Flowzone ZEPHYR FZSATJ-3 Operation Manual page 9

ZEPHYR
OPERATION GUIDE
FZSATJ-3
1 FZRARV Tank Lid with Wand Holster
FZRABW
Tank Strainer
2
3 FZRAMZ 4-Gallon Tank
4 FZRANL Upper Wand Holster
FZRANK
5 Lower Wand Holster
Pump
6 FZRATL
FZRAOG Pump Outlet Hose & Nut
7
FZRAGK Pump Inlet Filter
8
FlowZone Battery Adapter
9 FZAATA
FZRAEG Battery Door Assembly
10
FZAAEN 18V/2.6Ah Battery
11
FZAAEL 21V/1A Charger
12
45° Fan Tip w/ 45° Base Assembly
13
14 Adjustable Cone w/ 45° Base Assembly
FZRASV
0° Pin Stream Nozzle Tip
15
16 80° Fan Nozzle Tip
FZRAQX-V1 Inline Spray Handle
17
18 FZRADK 18-in. Carbon Fiber Wand
19 FZRAOF 5-ft. UV-Resistant Hose
20 FZRATK Backpack Straps
21 FZRATM Front Cover Plate
12
13
18
14
19
15
10
16
9
6
21
8
7
- 9 -
11
1
17
4
2
5
3
© WESSOL, LLC
20
