GRIND Press and hold the push-button for grinding mode (Fig. C) for 2 seconds to
activate grinding mode. The LED (Fig. B-2) flashes green every 3 seconds.
Press and hold the push-button for grinding mode for 1 second to deactivate
grinding mode.
DARK Press the "HIGH" push-button (Fig. B-6) to set the filter to level 10.
DUAL-COLOR To view the active colour settings, briefly press the "
The currently active setting will flash. If you want to change the set- The currently active setting will flash. If you want to change the set-
tings, press the "
LED to the other colour (Fig. B-8).
3.4 Helmet settings
1. Setting the headband to the proper fit
• To ensure the headband fits properly, push the small button out of the currently selected
slot, then slide it into the desired slot until the small button snaps into place (Fig. D-1).
• Adjust the headband to your head circumference by turning the adjustment dial (Fig. D-2).
• Once you have put on the helmet, move your head around to make sure the helmet fits
securely and firmly.
2. Setting the distance between the filter and your face
• Press down the "LOCK" catches on both sides and hold them firmly in place (Fig. D-3).
D-3). So kann das Kopfband vor- und zurückgeschoben werden. This allows you to push
the headband back and forth.
• Release the "LOCK" catches so that the pins can lock into the slots. Ensure that both
eyes are the same distance from the lens.
3. Setting the viewing angle
• Loosen the right block nut.
• Adjust the viewing angle using the pins on the angle limiting lens.
• Snap the pin into the desired slot on the right-hand screw (Fig. D-4).
• Retighten the right block nut.
" push-button repeatedly to switch the flashing
" push-button.
