FortiSwitch-AX2340S
Hardware Instruction Manual
AX23S-H002X
Reading and storing this manual
・ Before you use the equipment, carefully read the manual and make sure that you understand all safety
precautions.
・ After reading the manual, keep it in a convenient place for easy reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FortiSwitch-AX2340S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fortinet FortiSwitch-AX2340S

Summary of Contents for Fortinet FortiSwitch-AX2340S

  • Page 1 FortiSwitch-AX2340S Hardware Instruction Manual AX23S-H002X Reading and storing this manual ・ Before you use the equipment, carefully read the manual and make sure that you understand all safety precautions. ・ After reading the manual, keep it in a convenient place for easy reference.
  • Page 2 ■ Relevant products This manual contains information on the FortiSwitch-AX2340S series. ■ Export restrictions When you export this product, please follow the necessary procedures after confirming the regulations of the Foreign Exchange and Foreign Trade Control Law and the export-related laws and regulations of foreign countries such as the U.S.
  • Page 3 Preface ■ About this manual This manual describes how to handle the hardware of Fortinet's FortiSwitch-AX2340S series, a layer 2 switch that supports Gigabit Ethernet. Before you operate the equipment, carefully read the manual and make sure that you understand all instructions and cautionary notes. After reading the manual, keep it in a convenient place for easy reference.
  • Page 4 ■ Reading sequence of the FortiSwitch-AX2340S series manuals Hardware Instruction Manual When you want to check the hardware equipment conditions When you want to know how to handle the hardware When you want to know the FortiSwitch-AX Transceiver Hardware Instruction Manual...
  • Page 5 ■ Abbreviations American Wire Gauge CVCF Constant Voltage Constant Frequency Electronic Industries Alliance International Organization for Standardization Japanese Industrial Standards Local Area Network Light Emitting Diode Memory Card Medium Dependent Interface MDI-X Medium Dependent Interface Crossover NEMA National Electrical Manufacturers Association Power over Ethernet RJ-45 Registered Jack 45...
  • Page 6 Safety and Regulatory Information / Informations sur la sécurité et la réglementation Regulatory Compliances / Conformités réglementaires Emissions / Émissions EN IEC 61000-3-2:2019/A1:2021 CNS15936,105 Class A AS/NZS CISPR 32:2015 Amd1:2020 VCCI-CISPR 32:2016 Class A Immunity / Immunité EN 55035:2017/A11:2020 IEC 61000-4-2/3/4/5/6/8/11 Safety / Sécurité...
  • Page 7 Warning Avertissement When selecting a fiber SFP/SFP+ device, Lors de la sélection d'un périphérique fibre considering safety, please make sure that it SFP/SFP+, compte tenu de la sécurité, can function at a temperature that is not less assurez-vous qu'il peut fonctionner à une than the recommended maximum operational température qui n'est pas inférieure à...
  • Page 8 Les spécifications minimales pour le cordon Canada flexible cord are: flexible sont : ● For FortiSwitch-AX2340S-48P4X ● Pour FortiSwitch-AX2340S-48P4X et FortiSwitch-AX2340S-16P8MP2X FortiSwitch-AX2340S-16P8MP2X - No. 14 AWG - pas plus de 4,5 mètres, Type - No. 14 AWG - not longer than 4.5...
  • Page 9 Denmark / The supply plug must comply with La fiche d'alimentation doit être conforme à la Danemark Section 107-2-D1, Standard section 107-2-D1, norme DK2-1a ou DK2-5a. DK2-1a or DK2-5a. Switzerland / The supply plug must comply with La fiche d'alimentation doit être conforme à Suisse SEV/ASE 1011.

