FortiSwitch-AX2630S
Hardware Instruction Manual
AX26S-H002X
Reading and storing this manual
・ Before you use the equipment, carefully read the manual and make sure that you understand all safety
precautions.
・ After reading the manual, keep it in a convenient place for easy reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FortiSwitch-AX2630S Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fortinet FortiSwitch-AX2630S Series

Summary of Contents for Fortinet FortiSwitch-AX2630S Series

  • Page 1 FortiSwitch-AX2630S Hardware Instruction Manual AX26S-H002X Reading and storing this manual ・ Before you use the equipment, carefully read the manual and make sure that you understand all safety precautions. ・ After reading the manual, keep it in a convenient place for easy reference.
  • Page 2 ■ Relevant products This manual contains information on the FortiSwitch-AX2630S series. ■ Export restrictions When you export this product, please follow the necessary procedures after confirming the regulations of the Foreign Exchange and Foreign Trade Control Law and the export-related laws and regulations of foreign countries such as the U.S.
  • Page 3 Preface ■ About this manual This manual describes how to handle the hardware of Fortinet's FortiSwitch-AX2630S series, a layer 2 switch that supports Gigabit Ethernet. Before you operate the equipment, carefully read the manual and make sure that you understand all instructions and cautionary notes. After reading the manual, keep it in a convenient place for easy reference.
  • Page 4 ■ Reading sequence of the FortiSwitch-AX2630S series manuals Hardware Instruction Manual When you want to check the hardware equipment conditions When you want to know how to handle the hardware When you want to know the FortiSwitch-AX Transceiver Hardware Instruction Manual...
  • Page 5 ■ Abbreviations American Wire Gauge CVCF Constant Voltage Constant Frequency Electronic Industries Alliance International Organization for Standardization Japanese Industrial Standards Local Area Network Light Emitting Diode Memory Card Medium Dependent Interface MDI-X Medium Dependent Interface Crossover NEMA National Electrical Manufacturers Association Power over Ethernet RJ-45 Registered Jack 45...
  • Page 6 Safety and Regulatory Information / Informations sur la sécurité et la réglementation Regulatory Compliances / Conformités réglementaires Emissions / Émissions EN IEC 61000-3-2:2019/A1:2021 CNS15936,105 Class A AS/NZS CISPR 32:2015 Amd1:2020 VCCI-CISPR 32:2016 Class A Immunity / Immunité EN 55035:2017/A11:2020 IEC 61000-4-2/3/4/5/6/8/11 Safety / Sécurité...
  • Page 7 Warning Avertissement When selecting a fiber SFP/SFP+ device, Lors de la sélection d'un périphérique fibre considering safety, please make sure that it SFP/SFP+, compte tenu de la sécurité, can function at a temperature that is not less assurez-vous qu'il peut fonctionner à une than the recommended maximum operational température qui n'est pas inférieure à...
  • Page 8 ● This unit operates under SELV (Safety ● Cet appareil fonctionne dans des conditions Extra Low Voltage) conditions SELV (Safety Extra Low Voltage) according to IEC 60950 and/or conformément aux normes CEI 60950 et/ou 62368-1. The conditions are only 62368-1. Les conditions ne sont maintenues maintained if the equipment to which it que si l'équipement auquel il est connecté...
  • Page 9 Switzerland / The supply plug must comply with La fiche d'alimentation doit être conforme à Suisse SEV/ASE 1011. SEV/ASE 1011. U.K. / The supply plug must comply with La fiche d'alimentation doit être conforme à la ROYAUME-UNI BS1363 (3-pin 13 A) and be fitted norme BS1363 (3 broches 13 A) et être équipée with a 5 A fuse which complies with d'un fusible de 5 A conforme à...

