causes heat to Caution accumulate inside the Switch, and could result in a fire. Maintain a space of at least 50 mm around the ventilation slots.

  • Page 86: Device Noise

    Device noise The Switch has built-in cooling fan units, which generate noise. Before installing the Switch, consider such noise to plan your layout. For device noise, see "2.1 Installation ". conditions The following are some examples of a layout that reflects considerations specific to noise.

  • Page 87: Preparation Of Interface Cables And Terminal

    Preparation of Interface Cables and Terminal This chapter describes interface cables and terminal to be used with the Switch. 3.1 Interface cable list 3.2 Network interface specifications 3.3 Terminals and connection cables...

  • Page 88: Interface Cable List

    Interface cable list Interface cable connections with the Switch are listed below. The following cables must be prepared by the customer. For interface cables to be used for the transceiver, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". Table 3-1 Interface cables Port Transceiver Interface...

  • Page 89: Network Interface Specifications

    Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (1) Mode setting for ports For Ethernet 10BASE-T/100BASE-TX/1000BASE-T ports, the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 100BASE-TX full duplex (fixed) ➢...

  • Page 90: Ethernet 100Base-Tx/1000Base-T/10Gbase-T

    Table 3-3 10BASE-T/100BASE-TX/1000BASE-T pin configuration RJ-45 Physical specifications Pin No. 10BASE-T 1000BASE-T 100BASE-TX Receive (+) Send/Receive A (+) Receive (–) Send/Receive A (–) Send (+) Send/Receive B (+) Not used Send/Receive C (+) Not used Send/Receive C (–) Send (–) Send/Receive B (–) Not used Send/Receive D (+)

  • Page 91: Physical Specifications

    (4) PoE power supply method PoE is not supported with the Switch. (5) Physical specifications Table 3-4 100BASE-TX/1000BASE-T/10GBASE-T physical specifications Physical specifications Item 100BASE-TX 1000BASE-T 10GBASE-T Category 5 and Enhanced Enhanced category 6A and higher category 6 and higher UTP cable category 5 and higher higher...

  • Page 92: Ethernet 1000Base-X

    3.2.3 Ethernet 1000BASE-X (1) Mode setting for ports For Ethernet 1000BASE-X ports, the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 1000BASE-X full duplex (fixed) NOTE Half-duplex communication is not supported.

  • Page 93: Ethernet 40Gbase-R

    3.2.5 Ethernet 40GBASE-R (1) Mode setting for ports The mode setting of Ethernet 40GBASE-R is available only in the full-duplex (fixed) setting. NOTE Auto-negotiation and half-duplex communication are not supported. (2) Flow control function This function is valid during full-duplex communication. (3) Physical specifications For the optical fiber cable used for each transceiver, see "FortiSwitch-AX Transceiver Hardware Instruction Manual".

  • Page 94: Stack Port

    Stack port (1) Supported ports The following ports can be used as stack ports. ・ FortiSwitch-AX3660S-24T4X QSFP+ slots (stacking only) (Ports 29, 30) ・ FortiSwitch-AX3660S-24T4XW QSFP+ slots (stacking only) (Ports 29, 30) ・ FortiSwitch-AX3660S-48T4XW QSFP+ slots (stacking only) (Ports 53, 54) ・...

  • Page 95: Terminals And Connection Cables

    Terminals and connection cables 3.3.1 When connecting an operation terminal to the Console port (1) Operation terminals When connecting an operation terminal to the Console port of the Switch, prepare a personal computer or workstation that supports the following functions. Table 3-7 Operation terminal Item...

  • Page 96: When Connecting An Operation Terminal To The Management Port

    3.3.2 When connecting an operation terminal to the MANAGEMENT port (1) Operation terminals When connecting an operation terminal to the MANAGEMENT port of the Switch, prepare a personal computer or workstation that supports the following functions. Table 3-8 Operation terminal Item Specifications Communication port...

  • Page 97: Installation Of The Switch

    Installation of the Switch This chapter describes how to install the Switch. 4.1 Necessary tools and equipment 4.2 Read the following before you begin 4.3 Installing the Switch 4.4 Connecting and disconnecting the power cable 4.5 Inserting and removing the memory card 4.6 Connecting and disconnecting the transceiver 4.7 Connecting an operation terminal 4.8 Connecting an interface cable...

  • Page 98: Necessary Tools And Equipment

    Necessary tools and equipment The following tools and equipment are required to install the Switch. #2 Phillips screwdriver: Used to attach rack mounting brackets to the Switch and to attach or remove the Switch to or from a rack using M5 screws. 1/4 inch socket driver: Necessary for attaching the FS-AXF2430-PSD06 grounding cable.

  • Page 99: Read The Following Before You Begin

    Read the following before you begin Keep the Switch out of reach of children. The Switch is not suitable for use Caution where children may be present. Place the Switch horizontally when installing it on a table. The Switch may fall Caution over if placed vertically or leaned against a wall, resulting in injury or failure.