  • Page 10: Safety Information

    Safety Information Safety precautions are indicated by the headings shown below. These headings show a combination of safety warning symbols with headings such as "Warning", "Caution", and "Notification". This is a safety alert symbol. It is used to bring attention to potential hazards that may cause personal injury.
  • Page 11 Safety Information (continued) Warning ■ If anything seems wrong, immediately turn off the power. If smoke or an unusual smell is emanating from the Switch, or if liquid is spilled into the Switch or a foreign object falls into the Switch, immediately disconnect all power cables from the outlet and turn off the power of the Switch.
  • Page 12 Safety Information (continued) Safety Information (continued) Warning ■ Use the Switch only with the indicated power supply. Do not use the Switch at any voltage other than the indicated voltage. Depending on the magnitude of the voltage, the internal components may be damaged, overheated, or deteriorated, resulting in a fire or electric shock.
  • Page 13 In addition, do not use our supplied power cable with equipment other than the Switch. Doing so could result in a fire or electric shock. It is extremely dangerous. ■ Do not remove the power supply of FortiSwitch-AX2340S-24P4X, FortiSwitch-AX2340S-48P4X, and FortiSwitch-AX2340S-16P8MP2X.
  • Page 14 Safety Information (continued) Caution ■ Keep the Switch out of reach of children. The Switch is not suitable for use where children may be present. ■ Do not install the Switch in a dusty or humid location. Do not install the Switch in a dusty or humid location. Doing so could result in a fire or electric shock.
  • Page 15 Safety Information (continued) Caution ■ Do not place the Switch vertically or lean it against the wall. Place the Switch horizontally when installing it on a table. The Switch may fall over if placed vertically or leaned against a wall, resulting in injury or failure. ■...
  • Page 16 Safety Information (continued) Caution ■ Do not touch the Switch during operation and just after operation stops. Depending on the temperature of the installation environment, the surfaces of the Switch and transceivers may become hot. Do not touch them during operation and just after power-off. Doing so could result in burns.
  • Page 17 Switch. Do not stack another device above and below the Switch to block the heat dissipation of the Switch. Doing so could result in a malfunction. Also, when mounting the Switch in a rack, leave a space of 1U or more between it and other equipment. ・ FortiSwitch-AX2340S-16T4X ・ FortiSwitch-AX2340S-24T4X ・ FortiSwitch-AX2340S-24TH4X ・ FortiSwitch-AX2340S-24PH4X ■...
  • Page 18 Safety Information (continued) Notification ■ Do not attach any labels to a transceiver. The label attached to the transceiver indicates that the transceiver is a standard product from manufacturer. However, such labels are attached where they do not interfere with heat dissipation from the transceiver or the mechanism that prevents the transceiver from coming loose from the cage.
  • Page 19 Safety Information (continued) Safety Information (continued) Safety Information (continued) Notification ■ Use care when handling an air duster. ● Use an air duster specially designed for cleaning optical connectors. Using another type of air duster could cause the ferrule tip to become dirty. ●...

  • Page 20: Warning Labels

    Safety Information (continued) Warning labels Warning labels are attached to the following locations on the Switch. Check what each warning label indicates before handling the Switch. Also, do not stain or remove the warning labels. Safety-15...

  • Page 21: Table Of Contents

    Table of Contents Preface Safety and Regulatory Information Safety-1 Safety Information Safety-5 Overview of the Switch Switch main body 1.1.1 FortiSwitch-AX2340S-16T4X 1.1.2 FortiSwitch-AX2340S-24T4X, FortiSwitch-AX2340S-24TH4X, and FortiSwitch-AX2340S-24PH4X 1.1.3 FortiSwitch-AX2340S-48T4X 1.1.4 FortiSwitch-AX2340S-24P4X 1.1.5 FortiSwitch-AX2340S-48P4X 1.1.6 FortiSwitch-AX2340S-16P8MP2X 1.1.7 Accessories Transceiver Direct attach cable...
  • Page 22 Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T 3.2.2 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (PoE) 3.2.3 Ethernet 100BASE-TX/1000BASE-T/2.5GBASE-T (PoE) 3.2.4 Ethernet 1000BASE-X 3.2.5 Ethernet 10GBASE-R Terminals and connection cables 3.3.1 When connecting an operation terminal to the Console port Installation of the Switch Necessary tools and equipment Read the following before you begin Installing the Switch 4.3.1...
  • Page 23 Appendix A Cleaning the optical connector Appendix B Physical specifications for the network Interface...

  • Page 24: Overview Of The Switch

    Overview of the Switch This chapter describes an overview of each device that comprises the Switch. 1.1 Switch main body 1.2 Transceiver 1.3 Direct attach cable...

  • Page 25: Switch Main Body

    Switch main body The FortiSwitch-AX2340S series is a layer 2 switch that supports Gigabit Ethernet and can be used as a distribution switch whose reliability and scalability are demanded and as a floor switch in a local area network. The FortiSwitch-AX2340S series has the following models.

  • Page 26: External View

    (1) External view Figure 1-1 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 16 ports (4) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-2 Rear view (1) AC connector (2) Cable clamp...

