6. CLEANING AND STORAGE
6.1 Cleaning
• Clean the welding helmet with mild soap and lukewarm water.
• Use a mild disinfectant solution to disinfect the face mask. Do not use solvents under
any circumstances.
• Clean the auto darkening filter with a clean, lint-free cloth.
• Do not immerse the auto darkening filter in water or spray it directly with liquids.
6.2 Storage
Store the welding protection visor fully assembled in a dry and clean place. Protect it
from direct sunlight and heat radiation. Remove the batteries if you intend to store it
for a longer period.
7. SPECIFICATIONS
Model
Visible area
Filter size
Optical class
Number of sensors
Switch on/off
Battery type
Dark protection levels
Light state
Switching speed
Special modes
Sensitivity control
Delay
UV/IR protection
Operating temp.
Storage temp.
Helmet material
Approvals
Powershield Guardian Eclipse
107 x 75 mm (4.21 x 2.95")
156 x 123 x 33 mm (6.14 x 4.84 x 1.30")
1 / 1 / 1 / 2
4 + 2 automatic
Automatic on/off
Solar cell. Replaceable battery, 2 x CR2450 lithium batteries
5–9/9–13
Protection level 3
1/25,000 s (55 °C)
SMART/GRIND/CUT/MIX/DARK
Low–High, LED and push-button control
0.04-1.0 s, 11-level digital display control
Up to DIN16 protection level at all times
-10 °C to 55 °C (14 °F to 131 °F)
-20 °C to 70 °C (-4 °F to 158 °F)
Impact-resistant nylon
CE, ANSI, CSA, AS/NZS, EAC
