4. Hardware Jumper Explanations
IMPORTANT - BEFORE MAKING ANY CHANGES IN THE HARDWARE
JUMPERS, DISCONNECT ELECTRICITY AT THE MAIN SWITCH.
4.1 The Hardware Jumpers are situated according to this drawing. (back of the thermostat)
Jumper 2
Jumper 4
B
Jumper short - when the black cover is placed on the 2 pins. (2 pins shorted)
Jumper open - when the 2 pins of the jumper are NOT SHORTED (2 pins open)