  • Page 27: Front Panel

    (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-2 LED indications and connectors". Figure 1-3 Front panel layout Port1 (1) (2) (3) Port20 NOTE Direct attach cables can be used only for Port 19 and Port 20. Table 1-2 LED indications and connectors Name...

  • Page 28: Rear Panel

    The layout of the rear panel is shown below. Figure 1-4 Rear panel layout 1.1.2 FortiSwitch-AX2340S-24T4X, FortiSwitch-AX2340S-24TH4X, and FortiSwitch-AX2340S-24PH4X FortiSwitch-AX2340S-24T4X, FortiSwitch-AX2340S-24TH4X, and FortiSwitch-AX2340S-24PH4X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 24 ports (PoE is supported for FortiSwitch-AX2340S-24PH4X.) • SFP slot (1000BASE-X): 2 slots •...
  • Page 29 Figure 1-6 Rear view (1) AC connector (2) Cable clamp (3) Ground terminal (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-3 LED indications and connectors". Figure 1-7 Front panel layout ) (2)

  • Page 30: Fortiswitch-Ax2340S-48T4X

    (3) Rear panel The layout of the rear panel is shown below. Figure 1-8 Rear panel layout 1.1.3 FortiSwitch-AX2340S-48T4X FortiSwitch-AX2340S-48T4X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 48 ports • SFP slot (1000BASE-X): 2 slots • SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots •...
  • Page 31 (1) External view Figure 1-9 Front view (1) Console port: 1 port (RJ-45) (2) Memory card slot: 1 slot (3) Ethernet 10BASE-T/100BASE-TX/1000BASE-T port: 48 ports (4) SFP slot: 2 slots (5) SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots Figure 1-10 Rear view (1) AC connector (2) Cable clamp...
  • Page 32 Figure 1-11 Front panel layout Port1 Port49 1) (2) (3) Port48 Port54 NOTE Direct attach cables can be used only for Port 53 and Port 54. Table 1-4 LED indications and connectors Name Type Status Description LED: Green Indicates the status of Green Available for operation or orange...

  • Page 33: Fortiswitch-Ax2340S-24P4X

    The layout of the rear panel is shown below. Figure 1-12 Rear panel layout FAN3(2) FAN3(1) 1.1.4 FortiSwitch-AX2340S-24P4X FortiSwitch-AX2340S-24P4X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port (PoE support): 24 ports • SFP slot (1000BASE-X): 2 slots • SFP+ slot (10GBASE-R or 1000BASE-X): 4 slots •...
  • Page 34 Figure 1-14 Rear view (1) AC connector (2) Cable clamp (3) Ground terminal (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-5 LED indications and connectors". Figure 1-15 Front panel layout (1) (2) (3)
  • Page 35 Name Type Status Description LED: Green Indicates whether the Green Software and device information are being or orange status of the Switch is in saved. (Do not remove the memory card.) MC operation mode Orange While software and device information were being saved, a failure was detected, and the saving operation has stopped.

  • Page 36: Fortiswitch-Ax2340S-48P4X

    DC OK and AC OK LEDs blink red after the Switch is powered off. This blinking NOTE does not indicate a failure. 1.1.5 FortiSwitch-AX2340S-48P4X FortiSwitch-AX2340S-48P4X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port (PoE support): 48 ports • SFP slot (1000BASE-X): 2 slots •...
  • Page 37 Figure 1-18 Rear view (1) AC connector (2) Cable clamp (3) Ground terminal (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-7 LED indications and connectors". Figure 1-19 Front panel layout Port1...
  • Page 38 Name Type Status Description LED: Green Indicates the status of Green Software and device information are being the Switch in MC or orange saved. (Do not remove the memory card.) operation mode Orange While software and device information were being saved, a failure was detected, and the saving operation has stopped.

  • Page 39: Fortiswitch-Ax2340S-16P8Mp2X

    DC OK and AC OK LEDs blink red after the Switch is powered off. This blinking NOTE does not indicate a failure. 1.1.6 FortiSwitch-AX2340S-16P8MP2X FortiSwitch-AX2340S-16P8MP2X has the following hardware specifications. • Ethernet 10BASE-T/100BASE-TX/1000BASE-T port (PoE support): 16 ports • Ethernet 100BASE-TX/1000BASE-T/2.5GBASE-T port (PoE support): 8 ports •...
  • Page 40 Figure 1-22 Rear view (1) AC connector (2) Cable clamp (3) Ground terminal (2) Front panel The layout of the front panel is shown below. The numbers in the figure correspond to those in "Table 1-9 LED indications and connectors". Figure 1-23 Front panel layout (7) (8)
  • Page 41 Name Type Status Description LED: Green Indicates whether the Green Software and device information are being status of the Switch is in or orange saved. (Do not remove the memory card.) MC operation mode Orange While software and device information were being saved, a failure was detected, and the saving operation has stopped.

