STM DOMIX 45 User Instruction Manual

Water doser mixer
Hide thumbs

Advertisement

Quick Links

Download this manual
HIGH TECHNOLOGY IN
BAKERY EQUIPMENTS
STM PRODUCTS S.r.l.
Via Schiaparelli, 15 - 37135 Verona - ITALY
Phone +39 045 585700 - FAX +39 045 585730
E-mail: info@stm-products.com
DOMIX 45
®
Water Doser Mixer
USER'S INSTRUCTION MANUAL
CODE 2600201 – Rev. 06 - 02.09.2014

Advertisement

loading
Need help?

Need help?

Do you have a question about the DOMIX 45 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STM DOMIX 45

Summary of Contents for STM DOMIX 45

  • Page 1 HIGH TECHNOLOGY IN BAKERY EQUIPMENTS STM PRODUCTS S.r.l. Via Schiaparelli, 15 - 37135 Verona - ITALY Phone +39 045 585700 - FAX +39 045 585730 E-mail: info@stm-products.com DOMIX 45 ® Water Doser Mixer USER’S INSTRUCTION MANUAL CODE 2600201 – Rev. 06 - 02.09.2014...
  • Page 3 Manual Code 2600201 Fig. 1 (Descrizione esterna della macchina; Machine overview) DOMIX45 – Rev.06 - 02.09.2014 3/44...
  • Page 4 Manual Code 2600201 Boiler Rete Rete Refrigeratore Cold water mains Cold water mains Refrigerator Réseau Réseau Réfrigérateur Kaltwasser-Anschluß Kaltwasser Wasserkühler Caldera Cañería del agua C. del agua fría Refrigerador Boiler Refrigeratore Refrigerator Réfrigérateur Wasserkühler Caldera Refrigerador Fig. 2 (Layout collegamenti idraulici; Layout hydraulic connections) DOMIX45 –...
  • Page 5 Manual Code 2600201 Fig. 3 (Schema Elettrico; Wiring Diagram) DOMIX45 – Rev.06 - 02.09.2014 5/44...

  • Page 7: Technical Features

    Manual Code 2600201 1- TECHNICAL FEATURES Power supply (see Machine tag) 208-240V AC or 110-127V AC Mains frequency 50/60 Hz Total absorbed power 25 VA Installation category Environmental conditions Indoor use only Temperature range 5 ÷ 50°C (40 ÷ 120°F) Relative humidity range 0 ÷...

  • Page 8: Preliminary Inspection

    Manual Code 2600201 2- MANUAL INTERPRETATION All parts of the text that are important to the safety of people and objects are written in bold. The purpose of this manual is to provide the user, the installer and the maintenance technician with all the technical information required for the installation, use and ordinary maintenance to guarantee a long Machine life.

  • Page 9: Manufacturer Declaration

    Manual Code 2600201 It is prohibited to open the Machine without having previously disconnected it from mains. It is prohibited to disperse and to leave the packaging to the reach of children. It can be potentially dangerous. 5- MANUFACTURER DECLARATION THE MANUFACTURER DECLINES ANY LIABILITY WHATEVER FROM ANY DAMAGE DERIVING FROM IMPROPER USE OF THE MACHINE AND/OR USE OF THE MACHINE IN ENVIRONMENTAL CONDITIONS THAT ARE NOT ADMITTED.

  • Page 10: Installation

    Manual Code 2600201 6- INSTALLATION Necessary operations relating to lifting, transportation, installation, start-up, maintenance and repair work must be carried out only by qualified personnel. Disconnect the electrical power supply when carrying out any of the above. 2 fuses, for pump and logic board, are fitted on the logic board and can be replaced when needed by qualified personnel only.
  • Page 11 Manual Code 2600201 NOTICE: in the case of water chiller equipped with a surge tank with pressure switch, this must be by-passed and the pump must be controlled directly by the Doser, through a power relay. The pump plug has the following wiring diagram (clean contact): Fig.

  • Page 12: Machine Functions

    Manual Code 2600201 MACHINE FUNCTIONS 7.1. START To power the Machine use the external switch ( or plug in the flying socket). ). The first messages that appear are related to the Machine self-diagnosis. Type of Machine and microprocessor software version are also displayed. At the end of the self-diagnosis the displays indicate respectively Quantity discharged before power off.

  • Page 13: Recipe Setting

    XX) or wait for 6 seconds: in all these cases the recipe is stored. ATTENTION: recipe temperature in the model Domix 45 has only the purpose of storage. It has no influence on the batch Temp and on the by-pass length which is to be regulated manually with the ball valve (14).
  • Page 14 Manual Code 2600201 8- ERRORS All errors messages are displayed through flashing abbreviations and an intermittent beep. Press [STOP / C] to stop the latter. Press [START] to delete the error message and to resume delivery. Press twice [STOP / C] to delete delivery. Here below are the possible error messages and their abbreviations .

  • Page 15: Maintenance Instructions

    Manual Code 2600201 8.4. Solenoid valve leaking L E A K E. V. DISPLAY 4 If the outlet solenoid valve does not shut perfectly leakages are detected and the user is alerted through the warning: "LEak E.V." The error is non-blocking. The user can continue to work.

  • Page 16: Device Disposal

    Manual Code 2600201 10- DEVICE DISPOSAL The used package may be disposed through regular disposal treatment centres. It is made only of non-polluting materials, recyclable as secondary prime materials. The Machine, accessories and batteries included, do not belong to the domestic disposal category, since they can be recycled and reused.

