ZEPHYR
OPERATION GUIDE
FZSATJ-3
3
Determine the nozzle you
would like to use and place
it onto the carbon fiber
wand. Bring the turqouise
o-ring to sit flush with the
nozzle base. Once in place,
bring the cap to the nozzle
base and thread it to secure
the nozzle. General flow
rates for each nozzle can be
found on page 14.
4
Turn the pump on by
rotating the variable-
pressure dial clockwise
to the desired position.
Reference flow rate and
spraying pressure chart on
Page 14.
5
To begin spraying, simply
hold down the trigger on the
spray gun.
Priming your sprayer
NOTE: Although rare, when spraying for the first time or after storing
the sprayer for an extended amount of time, the sprayer may need help
priming. If the sprayer turns on and you can hear the pump running, but
no liquid is passing through the sprayer, you will need to manually prime
the sprayer according to the steps below:
1. With the sprayer off, install the battery and make sure
the battery cover is shut.
2. Remove the tank lid and take the tank strainer out to
reveal the inside of your sprayer tank.
3. Locate the inlet filter at the bottom of the sprayer tank
(See diagram 3 on page 18 for a visual representation).
Gently wiggle the white circular piece until it comes
apart from the inlet tube. Set aside.
4. Using a garden hose or similar delivery method,
rapidly run clean water into the inlet tube where the
mesh filter was. Turn your sprayer on at full power
(speed 5). Squeeze the trigger until water comes out.
5. Reinstall the inlet filter with the mesh screen facing
the bottom of the tank.
- 13 -
Scan for video instructions or visit
h t t p s : / /f z s p ra y.c o m /p a g e s /
troubleshoot#priming-sprayer
