EUROCHEF - PRO WALL HOOD
HOODS
24" range hood with 600 CFM blower
30" range hood with 600 CFM blower
36" range hood with 600 CFM blower
48" range hood with 1200 CFM blower
ACCESSORIES
WARMING LAMP KIT
Includes 175W Warming Lamps, rocker switches, quick connect wiring. Field installable.
BACKSPLASH WITH WARMING SHELVES KIT
Includes telescoping 2-piece backsplash, removable & dishwasher safe shelves
RECIRCULATING KIT
Includes 4" high duct cover, 90 degree transition, charcoal filters
NOTE: Do not use with indoor BBQ. Do not use with Blower Upgrade Kit (below).
REPLACEMENT CHARCOAL FILTER
For use with Recirculating Kit Only
BLOWER UPGRADE KIT
Kit for 30" and 36" hoods only. Includes 600 CFM blower.
Not for use with Recirculating Kit or horizontal ducting
DUCT COVER 6"
Stackable 304 stainless steel.
DUCT COVER 12"
Stackable 304 stainless steel.
2
WEIGHT MODEL NUMBER
22 lbs EC PH24S
30 lbs EC PH30S
36 lbs EC PH36S
48 lbs EC PH48S
24"/30" Warming Lamps Kit: (1) 175W Warming Lamp
36" Warming Lamps Kit: (2) 175W Warming Lamp
48" Warming Lamps Kit: (2) 175W Warming Lamp
24" Backsplash with (1) shelf
30" Backsplash with (1) shelf
36" Backsplash with (2) shelf
48" Backsplash with (2) shelf
24" Recirculating Kit
30" Recirculating Kit
36" Recirculating Kit
Not Available for 48" Hoods
Includes 2 Sets of Filters
24" wide 6" high duct cover
30" wide 6" high duct cover
36" wide 6" high duct cover
48" wide 6" high duct cover
24" wide 12" high duct cover
30" wide 12" high duct cover
36" wide 12" high duct cover
48" wide 12" high duct cover
FEATURES
Controls: 4-speed electronic with 15" minute delayed shutoff
timer
Fabrication: Welded, polished and brushed seams
All edges hemmed
Features: 304 stainless hood baffle filter and grease tray
12V halogen lighting, lamps included
Top and Back ducting 24", 30", 36" hoods
Transition to 8" round with damper included
Install to wall or cabinets
MODEL NUMBER
EC LAMP24/30
EC LAMP36
EC LAMP48
EC BKSPL24
EC BKSPL30
EC BKSPL36
EC BKSPL48
EC DLK24
EC DLK30
EC DLK36
EC FILT
EC BLMT
EC CVR246W
EC CVR306W
EC CVR366W
EC CVR486W
EC CVR2412W
EC CVR3012W
EC CVR3612W
EC CVR4812W
Air-2