  • Page 100: Installing The Switch

    Installing the Switch This section describes how to install the Switch on a table and in a rack. Please follow the steps below. When moving the Switch, do not hold the handle on the rear of the Switch. The handle may come off, resulting in the device falling and possibly causing injury. Caution Also, the power supply module may become deformed, resulting in a fire or electric shock.

  • Page 101: Mounting The Switch In A Rack

    Make sure that there is no dirt on the positions where rubber feet are attached. If NOTE it is dirty, wipe it off with a dry cloth before attaching the rubber feet. [Step 3] Turn over the Switch to its original orientation and place it on a table. 4.3.2 Mounting the Switch in a rack The Switch can be mounted in a 19-inch cabinet rack conforming to EIA standard.
  • Page 102 When mounting the Switch in a rack, if it is not possible to secure a space (for NOTE pulling out cables) in front of the Switch, attach the rack mounting brackets to protrude 50 mm from the front side. [Step 2] Mount the Switch in a rack.

  • Page 103: Connecting And Disconnecting The Power Cable

    Connecting and disconnecting the power cable This section describes steps for connecting/disconnecting the power cable to/from the Switch. Follow the steps below to connect/disconnect the power cable. 4.4.1 Connecting and disconnecting the AC power cable Use the supplied or one that meets the specifications of your country power cable.
  • Page 104 [Step 2] Connect the supplied power cable to the AC connector on the rear of the Switch. Figure 4-5 Connecting the power cable (1) Power cable (2) Cable clamp (3) AC connector Connect or disconnect the power cable while the power supply unit is installed in the Switch.
  • Page 105 (2) How to disconnect the cable Remove the cable clamp and disconnect the power cable. Connect or disconnect the power cable while the power supply unit is installed in the Switch. While the power cable is connected, power is supplied to the power Warning supply.

  • Page 106: Connecting And Disconnecting The Dc Power Cable

    4.4.2 Connecting and disconnecting the DC power cable If the Switch has a DC power supply unit, connect a grounding cable to ground Warning the Switch. Using the Switch without grounding could result in an electric shock as well as failures due to electrical noise. When using DC power, use a power facility for which the primary side and the Warning secondary side are insulated.
  • Page 107 (1) How to connect the cable [Step 1] Remove the nuts, washers, and tooth lock washers attached to the power supply unit ground terminal and install the grounding cables to the power sources as noted below. Figure 4-7 Connecting the grounding cable (1) Nuts (#-32，measured flat＝6.35mm) (2) Washers (3) Tooth-locked washers...
  • Page 108 [Step 2] (1) Loosen the DC power connector screw. Insert the screwdriver into the cable installation screw hole and loosen the screw. Figure 4-8 Connecting the DC power cable -1 Loosen the screws (1) Cable fixing screw hole (2) Wire insertion hole (0V) (3) Wire insertion hole (-48V) (4) DC power cable (5) 0V...
  • Page 109 Observe the specified stripping length of the sheath (the switch end) for DC power cables. If the striping length is too short, connection may fail or the cable Warning may become disconnected. Conversely, if the striping length is too long, the core will be exposed, risking a fire or electric shock.
  • Page 110 (2) How to disconnect the cable Turn off the circuit breaker of the distribution board before connecting or disconnecting the DC power cable to or from the power facility. Connecting or Warning disconnecting the DC power cable while the circuit breaker is turned on could result in an electric shock.
  • Page 111 [Step 3] Place the DC power connector extraction tool horizontally and disconnect the DC power connector from the power source. Pull out holding on to the DC power cable connector. Figure 4-12 Disconnect the DC power connector Step 3 Step 2 Fit protruding Draw horizontally.

  • Page 112: Inserting And Removing The Memory Card And Dummy Memory Cards

    Switch is being Notification moved, the memory card, or the connector of the memory card slot may be damaged. Note the following when using an SD card with the FortiSwitch-AX3660S. Notification ・ 1GB SD card max size ・ Recommendation: "Hagiwara Solutions NSD6-001GS”...

  • Page 113: How To Remove The Memory Card

    (2) How to remove the memory card [Step 1] After checking that the ACC LEED light is off, insert the memory card until you hear a distinct click. (Pull the memory card slightly forward when the lock unlocks). Figure 4-14 Removing the memory card (1) Memory card [Step 2]...

  • Page 114: Inserting And Removing The Dummy Memory Card

    4.5.2 Inserting and removing the dummy memory card The dummy memory card (referred to below as the “dummy card”) should be insert in memory card slot of the Switch when the memory card is not in use. The dummy card is packaged together with the Unit when shipped. After setting up the Switch, observe the following procedures to use the dummy card.
  • Page 115 (2) How to remove the dummy card [Step 1] Insert the dummy card until you hear a distinct click. (Pull the dummy card slightly forward when the lock unlocks). Figure 4-17 Removing the dummy card (1) Dummy card [Step 2] Remove the memory card.

  • Page 116: Connecting And Disconnecting The Transceiver

    Connecting and disconnecting the transceiver For information on connecting and disconnecting transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual".