  • Page 17: Troubleshooting

    Manual Code 2600201 12- TROUBLESHOOTING PROBLEM CAUSE SOLUTION The Machine The power fuse in the logic Disconnect power and replace the doesn’t switch on board is burnt. fuse. “Err.L” message There is no water coming from Check the inlets. the chiller. RUN or BY-PASS obstructed.
  • Page 19 Manual Code 2600201 POS. Desc. Cod. 230V Cod. 115V Saracinesca a sfera fredda (nera, DX) Cold water ball gate valve (black, right) 3801217 Vanne à sphère froid (noir, droite) Saracinesca a sfera calda (rossa, SX) Hot water ball gate valve (red, left) 3801216 Vanne à...
  • Page 21 HIGH TECHNOLOGY IN BAKERY EQUIPMENTS STM PRODUCTS S.r.l. Via Morgagni, 14 - 37135 Verona - ITALY Phone +39 045 585700 - FAX +39 045 585730 E-mail: info@stm-products.com DOMIX 45-45A-45APSKit Technician manual CODE 2600203 – Rev. 00 - 22.12.2009...

  • Page 22: Table Of Contents

    Manual Code 2600203 INDICE PARAMETERS ACCESS ................3 1.1. ENTER PASSWORD ......................3 INSTALLER PARAMETERS ................3 2.1. FLOW-METERS CALIBRATION (FIRST STEP, INSTANTANEOUS ERROR)...3 2.2. FLOW-METERS CALIBRATION (SECOND STEP, SYSTEMATIC ERROR)....4 2.3. UNIT OF MEASURE......................4 2.4. MINIMUM SET TEMPERATURE ..................4 2.5. MAX SET TEMPERATURE ....................5 2.6.

  • Page 23: Parameters Access

    Manual Code 2600203 1 PARAMETERS ACCESS 1.1. ENTER PASSWORD Switch on the device, holding down simultaneously for 3 seconds the [1] and [9] keys to access various screens to modify installer parameters. To move from one screen to the next using the [P] key, you can not go back on previous screens or jump directly to the end.

  • Page 24: Flow-Meters Calibration (Second Step, Systematic Error)

    Manual Code 2600203 ATTENTION!! INPUT THE VALUE READ FROM THE SCALE NOT THE DEVIATION EXAMPLE: THE BALANCE SHOWS 1,07 kg, INPUT 1.07 NOT 0.07. The entered value can be deviated from that starting +/-50%. If there is an error higher necessary, replace the meter.

  • Page 25: Max Set Temperature

    Manual Code 2600203 2.5. MAX SET TEMPERATURE t E M P M A X 6 0. 0 DISPLAY 6 The allowed values are between 20 and 60 °C (default 60 °C) or between 68 and 140 °F (default 140 °F). 2.6.

  • Page 26: Delay Time Before Unreachable Temperature Alarm

    Manual Code 2600203 2.8. DELAY TIME BEFORE UNREACHABLE TEMPERATURE ALARM t E M P t o L DISPLAY 10 This screen appears only if the bypass was selected in “Control temperature” mode. It can be set from 10 to 120 seconds, with default of 20. 2.9.

  • Page 27: Probes Test

    Manual Code 2600203 2.1.2. PROBES TEST I n. P r. 2 5. 4 DISPLAY 14 When the display shows “In.Pr.” the temperature shown is the internal, while when the display shows “ES.Pr.” the temperature shown is the external. To switch from internal to external use the [1] and [2] keys. 2.1.3.

  • Page 28: Factory Settings

    A U t DISPLAY 18 “AUt” value the device is configurated as a Domix 45A “MAN” value the device is configurated as a Domix 45 To switch use the [1] and [2] keys. 3.2. FLOW METER CONSTANT I M P. L DISPLAY 19 Modify this value only if the flow-meter used is different from the original.

  • Page 29: Cubic Meters Totalizer

    Manual Code 2600203 3.4. CUBIC METERS TOTALIZER X X X X M 3 C DISPLAY 21 The upper display shows the total cubic meters discharged (or if the previous parameter is set to "no" only from the RUN). To reset the counter, press for 3 seconds [STOP]. 3.5.

  • Page 30: Valves Switch Delay (Only For Domix45A)

    Manual Code 2600203 3.8. VALVES SWITCH DELAY (ONLY FOR DOMIX45A) d E L S. V. 0. 2 DISPLAY 25 It indicates the delay between the BY-PASS valves closing and the RUN opening. Allowed value from 0.1 to 0.5 seconds (default 0.2). 3.9.

  • Page 31: Transmission Protocol

    Manual Code 2600203 3.10.1. TRANSMISSION PROTOCOL A S C II 4 8 5 DISPLAY 29 In this menu it is possible to set the transmission protocol (ASCII or RTU mode). The choice can be done by pressing [1] or [2] 3.10.2.

  • Page 32: Reset

    Manual Code 2600203 4 RESET To force a reset of the machine to factory settings at any state of operation for 5 seconds, press the keys [2] [6] [0] simultaneously (after three beep row, the system starts as the first switch on).

  • Page 33: Troubleshooting

    Manual Code 2600203 5 TROUBLESHOOTING PROBLEM CAUSE SOLUTION The unit doesn’t The power fuse in the logic Disconnect the power and replace switch on board is burnt. the fuse. “Err.L” message There is no water coming from Check the inlets. the chiller.