  • Page 10: Safety Information

    Safety Information Safety precautions are indicated by the headings shown below. These headings show a combination of safety warning symbols with headings such as "Warning", "Caution", and "Notification". This is a safety alert symbol. It is used to bring attention to potential hazards that may cause personal injury.
  • Page 11 Safety Information (continued) Warning ■ If anything seems wrong, immediately turn off the power. If smoke or an unusual smell is emanating from the Switch, or if liquid is spilled into the Switch or a foreign object falls into the Switch, immediately turn off the Switch as described below. Continuing operation could result in a fire or electric shock.
  • Page 12 Safety Information (continued) Safety Information (continued) Warning ■ Do not place any objects on the Switch. Do not place any metallic objects, such as a small pin or paper clip, or any vessel containing liquid, such as a vase or a flowerpot, on the Switch. Liquid or metallic objects falling into the Switch could result in a fire or electric shock.
  • Page 13 Safety Information (continued) Safety Information (continued) Warning ■ Observe the specified stripping length of the sheath for DC power cables. Adjust the stripping length of the sheath for the power cable (the switch end) to the specified length. For details on the stripping length, see "2.2.2 ".
  • Page 14 Safety Information (continued) Warning ■ Do not overload the power outlet. Do not overload the power outlet by connecting multiple power plugs to the same outlet. Overloading the outlet could cause the cord and outlet to overheat, resulting in a fire or a tripped circuit breaker on the distribution board due to excessive power use.
  • Page 15 Safety Information (continued) Caution ■ Keep the Switch out of reach of children. The Switch is not suitable for use where children may be present. ■ Do not install the Switch in a dusty or humid location. Do not install the Switch in a dusty or humid location. Doing so could result in a fire or electric shock.
  • Page 16 Safety Information (continued) Caution ■ When moving the Switch, do not hold the handle on the power supply unit. When moving the Switch, do not hold the handle or lock lever on the power supply unit. The handle or lock lever might come off, resulting in the Switch falling and possibly causing injury. Also, the power supply unit might become deformed, resulting in a fire or electric shock.
  • Page 17 Safety Information (continued) Caution ■ Do not touch the SFP and SFP+ during operation and just after operation stops. The maximum temperature is 75°C during SFP or SFP+ operation (during link establishment). Do not touch them during operation and just after operation stops. Doing so could result in burns.
  • Page 18 Safety Information (continued) Notification ■ Do not block the heat dissipation of the Switch or stack Switches on top of one another. Since FortiSwitch-AX2630S-24T4XW does not have a fan, it also dissipates heat from the top plate of the Switch. Do not stack another device above and below the Switch to block the heat dissipation of the Switch.
  • Page 19 Safety Information (continued) Notification ■ Do not attach any labels to a transceiver. The label attached to the transceiver indicates that the transceiver is a standard product from manufacturer. However, such labels are attached where they do not interfere with heat dissipation from the transceiver or the mechanism that prevents the transceiver from coming loose from the cage.
  • Page 20 Safety Information (continued) Safety Information (continued) Safety Information (continued) Notification ■ Do not place a Switch where it will be exposed to hydrogen sulfide or salt. Placing a Switch in an area where sulfides are present, such as a hot-springs area, or in an area with salty air, such as along a coast, could shorten the life of the Switch.

  • Page 21: Warning Labels

    Safety Information (continued) Warning labels Warning labels are attached to the following locations on the Switch. Check what each warning label indicates before handling the Switch. Also, do not stain or remove the warning labels. Safety-16...

  • Page 22: Table Of Contents

    Table of Contents Preface Safety and Regulatory Information Safety-1 Safety Information Safety-5 Overview of the Switch Switch main body 1.1.1 FortiSwitch-AX2630S-24T4XW 1.1.2 FortiSwitch-AX2630S-48T4XW 1.1.3 FortiSwitch-AX2630S-24P4XW 1.1.4 FortiSwitch-AX2630S-48P4XW 1.1.5 Accessories Power supply unit (PS) 1.2.1 FS-AXF2630-PS26AF15 1.2.2 FS-AXF2630-PS26DF15 1.2.3 FS-AXF2630-PS26AF60 1.2.4 FS-AXF2630-PS26AF92 1.2.5 Power supply unit accessories...
  • Page 23 2.8.3 Cooling conditions for rack mounting Device noise Preparation of Interface Cables and Terminal Interface cable list Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T 3.2.2 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (PoE) 3.2.3 Ethernet 1000BASE-X 3.2.4 Ethernet 10GBASE-R 3.2.5 Stack port Terminals and connection cables 3.3.1 When connecting an operation terminal to the Console port Installation of the Switch...
  • Page 24 Points to be checked before initial installation Operations Required for Initial Installation 6.2.1 Overview of command input modes 6.2.2 Overview of initial installation operations 6.2.3 Login 6.2.4 Set a password for the device administrator 6.2.5 Add a user account and remove the "operator" user account 6.2.6 Set the time Subsequent operations...

  • Page 25: Overview Of The Switch

    Overview of the Switch This chapter describes an overview of each device that comprises the Switch. 1.1 Switch main body 1.2 Power supply unit (PS) 1.3 Transceiver 1.4 Direct attach cable...

  • Page 26: Switch Main Body

    Switch main body The FortiSwitch-AX2630S series is a layer 2 switch that supports Gigabit Ethernet and can be used as a distribution switch whose reliability and scalability are demanded and as a floor switch in a local area network. The FortiSwitch-AX2630S series has the following models.

  • Page 27: External View

    (1) External view Figure 1-1 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 24 ports (4) SFP slot: 2 slots (5) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-2 Rear view (1) Power supply unit slot 1 (2) AC connector...

  • Page 28: Front Panel

    (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-2 LED indications and connectors". Figure 1-3 Front panel layout ) (2) Port1 Port25 Port24 Port30 Direct attach cables can be used only for Port 29 and Port 30. These ports can NOTE also be used as stack ports.

