Commissioning
5.9.6 Erasing Data
The memory module can be erased via setting
parameter 31-43 Erase_MM without a new power cycle.
1. Make sure that the memory module is mounted
in the frequency converter.
2. Select [1] Erase MM in parameter 31-43 Erase_MM.
3. All files in the memory module are erased.
4. Parameter 31-43 Erase_MM setting returns to [0]
No function.
5.9.7 Transfer Performance and Indications
The time for transferring different data between the
frequency converter and the memory module is different,
refer to Table 5.16.
Data file
•
It takes around 2 minutes for
uploading data from the frequency
converter to the memory module.
Firmware file
•
It takes around 6 minutes for
downloading data from the memory
module to the frequency converter.
SIVP file
1)
Parameter file
Table 5.16 Transfer Performance
1) If a parameter is changed in the frequency converter, to upload
the updated parameter, wait at least 5 s before power-down.
Data file
GLCP
Firmware "Synchronizing with
file Memory Module." is
shown during
SIVP file
transferring.
Parameter
No text indication.
file
Table 5.17 Transfer Indications
1) The On LED is on the LCP. Refer to chapter 5.3.1 Numeric Local
Control Panel (NLCP) and chapter 5.3.5 Graphic Local Control Panel
(GLCP) for the On LED's position and functions.
5.9.8 Activating the PROFIBUS Converter
®
VLT Memory Module MCM 103 acts as a combination of
both memory module and activation module to enable the
PROFIBUS converter function in the firmware. VLT
Memory Module MCM 103 contains a PBconver.MME file,
which is combined with the individual memory module
MG07A502
Operating Guide
Time
Around 10 s.
Around 5 s.
Indications
NLCP On LED 1)
The LED flashes
slowly during the
No text
transfer.
indication.
The LED does not
flash.
®
Danfoss A/S © 08/2018 All rights reserved.
serial number. PBconver.MME is the key for the PROFIBUS
converter function.
To activate the PROFIBUS converter, choose the version in
parameter 14-70 Compatibility Selections.
Parameter 14-70 Compatibility
Selections
*[0] No Function
[12] VLT2800 3M
[13] VLT2800 3M incl. MAV
[14] VLT2800 12M
[15] VLT2800 12M incl. MAV
Table 5.18 Description of parameter 14-70 Compatibility Selections
Activate the PROFIBUS converter via VLT
Module MCM 103
1. Plug the memory module in the frequency
converter.
2. Select [12] VLT 2800 3M or [14] VLT 2800 12M in
parameter 14-70 Compatibility Selections.
3. Make a power cycle to start the frequency
®
converter as VLT 2800 PROFIBUS identification
number and mode.
NOTICE
®
For VLT Memory Module MCM 103 to work as PROFIBUS
converter, the parameter 31-40 Memory Module Function
must not be set to [0] Disabled.
It is possible to activate the PROFIBUS converter without
®
the VLT Memory Module MCM 103 for a limited time.
Before this time elapses, plug in a VLT
MCM 103 to keep the PROFIBUS converter function.
Description
Selection of the compatibility
function is disabled.
Select the VLT2800 3M
compatibility mode for the
frequency converter.
Select the VLT2800 3M incl.
MAV compatibility mode for
the frequency converter.
Select the VLT2800 12M
compatibility mode for the
frequency converter.
Select the VLT2800 12M incl.
MAV compatibility mode for
the frequency converter.
®
Memory
®
Memory Module