  • Page 42: Accessories

    Table 1-10 LED indications Name Type Status Description Normal operating state DC OK LED: Green or Indicates the status of Green PS1 output. Failure detection Output is off. AC OK LED: Green or Indicates the status of Green Normal AC power input AC power input.

  • Page 43: Rubber Feet

    Figure 1-25 Rack mounting brackets ● For FortiSwitch-AX2340S switches ● For FortiSwitch-AX2340S-16T4X other than (4) Screws The screws are used to attach the rack mounting brackets to the Switch. Figure 1-26 Screws (5) Rubber feet The rubber feet are used when installing the Switch on a table.
  • Page 44 When using the Switch at AC power supply, use the power cable supplied or one that meets the specifications of your country. Using another cable could result in a Warning fire or electric shock. In addition, do not use our supplied power cable with equipment other than the Switch.

  • Page 45: Transceiver

    Transceiver For transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual" or "FortiSwitch AX2340S Series Datasheet".

  • Page 46: Direct Attach Cable

    Direct attach cable The direct attach cable is an interface cable with transceiver-shaped ends. For direct attach cable supported by the Switch, see "FortiSwitch AX2340S Series Datasheet". Do not attach any labels to connectors. Attaching a label to a location that interferes with heat dissipation or the Notification cable latch mechanism could cause a malfunction of the direct attach cable or cause damage to the Switch.

  • Page 47: Preparation For Installation

    Preparation for Installation This chapter describes the environmental conditions and preparation required to install the Switch. Before you begin preparation for Switch installation, carefully read this chapter and make sure that you understand all instructions and cautionary notes. 2.1 Installation conditions 2.2 Power facility 2.3 Consideration for electrical noise 2.4 Leakage current...

  • Page 48: Installation Conditions

    Installation conditions Installation conditions for the Switch are as follows. An installation environment must satisfy these conditions. Table 2-1 General installation conditions for the Switch (1/2) Model name Item FortiSwitch- FortiSwitch- FortiSwitch- FortiSwitch- AX2340S-16T4X AX2340S-24T4X AX2340S-24TH4X AX2340S-48T4X Dimensions (W x D x H) 250 x 205 x 44 440 x 350 x 44 mm Weight...
  • Page 49 Class 4 (30.0 W), the number of ports available for power supply in the entire Switch is as follows. Class 5 (45.0 W) and above is not supported. FortiSwitch-AX2340S-24P4X: Up to 17 ports FortiSwitch-AX2340S-48P4X: Up to 26 ports *5 If the power class of powered devices is Class 3 (15.4 W), the maximum number of ports available for...
  • Page 50 Therefore, the noise value changes. Reference value: If PoE power supply is not used and the Switch environment temperature is 86°F(30°C) • FortiSwitch-AX2340S-24P4X: 40 dB or less • FortiSwitch-AX2340S-48P4X: 50 dB or less • FortiSwitch-AX2340S-16P8MP2X: 52 dB or less *10 According to General Requirements for Measuring Methods for Suspended Particulate Matter Concentration in Air (JIS Z 8813).

  • Page 51: Power Facility

    Power facility 2.2.1 AC power facility (1) Outlet Use the OUTLET one that meets the specifications of your country. Installation and removal of the unit must be carried out by qualified personnel Warning only. Always use a grounded power outlet. Using the Switch without grounding could Warning result in an electric shock as well as failures due to electrical noise.
  • Page 52 Table 2-3 Inrush current Model Current Current Time (peak value) (peak value) for 100V AC for 200V AC FortiSwitch-AX2340S-16T4X 30 A 60 A No more than 10 ms FortiSwitch-AX2340S-24T4X 100 A 200 A FortiSwitch-AX2340S-24TH4X 100 A 200 A...

  • Page 53: Consideration For Electrical Noise

    Consideration for electrical noise Electrical noise generated by other equipment may cause a Switch failure. Please develop the power facility plan to observe the following points. ⚫ Do not connect a device (such as an air conditioner) whose power is repeatedly turned on and off by a relay, micro-switch, etc., to the branch circuit of the power supply used for the Switch.

  • Page 54: Leakage Current

    Leakage current The Switch is equipped with a noise filter to prevent failure caused by electrical noise. As a result, leakage current flows through the safety ground wire (class D grounding). A maximum leakage current of 1 mA flows per device, so if you are required to install an earth leakage breaker under the Fire Services Act and other laws, take this into consideration.

  • Page 55: Environmental Requirements

    Environmental requirements (1) Dust The Switch uses cooling fans, so do not install it in a humid or dusty place. The dust conditions for the Switch are as follows. ➢ Suspended particulate concentration: 0.15 mg/m or less (JIS Z 8813, General Requirements for Measuring Methods for Suspended Particulate Matter Concentration in Air) Do not install the Switch in a location near a printer or in a location with a lot of...
  • Page 56 In particular, optical fiber cables should be protected by metal covers, etc., with a bending radius of at least 100 mm in the major axis direction and at least 50 mm in the minor axis direction. In addition, the optical fiber cable that accommodates the required number of optical fiber cores must have a structure that can protect the cable itself from mechanical stress such as repeated bending, tensile tension, compression, and ironing during installation, and stress from the installation environment.

  • Page 57: Installation Location

    Switch to block the heat dissipation of the Switch. Doing so could result in a malfunction. Also, when mounting the Switch in a rack, leave a space of 1U or more Notification between it and other equipment. • FortiSwitch-AX2340S-16T4X • FortiSwitch-AX2340S-24T4X • FortiSwitch-AX2340S-24TH4X •...
  • Page 58 Switch to block the heat dissipation of the Switch. Doing so could result in a malfunction. Also, when mounting the Switch in a rack, leave a space of 1U or more Notification between it and other equipment. • FortiSwitch-AX2340S-16T4X • FortiSwitch-AX2340S-24T4X • FortiSwitch-AX2340S-24TH4X •...

  • Page 59: Maintenance Area

    Maintenance area Secure the following space as the maintenance area for the Switch. (1) Maintenance area for installation on a table Figure 2-1 Maintenance area for installation on a table Switch Front (Unit: mm) (2) Maintenance area for rack mounting Figure 2-2 Maintenance area for rack mounting 1000...

  • Page 60: Cooling Conditions

    Cooling conditions 2.8.1 Airflow The airflow of the Switch is as follows. (1) FortiSwitch-AX2340S-16T4X, FortiSwitch-AX2340S-24T4X, FortiSwitch-AX2340S-24TH4X, and FortiSwitch-AX2340S-24PH4X Figure 2-3 Airflow of FortiSwitch-AX2340S-16T4X, FortiSwitch-AX2340S-24T4X, FortiSwitch-AX2340S-24TH4X, and FortiSwitch-AX2340S-24PH4X Intake and exhaust Intake and exhaust Intake and exhaust Intake and exhaust (2) FortiSwitch-AX2340S-48T4X, FortiSwitch-AX2340S-24P4X,...

  • Page 61: Cooling Conditions

    2.8.2 Cooling conditions Secure a space of at least 50 mm from each side of the Switch to ensure air flow. Do not obstruct the ventilation slots of the Switch. Doing so causes heat to Caution accumulate inside the Switch, and could result in a fire. Maintain a space of at least 50 mm around the ventilation slots.

  • Page 62: Device Noise

    Device noise The models shown below have built-in cooling fan units that produce noise. Before installing the Switch, consider such noise to plan your layout. • FortiSwitch-AX2340S-48T4X • FortiSwitch-AX2340S-24P4X • FortiSwitch-AX2340S-48P4X • FortiSwitch-AX2340S-16P8MP2X For device noise, see "2.1 Installation conditions".

  • Page 63: Preparation Of Interface Cables And Terminal

    Preparation of Interface Cables and Terminal This chapter describes interface cables and terminal to be used with the Switch. 3.1 Interface cable list 3.2 Network interface specifications 3.3 Terminals and connection cables...

  • Page 64: Interface Cable List

    Interface cable list Interface cable connections with the Switch are listed below. The following cables must be prepared by the customer. For interface cables to be used for the transceiver, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". Table 3-1 Interface cables Port Transceiver Interface...

