Press SELECT button, the HEAT and the SET TEMPERATURE will flash. Set heating with (+) or (-) buttons. Press SELECT
button again or Press ON/SEND button to send information to the thermostat.
The HEAT SET must always be at least 1 degree less than the COOL SET. The controller will not let you enter a wrong setting.
(Set Temperature See # 6.5)
Real Time Clock and Day:
Press SELECT button: CLOCK SET will flash. Press (+) or (-) buttons, the hours will flash. Use the set button, press (+) to
increase and (-) to decrease the hours.
Press SELECT button again, the minutes will flash. Use the set button, press (+) to increase and (-) to decrease the minutes.
Press SELECT button again, the week day will flash. Adjust the day by pressing the set buttons (ie. if Saturday selected SAT will
show in display etc).
Press SELECT button again to exit from program or Press ON/SEND button to send information to the thermostat.
Programming:
To set the Program times and Temperature settings for the week:
The remote is 5-1-1 programmable; weekdays (Monday to Friday), Saturday, and Sunday can be programmed differently. There are
4 program events per day; 1 (Morning), 2 (Day), 3 (Evening), 4 (Night)
To enter programming: Press and hold SELECT button for three seconds.
PROGRAM (flashing) and the days Mon-Fri will appear on display.
Press (+) or (-) buttons, PROGRAM 1 & START (flashing) will appear in display.
Press SELECT button, the hours will flash. To change the hours press (+) to increase, (-) to decrease.
Press SELECT button, the minutes will flash. To change the minutes press (+) to increase, (-) to decrease.
Press SELECT button; Cool (flashing) &Temperature will appear on display, To change the Temperature, Press (+) to increase,
(-) to decrease.
Press SELECT button; Heat (flashing) &Temperature will appear on display, To change the Temperature Press (+) to increase, (-)
to decrease.
The controller keeps a safety differential of at least 1 degree between Heat set and Cool set (Heat is always less than Cool).
Note: After choosing the heat set, you cannot reduce the cool set to less than the heat set.
Press SELECT button: PROGRAM 2 & START (flashing) will appear in display.
Press (+) or (-) buttons and adjust the hours, minutes and temperature the same way as in PROGRAM 1
Press SELECT button: PROGRAM 3 & START (flashing) will appear in display.
Press (+) or (-) buttons and adjust the hours, minutes and temperature the same way as in PROGRAM 1
Press SELECT button: PROGRAM 4 & START (flashing) will appear in display.
Press (+) or (-) buttons and adjust the hours, minutes and temperature the same way as in PROGRAM 1
SEND will blink, press ON/SEND button to send the information to the thermostat.
PROGRAM (flashing) and SA (Saturday) will appear in display
Adjust the programming for Saturday the same way as programming MON to FRI.
SEND will blink, press ON/SEND button to send the information to the thermostat.
PROGRAM (flashing) and SU (Sunday) will appear in display
Adjust the programming for Sunday the same way as programming MON to FRI.
SEND will blink; press ON/SEND button to send the information to the thermostat.
