Panasonic EH-ND30 Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Hair Dryer
  5. EH-ND30
  6. Service manual
Panasonic EH-ND30 Service Manual

Panasonic EH-ND30 Service Manual

Household hair dryer
Hide thumbs Also See for EH-ND30:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

TABLE OF CONTENTS
1 Warning --------------------------------------------------------------------------
2 Specifications ---------------------------------------------------------------
3 Troubleshooting Guide ----------------------------------------------------------
4 Disassembly and Assembly Instructions ---------------------------
4.1. Disassembly instruction-------------------------------------------
4.2 Assembly Instructions----------------------------------------------
5 Wiring Connection Diagram----------------------------------------------
6 Schematic Diagram ------------------------------------------------------
7 Exploded View & Replacement Parts List -----------------------------
7.1. Exploded View for EH-ND30 -------------------------------------------
7.2. Parts List for EH-ND30 ------------------------------------------------------
Order Number PEWT1709A19CE
(Household) Hair Dryer
EH-ND30
Model No.
Asia
PAGE
2
2
3
4
4
5
6
7
8
8
9
© Panasonic Corporation 2014 Unauthorized copying
and distribution is a violation of law.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EH-ND30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic EH-ND30

Summary of Contents for Panasonic EH-ND30

  • Page 1 5 Wiring Connection Diagram---------------------------------------------- 6 Schematic Diagram ------------------------------------------------------ 7 Exploded View & Replacement Parts List ----------------------------- 7.1. Exploded View for EH-ND30 ------------------------------------------- 7.2. Parts List for EH-ND30 ------------------------------------------------------ © Panasonic Corporation 2014 Unauthorized copying and distribution is a violation of law.

  • Page 2: Specifications

    Air flow temperature ("III" Turbo) 90 K (in case of room temperature 30°C) Dimensions (W) 74 x (D) 172 x (H) 210 mm Cord length L = 1.7 m Weight Approx. 315 g (Without cord and Without Nozzle) Supplied accessory EH-ND30 Set nozzle...

  • Page 3: Troubleshooting Guide

    3 TROUBLESHOOTING GUIDE Refer to WIRING CONNECTION DIAGRAM. < TROUBLE > < REMEDY > < CHECK > Main body does <CHECK POWER CORD> Replace the not operate Check the conductivity of power cord. AIR FLOW ASSEMBLY Replace the <CHECK MAIN SWITCH> MAIN SWITCH Check the conductivity between the terminal 1 and 4 by setting the main switch...
  • Page 4 4. Disassembly and Assembly Instructions 4.1. Disassembly Instructions (1). Take off NOZZLE (4). Take off HANDLE AB then take out as same direction as below. CLICK RING and SWIVEL RING method as below. (2). Remove two TAPPING SCREWS at HOUSING A (5).
  • Page 5 4.2 Assembly Instructions (1). Install AIR FLOW ASSEMBLY (4). Insert an AIR OUTLET GRILL into HOUSING A as below drawing. into an AIR OUTLET RING by fix position as below. Small rib Large rib (2). Install HOUSING A method as below. (5).

  • Page 6: Wiring Connection Diagram

    5. Wiring Connection Diagram...

  • Page 7: Schematic Diagram

    6. Schematic Diagram Option for Code 605, 655 and 685 Main Sw. Off " " Cool " " Heat Protection " " Turbo " " Symbol Specification Part name Code : Code : 605/655/685 L/415/615/645/62B CAPACITOR 0.22 mF, 275V NOT USE CAPACITOR (FOR MOTOR) 0.1 mF, 50VDC D1, D2, D3, D4...

  • Page 8: Exploded View And Replacement Parts List

    7 EXPLODED VIEW & REPLACEMENT PARTS LIST 7.1. Exploded View for : EH-ND30 All parts are supplied from PMFTH-AP throught PLAP...
  • Page 9 7.2 Parts List for EH-ND30 Ref. Safety Part No. Part Name & Description Remarks Q'ty EHND30HSBW HOUSING AB BLACK,OTHERS EHND30HSPW HOUSING AB PINK,OTHERS EHND30HS41BW HOUSING AB BLACK,FOR -K415 : INDONESIA EHND30HS41PW HOUSING AB PINK,FOR -P415 : INDONESIA EHND30HS64BW HOUSING AB...