  • Page 65: Network Interface Specifications

    Network interface specifications 3.2.1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T (1) Mode setting for ports For Ethernet 10BASE-T/100BASE-TX/1000BASE-T ports, the mode can be specified from the following. When shipped from the factory, the Switch is set to auto-negotiation. ➢ Auto-negotiation (default) ➢ 100BASE-TX full duplex (fixed) ➢...

  • Page 66: Physical Specifications

    (4) Physical specifications Table 3-2 10BASE-T/100BASE-TX/1000BASE-T physical specifications Physical specifications Item 10BASE-T 100BASE-TX 1000BASE-T Category 3 and Category 5 and Enhanced higher higher UTP cable category 5 and higher Transmission 100m 100m 100m distance (maximum) Table 3-3 10BASE-T/100BASE-TX/1000BASE-T pin configuration RJ-45 Physical specifications Pin No.

  • Page 67: Ethernet 10Base-T/100Base-Tx/1000Base-T (Poe)

    (4) PoE power supply method FortiSwitch-AX2340S-24P4X, FortiSwitch-AX2340S-48P4X, FortiSwitch-AX2340S-24PH4X, and ports 1 to 16 of FortiSwitch-AX2340S-16P8MP2X support power supply to IEEE 802.3af and IEEE 802.3at compliant devices (powered devices). For PoE power supply pin assignment, the Alternative A method is adopted, which is a 2-pair power supply method specified by IEEE 802.3af and IEEE 802.3at.
  • Page 68 Table 3-4 Power supply pin assignment RJ45 pin number Pair Signal name Negative Vport Negative Vport Positive Vport Positive Vport (5) Physical specifications Table 3-5 10BASE-T/100BASE-TX/1000BASE-T physical specifications Physical specifications Item 10BASE-T 100BASE-TX 1000BASE-T Category 5 and Category 5 and Enhanced category UTP cable higher...

  • Page 69: Ethernet 100Base-Tx/1000Base-T/2.5Gbase-T (Poe)

    When using a fixed setting, the port type is identified as MDI-X. (4) PoE power supply method Ports 17 to 24 of the FortiSwitch-AX2340S-16P8MP2X support power supply to IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt compliant devices (powered devices). For PoE power supply pin assignment, the following methods are adopted: Alternative A which is a 2-pair power supply method specified by IEEE 802.3af/at, and Alternative A + Alternative B...
  • Page 70 Table 3-7 Power supply pin assignment (Alternative A method) RJ45 pin number Pair Signal name Negative Vport Negative Vport Positive Vport Positive Vport Table 3-8 Power supply pin assignment (Alternative A/B method) RJ45 pin number Pair Signal name Negative Vport (A) Negative Vport (A) Positive Vport (A) Positive Vport (B)

  • Page 71: Ethernet 1000Base-X

    Table 3-10 100BASE-TX/1000BASE-T/2.5GBASE-T pin configuration RJ-45 Physical specifications Pin No. 100BASE-TX 1000BASE-T 2.5GBASE-T Receive (+) Send/Receive A (+) Receive (–) Send/Receive A (–) Send (+) Send/Receive B (+) Not used Send/Receive C (+) Not used Send/Receive C (–) Send (–) Send/Receive B (–) Not used Send/Receive D (+)

  • Page 72: Ethernet 10Gbase-R

    3.2.5 Ethernet 10GBASE-R (1) Mode setting for ports The mode setting of Ethernet 10GBASE-R is available only in the full-duplex (fixed) setting. NOTE Auto-negotiation and half-duplex communication are not supported. (2) Flow control function This function is valid during full-duplex communication. (3) Physical specifications For the optical fiber cable used for each transceiver, see "FortiSwitch-AX Transceiver Hardware Instruction Manual".

  • Page 73: Terminals And Connection Cables

    Terminals and connection cables 3.3.1 When connecting an operation terminal to the Console port (1) Operation terminals When connecting an operation terminal to the Console port of the Switch, prepare a personal computer or workstation that supports the following functions. Table 3-11 Operation terminal Item Specifications...

  • Page 74: Installation Of The Switch

    Installation of the Switch This chapter describes how to install the Switch. 4.1 Necessary tools and equipment 4.2 Read the following before you begin 4.3 Installing the Switch 4.4 Connecting and disconnecting the power cable 4.5 Inserting and removing the memory card 4.6 Connecting and disconnecting the transceiver 4.7 Connecting an operation terminal 4.8 Connecting an interface cable...

  • Page 75: Necessary Tools And Equipment

    Necessary tools and equipment The following tools and equipment are required to install the Switch. #2 Phillips screwdriver: Used to attach rack mounting brackets to the Switch and to attach or remove the Switch to or from a rack using M5 screws. Also used to connect or disconnect the grounding cable.

  • Page 76: Read The Following Before You Begin

    Read the following before you begin Keep the Switch out of reach of children. The Switch is not suitable for use Caution where children may be present. Place the Switch horizontally when installing it on a table. The Switch may fall Caution over if placed vertically or leaned against a wall, resulting in injury or failure.

  • Page 77: Installing The Switch

    The Switch can be installed on a horizontal and stable flat surface. Follow the following steps to install the Switch. Figure 4-1 Ground the Switch (1) Grounding cable Table 4-1 Grounding wire specifications Model AWG No FortiSwitch-AX2340S-48P4X FortiSwitch-AX2340S-16P8MP2X FortiSwitch-AX2340S-24P4X Other models...

  • Page 78: Installing The Switch On A Table

    4.3.2 Installing the Switch on a table The Switch can be installed on a horizontal and stable flat surface. Follow the following steps to install the Switch. [Step 1] Place the Switch upside down on a flat surface. [Step 2] Attach the rubber feet (4 pieces) to the Switch.
  • Page 79 NOTE Use the supplied screws to attach the rack mounting brackets to the Switch. Figure 4-3 Attaching the rack mounting brackets (1) Rack mounting bracket (2) Screws (M4x6, 8 screws) When mounting the Switch in a rack, if it is not possible to secure a space (for pulling out cables) in front of the Switch, attach the rack mounting brackets to NOTE protrude 50 mm from the front side as shown in the figure below.
  • Page 80 [Step 2] Mount the Switch in a rack. When mounting the Switch onto a rack, two or more persons should perform the Caution task. Lifting the Switch by yourself may cause it to fall over, which could result in injury. When mounting the Switch in a rack, make sure that the Switch is stable.

  • Page 81: Connecting And Disconnecting The Power Cable

    (2) Cable clamp (3) AC connector For FortiSwitch-AX2340S-24P4X, FortiSwitch-AX2340S-48P4X, and FortiSwitch-AX2340S-16P8MP2X, connect the power cable to the Switch with the power supply installed. While the power cable is connected, power is Warning supplied to the power supply. Because of this, if you remove the power supply with the power cable connected, a fire or electric shock could result.
  • Page 82 1 Tighten 2 Push Notification Securely fix the power cable with the supplied cable clamp. The figure above is an example of FortiSwitch-AX2340S-24T4X. Follow the same NOTE steps for other models and power supply units. (2) How to disconnect the cable Remove the cable clamp and disconnect the power cable.

  • Page 83: Inserting And Removing The Memory Card

    Inserting and removing the memory card The memory card can be inserted and removed while the Switch is powered on. When moving the Switch, remove USB memory from the Switch. If the USB memory are subjected to excessive force while the Switch is being moved, Notification the USB memory, or the connector of the memory card slot may be damaged.

  • Page 84: How To Remove The Memory Card

    (2) How to remove the memory card After confirming that the memory card is no longer being accessed, slowly pull the memory card straight out. Figure 4-9 Removing the memory card (1) Memory card When the memory card is being accessed, do not remove the memory card or turn off the power.

  • Page 85: Connecting And Disconnecting The Transceiver

    Connecting and disconnecting the transceiver For information on connecting and disconnecting transceivers supported by the Switch, see "FortiSwitch-AX Transceiver Hardware Instruction Manual".

  • Page 86: Connecting An Operation Terminal

    Connecting an operation terminal An operation terminal is connected to the Console port of the Switch. To connect an operation terminal, use an RS-232C crossover cable (RJ-45 (male) - D-Sub 9-pin (female)). [Step 1] Insert the connector of an RS-232C cable into the Console port of the Switch until it clicks. Figure 4-10 Connecting an RS-232C cable (1) RS-232C cable...

  • Page 87: Connecting An Interface Cable

    Connecting an interface cable For information on connecting and disconnecting interface cables for NOTE transceivers, see "FortiSwitch-AX Transceiver Hardware Instruction Manual". (1) UTP cable UTP cables can be connected and disconnected while the Switch is powered on. Insert the connector until it clicks. Figure 4-12 Connecting a UTP cable (1) 10/100/1000BASE-T port...
  • Page 88 (2) Direct attach cable Direct attach cables can be connected and disconnected while the Switch is powered on. [How to connect the cable] Hold the root of the cable and insert the connector until it clicks. Figure 4-13 Connecting a direct attach cable (1) SFP+ slot (2) Connector (3) Cable root...
  • Page 89 [How to disconnect the cable] When removing the direct attach cable, push and hold the back shell of the direct attach cable horizontally toward the Switch (① in the figure below), and pull the pull tab slowly (② in the figure below).

  • Page 90: Turning The Power On And Off

    (2) Cable clamp (3) AC connector For FortiSwitch-AX2340S-24P4X, FortiSwitch-AX2340S-48P4X, and FortiSwitch-AX2340S-16P8MP2X, connect the power cable to the Switch with the power supply installed. While the power cable is connected, power is Warning supplied to the power supply. Because of this, if you remove the power supply with the power cable connected, a fire or electric shock could result.

  • Page 91: Turning The Power Off

    ". power cable For FortiSwitch-AX2340S-24P4X, FortiSwitch-AX2340S-48P4X, and FortiSwitch-AX2340S-16P8MP2X, connect the power cable to the Switch with the power supply installed. While the power cable is connected, power is Warning supplied to the power supply. Because of this, if you remove the power supply with the power cable connected, a fire or electric shock could result.

  • Page 92: Operations Required For Initial Installation

    Operations Required for Initial Installation This chapter describes how to set the administrator mode password, add and delete user accounts, and set the time, all of which are required for initial installation. 5.1 Points to be checked before initial installation 5.2 Operations Required for Initial Installation 5.3 Subsequent operations...

  • Page 93: Points To Be Checked Before Initial Installation

    Points to be checked before initial installation The following are the points that you must check before initial installation. (1) Confirm the progress until the device starts up The process from turning on the power to starting up the Switch is described below. ➢...

  • Page 94: Operations Required For Initial Installation

    Operations Required for Initial Installation The operations required for initial installation are described below. 5.2.1 Overview of command input modes The command input mode for the Switch command line interface (CLI) includes user mode, administrator mode, and configuration command mode. To set and change the configuration or check the status of the Switch, you must enter an appropriate command input mode, and then type a configuration command or operation command.

  • Page 95: Configuration Command Mode

    ● Configuration command mode When you type the configure command in administrator mode, you switch to configuration command mode. By using configuration commands in configuration command mode, the configuration of the Switch can be set and changed. Each command input mode in which operation commands can be executed is described in the "Software Manual Operation Command Reference".

  • Page 96: Login

    5.2.3 Login The "login" prompt appears when the Switch starts up. Enter your user ID after the "login" prompt to log in to the Switch. …Type the user name "operator". login: operator …Press the [Enter] key. Password: …A banner appears. No password is set.

  • Page 97: Add A User Account And Remove The "Operator" User Account

    5.2.5 Add a user account and remove the "operator" user account [Step 1] Create a user account and set a login password. Create a new user account and set a login password. The following example shows how to create the new user name "newuser" and set a login password.

  • Page 98: Set The Time

    5.2.6 Set the time The following example shows the steps for setting the time to "August 6, 2021, 15:30" in Japan time. …Switch to configuration command mode. # configure …Set the time zone to JST and the offset from UTC to +9. (config)# clock timezone JST +9 …Save the time zone setting.

  • Page 99: Subsequent Operations

    Subsequent operations (1) Operation management and configuration setting For details on operation management and configuration setting, see the following manuals. ● Manuals to reference during operation management and configuration setting • Software Manual Configuration Guide Vol. 1 • Software Manual Configuration Guide Vol. 2 ●...

  • Page 100: Appendix

    Appendix Appendix A Cleaning the optical connector Appendix B Physical specifications for the network Interface Appendix-1...

  • Page 101: Cleaning The Optical Connector

    Appendix A Cleaning the optical connector For information on cleaning optical connectors, see " Transceiver Hardware FortiSwitch-AX Instruction Manual". Appendix-2...
  • Page 102 Appendix B Physical specifications for the network Interface For physical specifications for the network interface of transceivers supported by the Switch, see " Transceiver Hardware Instruction Manual". FortiSwitch-AX Appendix-3...