  • Page 29: Rear Panel

    Name Type Status Description 1-24 LED: Indicates the operating Green A link has been established. Green or status of (UTP) Blinking A link is established, and frames are being sent 10BASE-T/100BASE-TX orange green or received. /1000BASE-T ports. Orange Line failure detection Link failure or block when the ST1 LED is lit up green 25-26...
  • Page 30 (1) External view Figure 1-5 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 48 ports (4) SFP slot: 2 slots (5) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-6 Rear view (1) Power supply unit slot 1 (2) AC connector...
  • Page 31 (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-3 LED indications and connectors". Figure 1-7 Front panel layout 1) (2) (3) Port1 Port49 Port48 Port54 Direct attach cables can be used only for Port 53 and Port 54. These ports can NOTE also be used as stack ports.

  • Page 32: Fortiswitch-Ax2630S-24P4Xw

    Name Type Status Description 1-48 LED: Green Indicates the operating Green A link has been established. status or orange (UTP) Blinking A link is established, and frames are being sent 10BASE-T/100BASE-TX green or received. /1000BASE-T ports. Orange Line failure detection Link failure or block when the ST1 LED is lit up green 49-50...
  • Page 33 (1) External view Figure 1-9 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port (PoE): 24 ports (4) SFP slot: 2 slots (5) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-10 Rear view (1) Power supply unit slot 1 (2) Power supply unit slot 2...
  • Page 34 (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-4 LED indications and connectors". Figure 1-11 Front panel layout (1) (2) (3) Port1 Port25 Port24 Port30 Direct attach cables can be used only for Port 29 and Port 30. These ports can NOTE also be used as stack ports.

  • Page 35: Fortiswitch-Ax2630S-48P4Xw

    Name Type Status Description 1-24 LED: Green Indicates the operating Green A link has been established. or orange status of (UTP) Blinking A link is established, and frames are being sent 10BASE-T/100BASE-TX green or received. /1000BASE-T ports. Orange Line failure detection Link failure or block when the ST1 LED is lit up green 25-26...
  • Page 36 (1) External view Figure 1-13 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port (PoE): 48 ports (4) SFP slot: 2 slots (5) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-14 Rear view (1) Power supply unit slot 1 (2) Power supply unit slot 2...
  • Page 37 (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-5 LED indications and connectors". Figure 1-15 Front panel layout Port1 Port49 1) (2) (3) Port48 Port54 Direct attach cables can be used only for Port 53 and Port 54. These ports can NOTE also be used as stack ports.

  • Page 38: Accessories

    Name Type Status Description 1-48 LED: Green Indicates the operating Green A link has been established. or orange status of (UTP) Blinking A link is established, and frames are being sent 10BASE-T/100BASE-TX green or received. /1000BASE-T ports. Orange Line failure detection Link failure or block when the ST1 LED is lit up green 49-50...

  • Page 39: Safety Guide

    (2) Safety Guide This guide provides important information for ensuring safe use of the Switch. Please read this guide completely before using the Switch. (3) Rack mounting brackets The brackets are used when mounting the Switch in a 19-inch cabinet rack. Figure 1-17 Rack mounting brackets (4) Screws...

  • Page 40: Power Cable

    (6) Power cable AC power cable. Figure 1-20 Power cable When using the Switch at AC power supply, use the power cable supplied or one that meets the specifications of your country. Using another cable could result in a Warning fire or electric shock.

  • Page 41: Power Supply Unit (Ps)

    Power supply unit (PS) The power supply unit supplies power to the Switch and is mounted to the power supply unit slot of the Switch. 1.2.1 FS-AXF2630-PS26AF15 This AC power supply unit is used for FortiSwitch-AX2630S-24T4XW and FortiSwitch-AX2630S-48T4XW, and supports 100 to 240 V AC power supplies. Figure 1-22 External view (1) LED...

  • Page 42: Fs-Axf2630-Ps26Df15

    1.2.2 FS-AXF2630-PS26DF15 This DC power supply unit is used for FortiSwitch-AX2630S-24T4XW and FortiSwitch-AX2630S-48T4XW, and supports -36 to -72 V DC power supply. Figure 1-23 External view (1) LED (2) Lever (3) DC connector (4) Handle Table 1-8 LED indications Name Type Status Description...

  • Page 43: Fs-Axf2630-Ps26Af60

    1.2.3 FS-AXF2630-PS26AF60 This AC power supply unit is used for FortiSwitch-AX2630S-24P4XW, and supports 100 to 240 V AC power supplies. Figure 1-24 External view (1) LED (2) Lever (3) Cable clamp (4) AC connector (5) Handle Table 1-9 LED indications Name Type Status...

  • Page 44: Fs-Axf2630-Ps26Af92

    1.2.4 FS-AXF2630-PS26AF92 This AC power supply unit is used for FortiSwitch-AX2630S-48P4XW, and supports 100 to 240 V AC power supplies. Figure 1-25 External view (1) LED (2) Lever (3) Cable clamp (4) AC connector (5) Handle Table 1-10 LED indications Name Type Status...

  • Page 45: Power Supply Unit Accessories

    1.2.5 Power supply unit accessories The following items are included as accessories with the Switch when shipped from the factory. Table 1-11 Power supply unit accessories Item name Quantity Remarks Packing list Safety Guide AC power cable DC connector (1) Packing list Items that are included with the power supply unit when shipped from the factory are listed.
  • Page 46 (4) DC connector This is a dedicated power connector for the FS-AXF2630-PS26DF15. This connector is included with the FS-AXF2630-PS26DF15. Figure 1-27 DC connector...

  • Page 47: Transceiver

    Transceiver For transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual" or "FortiSwitch AX2630S Series Datasheet".

  • Page 48: Direct Attach Cable

    Direct attach cable The direct attach cable is an interface cable with transceiver-shaped ends. For direct attach cable supported by the Switch, see "FortiSwitch AX2630S Series Datasheet". Do not attach any labels to connectors. Attaching a label to a location that interferes with heat dissipation or the Notification cable latch mechanism could cause a malfunction of the direct attach cable or cause damage to the Switch.

  • Page 49: Preparation For Installation

    Preparation for Installation This chapter describes the environmental conditions and preparation required to install the Switch. Before you begin preparation for Switch installation, carefully read this chapter and make sure that you understand all instructions and cautionary notes. 2.1 Installation conditions 2.2 Power facility 2.3 Consideration for electrical noise 2.4 Leakage current...

  • Page 50: Installation Conditions

    Installation conditions Installation conditions for the Switch are as follows. An installation environment must satisfy these conditions. Table 2-1 General installation conditions for the Switch (1/2) Model name Item FortiSwitch-AX2630S-24T4XW FortiSwitch-AX2630S-48T4XW Dimensions (W x D x H) 440 x 350 x 44 mm Weight 4.4 kg 4.9 kg...
  • Page 51 Table 2-2 General installation conditions for the Switch (2/2) Model name Item FortiSwitch-AX2630S-24P4XW FortiSwitch-AX2630S-48P4XW Dimensions (W x D x H) 440 x 350 x 44 mm Weight 5.8 kg 6.4 kg 100 - 240 V ～ Input Rated voltage 90 - 264 V ～ Fluctuation range Frequency...
  • Page 52 Reference value: If PoE power supply is not used and the Switch environment temperature is 86°F(30°C) • FortiSwitch-AX2630S-24P4XW: 40 dB or less • FortiSwitch-AX2630S-48P4XW: 53 dB or less *9 According to General Requirements for Measuring Methods for Suspended Particulate Matter Concentration in Air (JIS Z 8813). *10 The internal temperature is the one displayed by the "show system"...

  • Page 53: Power Facility

    Power facility 2.2.1 AC power facility (1) Outlet Use the OUTLET one that meets the specifications of your country. Installation and removal of the unit must be carried out by qualified personnel Warning only. Always use a grounded power outlet. Using the Switch without grounding could Warning result in an electric shock as well as failures due to electrical noise.
  • Page 54 (3) Conditions for supplying power to the distribution board Ensure that the capacity for incoming current to the distribution board is greater than the operating current of the circuit breaker shown in "(2) Distribution board". Ensure that the capacity of incoming current to the distribution board is greater than the operating current of the circuit breakers on the distribution board.

  • Page 55: Dc Power Facility

    2.2.2 DC power facility When using DC power, use an electric shock risk-free power facility for which the Warning primary side and the secondary side are insulated. Using a power facility that is not insulated could result in an electric shock. (1) DC power cable No power cable is included with the Switch.
  • Page 56 (2) Distribution board Install a breaker on the branch circuit of the distribution board that supplies power to the Switch. ➢ Breaker rating: 15AT or less Install the distribution board in the same room as the Switch or in a neighboring Warning room to ensure easy access and operation.

  • Page 57: Consideration For Electrical Noise

    Consideration for electrical noise Electrical noise generated by other equipment may cause a Switch failure. Please develop the power facility plan to observe the following points. ⚫ Do not connect a device (such as an air conditioner) whose power is repeatedly turned on and off by a relay, micro-switch, etc., to the branch circuit of the power supply used for the Switch.

  • Page 58: Leakage Current

    Leakage current The Switch is equipped with a noise filter to prevent failure caused by electrical noise. As a result, leakage current flows through the safety ground wire (class D grounding). A maximum leakage current of 1 mA flows per device, so if you are required to install an earth leakage breaker under the Fire Services Act and other laws, take this into consideration.

  • Page 59: Environmental Requirements

    Environmental requirements (1) Dust The Switch uses cooling fans, so do not install it in a humid or dusty place. The dust conditions for the Switch are as follows. ➢ Suspended particulate concentration: 0.15 mg/m or less (JIS Z 8813, General Requirements for Measuring Methods for Suspended Particulate Matter Concentration in Air) Do not install the Switch in a location near a printer or in a location with a lot of...
  • Page 60 In particular, optical fiber cables should be protected by metal covers, etc., with a bending radius of at least 100 mm in the major axis direction and at least 50 mm in the minor axis direction. In addition, the optical fiber cable that accommodates the required number of optical fiber cores must have a structure that can protect the cable itself from mechanical stress such as repeated bending, tensile tension, compression, and ironing during installation, and stress from the installation environment.

  • Page 61: Installation Location

    Installation location Use the Switch indoors. Also, make sure that all interface cables to be connected Warning to the Switch are indoor-wired. If connecting a cable that is laid outdoors, ensure that lightning protection measures have been taken before connection. The Switch can be used installed on a table or mounted in a 19-inch cabinet rack.
  • Page 62 (2) 19-inch cabinet rack When mounting the Switch in a rack, use a rack that satisfies the conditions in the table below. Table 2-7 Rack conditions Item Conditions Rack standard EIA standard compliant 19-inch cabinet rack For ventilation, the cabinet rack should secure a space of at least 50 Space for ventilation mm between rack structures such as rack posts, side plates, and the ventilation slots of the Switch.

  • Page 63: Maintenance Area

    Maintenance area Secure the following space as the maintenance area for the Switch. (1) Maintenance area for installation on a table Figure 2-1 Maintenance area for installation on a table Switch Front (Unit: mm) (2) Maintenance area for rack mounting Figure 2-2 Maintenance area for rack mounting 1000...

  • Page 64: Cooling Conditions

    Cooling conditions 2.8.1 Airflow The airflow of the Switch is as follows. (1) FortiSwitch-AX2630S-24T4XW Figure 2-3 Airflow of FortiSwitch-AX2630S-24T4XW Intake and exhaust Intake and exhaust Intake and exhaust Intake and exhaust (2) FortiSwitch-AX2630S-48T4XW, FortiSwitch-AX2630S-24P4XW, and FortiSwitch-AX2630S-48P4XW Figure 2-4 Airflow of FortiSwitch-AX2630S-48T4XW, FortiSwitch-AX2630S-24P4XW, and FortiSwitch-AX2630S-48P4XW Exhaust Intake...

  • Page 65: Cooling Conditions

    2.8.2 Cooling conditions Secure a space of at least 50 mm from each side of the Switch to ensure air flow. Do not obstruct the ventilation slots of the Switch. Doing so causes heat to Caution accumulate inside the Switch, and could result in a fire. Maintain a space of at least 50 mm around the ventilation slots.

  • Page 66: Device Noise

    Device noise The Switch has built-in cooling fan units, which generate noise. Before installing the Switch, consider such noise to plan your layout. For device noise, see "2.1 ". Installation conditions If FortiSwitch-AX2630S-24T4XW is not equipped with FS-AXF2630-PS26AF15 or FS-AXF2630-PS26DF15, noise will not occur. The following are some examples of a layout that reflects considerations specific to noise.

  • Page 67: Preparation Of Interface Cables And Terminal

    Preparation of Interface Cables and Terminal This chapter describes interface cables and terminal to be used with the Switch. 3.1 Interface cable list 3.2 Network interface specifications 3.3 Terminals and connection cables...

  • Page 68: Interface Cable List

    Interface cable list Interface cable connections with the Switch are listed below. The following cables must be prepared by the customer. For interface cables to be used for the transceiver, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". Table 3-1 Interface cables Port Transceiver Interface...

  • Page 69: Network Interface Specifications

    Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (1) Mode setting for ports For Ethernet 10BASE-T/100BASE-TX/1000BASE-T ports, the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 100BASE-TX full duplex (fixed) ➢...

  • Page 70: Physical Specifications

    (4) Physical specifications Table 3-2 10BASE-T/100BASE-TX/1000BASE-T physical specifications Physical specifications Item 10BASE-T 100BASE-TX 1000BASE-T Category 3 and Category 5 and Enhanced higher higher UTP cable category 5 and higher Transmission 100m 100m 100m distance (maximum) Table 3-3 10BASE-T/100BASE-TX/1000BASE-T pin configuration RJ-45 Physical specifications Pin No.

  • Page 71: Ethernet 10Base-T/100Base-Tx/1000Base-T (Poe)

    3.2.2 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (PoE) (1) Mode setting for ports For Ethernet 10BASE-T/100BASE-TX/1000BASE-T ports (PoE), the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 100BASE-TX full duplex (fixed) ➢...
  • Page 72 Table 3-4 Power supply pin assignment RJ45 pin number Pair Signal name Negative Vport Negative Vport Positive Vport Positive Vport (5) Physical specifications Table 3-5 10BASE-T/100BASE-TX/1000BASE-T physical specifications Physical specifications Item 10BASE-T 100BASE-TX 1000BASE-T Category 5 and Category 5 and Enhanced category UTP cable higher...

  • Page 73: Ethernet 1000Base-X

    3.2.3 Ethernet 1000BASE-X (1) Mode setting for ports For Ethernet 1000BASE-X ports, the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 1000BASE-X full duplex (fixed) NOTE Half-duplex communication is not supported.

  • Page 74: Stack Port

    3.2.5 Stack port (1) Supported ports The following ports can be used as stack ports. ・ FortiSwitch-AX2630S-24T4XW SFP+ slots (Ports 29, 30) ・ FortiSwitch-AX2630S-48T4XW SFP+ slots (Ports 53, 54) ・ FortiSwitch-AX2630S-24P4XW SFP+ slots (Ports 29, 30) ・ FortiSwitch-AX2630S-48P4XW SFP+ slots (Ports 53, 54) (2) Flow control function Both receiving and sending operations are turned off.

  • Page 75: Terminals And Connection Cables

    Terminals and connection cables 3.3.1 When connecting an operation terminal to the Console port (1) Operation terminals When connecting an operation terminal to the Console port of the Switch, prepare a personal computer or workstation that supports the following functions. Table 3-8 Operation terminal Item...

  • Page 76: Installation Of The Switch

    Installation of the Switch This chapter describes how to install the Switch. 4.1 Necessary tools and equipment 4.2 Read the following before you begin 4.3 Installing the Switch 4.4 Connecting and disconnecting the power cable 4.5 Inserting and removing the memory card 4.6 Connecting and disconnecting the transceiver 4.7 Connecting an operation terminal 4.8 Connecting an interface cable...

  • Page 77: Necessary Tools And Equipment

    Necessary tools and equipment The following tools and equipment are required to install the Switch. #2 Phillips screwdriver: Used to attach rack mounting brackets to the Switch and to attach or remove the Switch to or from a rack using M5 screws. Also used to connect or disconnect the grounding cable.

  • Page 78: Read The Following Before You Begin

    Read the following before you begin Keep the Switch out of reach of children. The Switch is not suitable for use Caution where children may be present. Place the Switch horizontally when installing it on a table. The Switch may fall Caution over if placed vertically or leaned against a wall, resulting in injury or failure.

  • Page 79: Installing The Switch

    Installing the Switch This section describes how to install the Switch on a table and in a rack. Please follow the steps below. When moving the Switch, do not hold the handle on the rear of the Switch. The handle may come off, resulting in the device falling and possibly causing injury. Caution Also, the power supply module may become deformed, resulting in a fire or electric shock.

  • Page 80: Installing The Switch On A Table

    4.3.2 Installing the Switch on a table The Switch can be installed on a horizontal and stable flat surface. Follow the following steps to install the Switch. [Step 1] Place the Switch upside down on a flat surface. [Step 2] Attach the rubber feet (4 pieces) to the Switch.
  • Page 81 NOTE Use the supplied screws to attach the rack mounting brackets to the Switch. Figure 4-3 Attaching the rack mounting brackets (1) Rack mounting bracket (2) Screws (M4x6, 8 screws) When mounting the Switch in a rack, if it is not possible to secure a space (for pulling out cables) in front of the Switch, attach the rack mounting brackets to NOTE protrude 50 mm from the front side as shown in the figure below.
  • Page 82 [Step 2] Mount the Switch in a rack. When mounting the Switch onto a rack, two or more persons should perform the Caution task. Lifting the Switch by yourself may cause it to fall over, which could result in injury. When mounting the Switch in a rack, make sure that the Switch is stable.

  • Page 83: Connecting And Disconnecting The Power Cable

    Connecting and disconnecting the power cable This section describes steps for connecting/disconnecting the power cable to/from the Switch. Follow the steps below to connect/disconnect the power cable. 4.4.1 Connecting and disconnecting the AC power cable Use the supplied or a designated power cable. Using another cable could result Warning in a fire or electric shock.
  • Page 84 The Switch does not have a power switch. Connecting the power cable starts the NOTE supply of power to the Switch. [Step 2] Clamp the connector of the power cable with the cable clamp. Figure 4-7 Clamping the power cable 1 Tighten 2 Push Notification...

  • Page 85: Connecting And Disconnecting The Dc Power Cable

    4.4.2 Connecting and disconnecting the DC power cable If the Switch has a DC power supply unit, connect a grounding cable to ground Warning the Switch. Using the Switch without grounding could result in an electric shock as well as failures due to electrical noise. When using DC power, use a power facility for which the primary side and the Warning secondary side are insulated.
  • Page 86 (1) How to connect the cable [Step 1] Insert a screwdriver into the hole of each cable fixing screw on the DC connector and loosen the screw. Figure 4-8 Connecting the DC power cable -1 (1) Cable fixing screw hole (2) Wire insertion hole (+) (3) Wire insertion hole (-) (4) Wire insertion hole (FG)
  • Page 87 Turn off the circuit breaker of the distribution board before connecting or Warning disconnecting the DC power cable. Connecting or disconnecting the DC power cable while the circuit breaker is turned on could result in an electric shock. Observe the specified stripping length of the sheath (the switch end) for DC power cables.
  • Page 88 (2) How to disconnect the cable To disconnect the DC power cable, follow the procedure in "(1) How to connect the cable" in the reverse order. Turn off the circuit breaker of the distribution board before connecting or disconnecting the DC power cable to or from the power facility. Connecting or Warning disconnecting the DC power cable while the circuit breaker is turned on could result in an electric shock.

  • Page 89: Inserting And Removing The Memory Card

    Inserting and removing the memory card The memory card can be inserted and removed while the Switch is powered on. When moving the Switch, remove USB memory from the Switch. If the USB memory are subjected to excessive force while the Switch is being moved, Notification the USB memory, or the connector of the memory card slot may be damaged.

  • Page 90: How To Remove The Memory Card

    (2) How to remove the memory card After confirming that the memory card is no longer being accessed, slowly pull the memory card straight out. Figure 4-12 Removing the memory card (1) Memory card When the memory card is being accessed, do not remove the memory card or turn off the power.

  • Page 91: Connecting And Disconnecting The Transceiver

    Connecting and disconnecting the transceiver For information on connecting and disconnecting transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual".

  • Page 92: Connecting An Operation Terminal

    Connecting an operation terminal An operation terminal is connected to the Console port of the Switch. To connect an operation terminal, use an RS-232C crossover cable (RJ-45 (male) - D-Sub 9-pin (female)). [Step 1] Insert the connector of an RS-232C cable into the Console port of the Switch until it clicks. Figure 4-13 Connecting an RS-232C cable (1) RS-232C cable...

  • Page 93: Connecting An Interface Cable

    Connecting an interface cable For information on connecting and disconnecting interface cables for NOTE transceivers, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". (1) UTP cable UTP cables can be connected and disconnected while the Switch is powered on. Insert the connector until it clicks. Figure 4-15 Connecting a UTP cable (1) 10/100/1000BASE-T port...
  • Page 94 (2) Direct attach cable Direct attach cables can be connected and disconnected while the Switch is powered on. [How to connect the cable] Hold the root of the cable and insert the connector until it clicks. Figure 4-16 Connecting a direct attach cable (1) SFP+ slot (2) Connector (3) Cable root...
  • Page 95 [How to disconnect the cable] When removing the direct attach cable, push and hold the back shell of the direct attach cable horizontally toward the Switch (① in the figure below), and pull the pull tab slowly (② in the figure below).

  • Page 96: Turning The Power On And Off

    Turning the power on and off The following is an example of turning on and off the power when an AC power supply unit is installed. Follow the same steps when a DC power supply unit is NOTE installed. For information on connecting the DC power cable, see "4.4.2 Connecting and disconnecting the DC power cable ".

  • Page 97: Turning The Power Off

    [Step 2] ● When an AC power supply unit is installed Insert the power plug into an outlet. ● When a DC power supply unit is installed Turn on the circuit breaker of the distribution board. (2) Turning the power off Disconnect all the power cable from the rear of the Switch.

  • Page 98: Adding And Replacing A Power Supply Unit

    Adding and Replacing a Power Supply Unit This chapter describes steps for adding and replacing a power supply unit. 5.1 Necessary tools 5.2 Read the following before you begin 5.3 Adding and replacing a power supply unit...

  • Page 99: Necessary Tools

    Necessary tools The following tools are required to add, replace, and remove devices. #2 Phillips screwdriver: Used for removing and attaching blank panels. 2 mm diameter flathead screwdriver: Used when using FS-AXF2630-PS26DF15, when disconnecting or connecting the DC power cable from or to the DC connector, or when removing or inserting the DC connector from or to FS-AXF2630-PS26DF15.

  • Page 100: Read The Following Before You Begin

    Read the following before you begin Adding or replacing a power supply unit must be performed by a trained technician or maintenance personnel. Adding or replacing a power supply unit Warning requires connecting and disconnecting power cables. If anyone other than those mentioned above performs these tasks and handles the parts improperly, a fire, electric shock, or failure could result.

  • Page 101: Adding And Replacing A Power Supply Unit

    Adding and replacing a power supply unit A power supply unit can be replaced while the Switch is powered on. Adding or replacing a power supply unit must be performed by a trained technician or maintenance personnel. Adding or replacing a power supply unit Warning requires connecting and disconnecting power cables.
  • Page 102 [Step 2] Push down the lock lever of the power supply unit in the direction of the arrow. Figure 5-1 Removing (unlocking) a power supply unit ● For FortiSwitch-AX2630S-24T4XW and FortiSwitch-AX2630S-48T4XW: (1) Lock lever It may be difficult to remove a power supply unit. Push down the lock lever NOTE completely.
  • Page 103 Figure 5-2 Removing a power supply unit ● For FortiSwitch-AX2630S-24T4XW and FortiSwitch-AX2630S-48T4XW: (1) Power supply unit (2) Handle If removing a power supply unit is difficult, push the body of the power supply unit NOTE toward the Switch and then push down the lock lever completely and remove the unit.
  • Page 104 (2) How to install a power supply unit [Step 1] Attach the power supply unit to the power supply unit slot. (Support the bottom surface while attaching.) Figure 5-3 Installing a power supply unit (1) Power supply unit slot (2) Power supply unit FortiSwitch- The figure above is an example of AX2630S-24T4XW.
  • Page 105 [Step 1] and [Step 2] are examples of FS-AXF2630-PS26AF15. Follow the same NOTE steps for FS-AXF2630-PS26DF15 as well. ● For FortiSwitch-AX2630S-24P4XW and FortiSwitch-AX2630S-48P4XW: (1) Lock lever [Step 3] Connect the power cable to the power supply unit. For information on connecting the power cable, see "4.4 Connecting and disconnecting the ".

  • Page 106: Operations Required For Initial Installation

    Operations Required for Initial Installation This chapter describes how to set the administrator mode password, add and delete user accounts, and set the time, all of which are required for initial installation. 6.1 Points to be checked before initial installation 6.2 Operations Required for Initial Installation 6.3 Subsequent operations...

  • Page 107: Points To Be Checked Before Initial Installation

    Points to be checked before initial installation The following are the points that you must check before initial installation. (1) Confirm the progress until the device starts up The process from turning on the power to starting up the Switch is described below. ➢...

  • Page 108: Operations Required For Initial Installation

    Operations Required for Initial Installation The operations required for initial installation are described below. 6.2.1 Overview of command input modes The command input mode for the Switch command line interface (CLI) includes user mode, administrator mode, and configuration command mode. To set and change the configuration or check the status of the Switch, you must enter an appropriate command input mode, and then type a configuration command or operation command.

  • Page 109: Overview Of Initial Installation Operations

    ● Configuration command mode When you type the configure command in administrator mode, you switch to configuration command mode. By using configuration commands in configuration command mode, the configuration of the Switch can be set and changed. Each command input mode in which operation commands can be executed is described in the "Software Manual Operation Command Reference".

  • Page 110: Login

    6.2.3 Login The "login" prompt appears when the Switch starts up. Enter your user ID after the "login" prompt to log in to the Switch. …Type the user name "operator". login: operator …Press the [Enter] key. Password: …A banner appears. No password is set.

  • Page 111: Add A User Account And Remove The "Operator" User Account

    6.2.5 Add a user account and remove the "operator" user account [Step 1] Create a user account and set a login password. Create a new user account and set a login password. The following example shows how to create the new user name "newuser" and set a login password.

  • Page 112: Set The Time

    6.2.6 Set the time The following example shows the steps for setting the time to "August 6, 2021, 15:30" in Japan time. …Switch to configuration command mode. # configure …Set the time zone to JST and the offset from UTC to +9. (config)# clock timezone JST +9 …Save the time zone setting.

  • Page 113: Subsequent Operations

    Subsequent operations (1) Operation management and configuration setting For details on operation management and configuration setting, see the following manuals. ● Manuals to reference during operation management and configuration setting • Software Manual Configuration Guide Vol. 1 • Software Manual Configuration Guide Vol. 2 ●...

  • Page 114: Appendix

    Appendix Appendix A Cleaning the optical connector Appendix B Physical specifications for the network Interface Appendix-1...

  • Page 115: Appendix A Cleaning The Optical Connector

    Appendix A Cleaning the optical connector For information on cleaning optical connectors, see " Transceiver Hardware FortiSwitch-AX Instruction Manual". Appendix-2...

  • Page 116: Appendix B Physical Specifications For The Network Interface

    Appendix B Physical specifications for the network Interface For physical specifications for the network interface of transceivers supported by the Switch, see " Transceiver Hardware Instruction Manual". FortiSwitch-AX Appendix-3...