  • Page 117: Connecting An Operation Terminal

    Connecting an operation terminal An operation terminal is connected to the Console port of the Switch. To connect an operation terminal, use an RS-232C crossover cable (RJ-45 (male) - D-Sub 9-pin (female)). [Step 1] Insert the connector of an RS-232C cable into the Console port of the Switch until it clicks. Figure 4-19 Connecting an RS-232C cable (1) RS-232C cable...

  • Page 118: Connecting An Interface Cable

    Connecting an interface cable For information on connecting and disconnecting interface cables for NOTE transceivers, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". (1) UTP cable UTP cables can be connected and disconnected while the Switch is powered on. Insert the connector until it clicks. Figure 4-21 Connecting a UTP cable (1) UTP cable...
  • Page 119 (2) Direct attach cable Direct attach cables can be connected and disconnected while the Switch is powered on. [How to connect the cable] Hold the root of the cable and insert the connector until it clicks. Figure 4-22 Connecting a direct attach cable (1) SFP+ slot (2) Connector (3) Cable root...
  • Page 120 [How to disconnect the cable] When removing the direct attach cable, push and hold the back shell of the direct attach cable horizontally toward the Switch (① in the figure below), and pull the pull tab slowly (② in the figure below).

  • Page 121: Turning The Power On And Off

    Turning the power on and off The following is an example of turning on and off the power when an AC power supply unit is installed. Follow the same steps when a DC power supply unit is NOTE installed. For information on connecting the DC power cable, see "4.4.2 and disconnecting the DC power cable Connecting ".

  • Page 122: Turning The Power Off

    The figure above is an example of an AC power supply unit. Follow the same NOTE steps for a DC power supply unit. [Step 2] ● When an AC power supply unit is installed Insert the power plug into an outlet. ●...

  • Page 123: 4.10 Subsequent Operations

    4.10 Subsequent operations (1) Set the time The time is not set when the Unit is purchased. The user must set the time. Refer to Software Manual Configuration Guide Vol.1 for instructions on how to set the time. The Switch maintains time settings for about ten days once the power sources NOTE have been disconnected.

  • Page 124: Adding And Replacing A Power Supply Unit

    Adding and Replacing a Power Supply Unit This chapter describes steps for adding and replacing a power supply unit. 5.1 Necessary tools 5.2 Read the following before you begin 5.3 Adding and replacing a power supply unit 5.4 Replacing a Fan Unit...

  • Page 125: Necessary Tools

    Necessary tools The following tools are required to add, replace, and remove devices. #2 Phillips screwdriver: Used for removing and attaching blank panels. It is also used to disconnect or connect a grounding cable when using a DC power supply unit.

  • Page 126: Read The Following Before You Begin

    Read the following before you begin Adding or replacing a power supply unit, replacing a fan unit must be performed by a trained technician or maintenance personnel. Adding or replacing a power Warning supply unit requires connecting and disconnecting power cables. If anyone other than those mentioned above performs these tasks and handles the parts improperly, a fire, electric shock, or failure could result.

  • Page 127: Adding And Replacing A Power Supply Unit

    Adding and replacing a power supply unit A power supply unit can be replaced while the Switch is powered on. Adding or replacing a power supply unit, replacing a fan unit must be performed by a trained technician or maintenance personnel. Adding or replacing a power Warning supply unit requires connecting and disconnecting power cables.
  • Page 128 [Step 2] Push down the lock lever of the power supply unit in the direction of the arrow. Figure 5-1 Removing (unlocking) a power supply unit (1) Lock lever [Step 3] Remove the power supply unit by slowly pulling it toward you while keeping the locking lever completely down.
  • Page 129 (2) How to install a power supply unit [Step 1] Attach the power supply unit to the power supply unit slot. (Support the bottom surface while attaching.) Figure 5-3 Installing a power supply unit (1) Power supply unit slot (2) Power supply unit [Step 2] Insert the power supply unit until it clicks, and confirm that it is locked.

  • Page 130: Replacing A Fan Unit

    Replacing a Fan Unit A fan unit can be replaced while the Switch is powered on. Adding or replacing a power supply unit, replacing a fan unit must be performed by a trained technician or maintenance personnel. Adding or replacing a power Warning supply unit requires connecting and disconnecting power cables.
  • Page 131 (2) How to install a fan unit Insert the fan unit until it clicks, and confirm that it is locked. Figure 5-5 Installing a fan unit (1) Fany unit (2) Fan unit slot...

  • Page 132: Appendix

    Appendix Appendix A Cleaning the optical connector Appendix B Physical specifications for the network Interface Appendix-1...

  • Page 133: Appendix A Cleaning The Optical Connector

    Appendix A Cleaning the optical connector For information on cleaning optical connectors, see " Transceiver Hardware FortiSwitch-AX Instruction Manual". Appendix-2...

  • Page 134: Appendix B Physical Specifications For The Network Interface

    Appendix B Physical specifications for the network Interface For physical specifications for the network interface of transceivers supported by the Switch, see " Transceiver Hardware Instruction Manual". FortiSwitch-AX Appendix-3...

This manual is also suitable for:
