FortiSwitch-AX3660S

Quick Start Guide

AX36S-Q003X

Reading and storing this manual

・ Before you use the equipment, carefully read the manual and make sure that you understand all safety

precautions.

・ After reading the manual, keep it in a convenient place for easy reference.

Table of Contents

Need help?

Do you have a question about the FortiSwitch-AX3660S Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fortinet FortiSwitch-AX3660S Series

Page 1 FortiSwitch-AX3660S Quick Start Guide AX36S-Q003X Reading and storing this manual ・ Before you use the equipment, carefully read the manual and make sure that you understand all safety precautions. ・ After reading the manual, keep it in a convenient place for easy reference.
Page 2 ■ Relevant products This manual contains information on the FortiSwitch-AX3660S series. ■ Export restrictions When you export this product, please follow the necessary procedures after confirming the regulations of the Foreign Exchange and Foreign Trade Control Law and the export-related laws and regulations of foreign countries such as the U.S.
Page 3 Thank you for choosing an FortiSwitch-AX3660S series switch. This guide describes the procedures from unpacking to the basic configuration of FortiSwitch-AX3660S series switches. In addition, the Guide also explains how to use the Manuals for the FortiSwitch-AX3660S series switches to ensure stable operation of the Unit.
Page 4 Safety and Regulatory Information / Informations sur la sécurité et la réglementation Regulatory Compliances / Conformités réglementaires Emissions / Émissions EN IEC 61000-3-2:2019/A1:2021 CNS15936,105 Class A AS/NZS CISPR 32:2015 Amd1:2020 VCCI-CISPR 32:2016 Class A Immunity / Immunité EN 55035:2017/A11:2020 IEC 61000-4-2/3/4/5/6/8/11 Safety / Sécurité...
Page 5 Warning Avertissement When selecting a fiber SFP/SFP+/QSFP+/ Lors de la sélection d'un périphérique fibre QSFP28 device, considering safety, please SFP/SFP+/QSFP+/QSFP28, compte tenu de la make sure that it can function at a sécurité, assurez-vous qu'il peut fonctionner à une temperature that is not less than the température qui n'est pas inférieure à...
Page 6 ● This unit operates under SELV (Safety ● Cet appareil fonctionne dans des conditions Extra Low Voltage) conditions SELV (Safety Extra Low Voltage) according to IEC 60950 and/or conformément aux normes CEI 60950 et/ou 62368-1. The conditions are only 62368-1. Les conditions ne sont maintenues maintained if the equipment to which it que si l'équipement auquel il est connecté...
Page 7 The mains cord must comply with norme IEC 60227 (désignation 60227 IEC 52). IEC 60227 (designation 60227 IEC 52). Europe / The supply plug must comply with La fiche d'alimentation doit être conforme à CEE7/7 (“SCHUKO”). L'Europe CEE7/7 ("SCHUKO"). The mains cord must comply with Le cordon d'alimentation doit être conforme à...
Page 8: Safety Information
Safety Information Safety precautions are indicated by the headings shown below. These headings show a combination of safety warning symbols with headings such as "Warning", "Caution", and "Notification". This is a safety alert symbol. It is used to bring attention to potential hazards that may cause personal injury.
Page 9 Safety Information (continued) Warning ■ If anything seems wrong, immediately turn off the power. If smoke or an unusual smell is emanating from the Switch, or if liquid is spilled into the Switch or a foreign object falls into the Switch, immediately turn off the Switch as described below. Continuing operation could result in a fire or electric shock.
Page 10 Safety Information (continued) Warning ■ Do not repair, modify, or disassemble the Switch. Do not repair, modify, or disassemble the Switch. Doing so could result in an electric shock, fire, or burns. The power unit in particular contains many high-voltage components, and touching them would be dangerous.
Page 11 Safety Information (continued) Safety Information (continued) Warning ■ Connecting and disconnecting a DC power cable must be performed by a trained technician or maintenance personnel. Connecting or disconnecting a DC power cable to or from a power facility must be performed by a trained technician or maintenance personnel.
Page 12 Safety Information (continued) Safety Information (continued) Warning Warning ■ Be careful of poor contact and tracking of the power plug. If the power plug is not used as follows, it may overheat due to tracking or poor contact, resulting in a fire. ●...
Page 13 Safety Information (continued) Warning ■ Do not use an air duster near a flame. When cleaning the optical connectors, do not use an air duster that contains flammable gas near a flame. Doing so could result in a fire. ■ Storage of packing plastic bags Keep the packaging bag for the Switch out of reach of small children.
Page 14 Safety Information (continued) Caution ■ Keep the Switch out of reach of children. The Switch is not suitable for use where children may be present. ■ Do not install the Switch in a dusty or humid location. Do not install the Switch in a dusty or humid location. Doing so could result in a fire or electric shock.
Page 15 Safety Information (continued) Caution ■ When moving the Switch, do not hold the handle on the power supply unit, fan unit. When moving the Switch, do not hold the handle or lock lever on the power supply unit or fan unit.
Page 16 Safety Information (continued) Caution ■ Do not touch the FN-TRAN-GC, FN-TRAN-SFP+ZR, or FN-TRAN-QSFP28 when they are in motion, or immediately after they have been powered down. The temperature during operation of FN-TRAN-GC, FN-TRAN-SFP+ZR, or FN-TRAN-QSFP28 could should be no higher than 65℃ Do not touch the Unit while it is operating or immediately after it stops.
Page 17 Safety Information (continued) Notification ■ Check the usage environment of the Switch. Installation conditions must be met for the usage environment of the Switch. For example, if the Switch is exposed to direct sunlight or near a heating appliance such as a stove, the internal temperature will rise and may cause the Switch to malfunction.
Page 18 Safety Information (continued) Notification ■ After removing a power supply unit, attach a blank panel. Attach a blank panel to a slot in which a power supply unit is not installed. If you use the Switch without attaching the blank panel, airflow inside the Switch cannot be maintained. If airflow is not maintained, the temperature inside the Switch rises, resulting in a failure.
Page 19 Safety Information (continued) Safety Information (continued) Safety Information (continued) Notification ■ Protect the Switch when using a fuming liquid. Before using a fuming liquid such as a pesticide, completely wrap the Switch with a plastic sheet or similar protection. If the fuming liquid enters the Switch, this may cause a Switch failure.
Page 20: Table Of Contents
Table of Contents Preface Safety and Regulatory Information Safety-1 Getting Ready Reading sequence of the FortiSwitch-AX3660S series manuals Check Items Included in Box Get Required Items Ready Equipment Setup Equipment Setup Other Operations Operations Required at Initial Installation Overview of command input modes...
Page 21: Getting Ready
This Chapter indicates the steps required to use the unit. It also explains the manual style, the importance of this Guide, and how to refer to the Manuals for the FortiSwitch-AX3660S Series. 1.1 Reading sequence of the FortiSwitch-AX3660S series manuals 1.2 Check Items Included in Box 1.3 Get Required Items Ready...
Page 22: Reading Sequence Of The Fortiswitch-Ax3660S Series Manuals
Reading sequence of the FortiSwitch-AX3660S series manuals The following chart provides an overview of how to view the FortiSwitch-AX3660S Series Manual. This Guide indicates how to perform the basic settings after unpacking the box. Note that it explains only the most necessary basic information. Refer to the Manuals noted below on how to use the numerous features of the FortiSwitch-AX3660S Series products.
Page 23: Check Items Included In Box
Check Items Included in Box Refer to the list of accessory items included in the box, and check that all are included.
Page 24: Get Required Items Ready
Get Required Items Ready To set up, get the following equipment ready in addition to the unit and options. ● Terminal Set up a personal computer or workstation supporting the following features. Table 1-1 Operation terminal (when connecting to the Console port) Item Specifications Communication port...
Page 25: Equipment Setup
Equipment Setup This Chapter covers the process from connecting equipment such as power cables and interface cables to the unit through powering on the device. 2.1 Equipment Setup 2.2 Other Operations...
Page 26: Equipment Setup
Equipment Setup The following is an overview of equipment setup. Step 1 Attaching the Wrist Strap Attach the wrist strap to prevent static electricity and protect the equipment from static electricity. Step 2 Attaching the Operational Terminal 1. Connect with the operational terminal to the console port. To connect the operation terminal, use the RS-232C closed cable.
Page 27 Step 5 Checking the LEDs When the ST1 LED on the Switch green light on, this indicates that it has launched. ST1 LED The following illustrates the process though powering on of the device. Power on Launch complete Self-diagnosis / software loading Device on Green light on Green light blinking...
Page 28: Other Operations
Other Operations ● Installing and removing option modules Regarding installing and removing of optional modules such as fan units, power ports, memory cards, transceivers, etc., refer to the ”FortiSwitch-AX3660S Hardware Instruction Manual" and "FortiSwitch-AX Transceiver Hardware Instruction Manual". ● Details on the Switch main body and options Regarding the names and details on the Switch main body and the various option modules, refer to the ”FortiSwitch-AX3660S Hardware Instruction Manual".
Page 29: Operations Required At Initial Installation
Operations Required at Initial Installation This Chapter covers password setup for Administrator Mode required at initial installation, adding and deleting user accounts, and setting the time. 3.1 Overview of command input modes 3.2 Overview of initial installation operations 3.3 Login 3.4 Set a password for the device administrator 3.5 Add a user account and remove the "operator"...
Page 30: Overview Of Command Input Modes
Overview of command input modes The command input mode for the Switch command line interface (CLI) includes user mode, administrator mode, and configuration command mode. To set and change the configuration or check the status of the Switch, you must enter an appropriate command input mode, and then type a configuration command or operation command.
Page 31 ● Configuration command mode When you type the configure command in administrator mode, you switch to configuration command mode. By using configuration commands in configuration command mode, the configuration of the Switch can be set and changed. Each command input mode in which operation commands can be executed is described in the "Software Manual Operation Command Reference".
Page 32: Overview Of Initial Installation Operations
Overview of initial installation operations This section describes an overview of the operations required during initial installation. The details of each operation can be found in the following sections. (1) Login Log in to the Switch. Use the user ID "operator" provided during initial installation. (Since no password is set for "operator", you can log in without authentication.) (2) Set a password for administrator mode Set a password to be required when using the enable command to enter administrator mode.
Page 33: Login
Login This section describes an overview of the operations required during initial installation. The details of each operation can be found in the following sections. Users who have not set a password (initial users) will see the Password prompt. NOTE In addition, if you log in but have not created a password, you will see a banner asking you to create a password.
Page 34: Set A Password For The Device Administrator
Set a password for the device administrator Set a password for the device administrator. …Enter administrator mode. > enable …Enable password setting for administrator mode. # password enable-mode Changing local password for admin …Type a password for administrator mode. New password: ******** (The actual characters are not shown).
Page 35: Add A User Account And Remove The "Operator" User Account
Add a user account and remove the "operator" user account [Step 1] Create a user account and set a login password. Create a new user account and set a login password. The following example shows how to create the new user name "newuser" and set a login password.
Page 36: Set The Time
Set the time The following example shows the steps for setting the time to "August 6, 2021, 15:30" in Japan time. …Switch to configuration command mode. # configure …Set the time zone to JST and the offset from UTC to +9. (config)# clock timezone JST +9 …Save the time zone setting.
Page 37: Subsequent Operations
Subsequent operations This Chapter covers the Manuals used for reference in the Switch setup, checking operational status, and troubleshooting. 4.1 Operation management and configuration setting 4.2 Troubleshooting...
Page 38: Operation Management And Configuration Setting
Operation management and configuration setting For details on operation management and configuration setting, see the following manuals. ● Manuals to reference during operation management and configuration setting • Software Manual Configuration Guide Vol. 1 • Software Manual Configuration Guide Vol. 2 •...
Page 39: Troubleshooting
Troubleshooting For troubleshooting when any problem occurs, see the following manual. • Troubleshooting Guide...
