ZEPHYR
OPERATION GUIDE
FZSATJ-3
GETTING
STARTED
Setting up your
sprayer
NOTE: The sprayer may
have residual water in it
when first opened. This is
due to quality testing every
sprayer undergoes before
leaving our factory.
1
Take off the tank lid (1).
Remove the nuts and bolts
(6), and holsters (4, 5) from
the tank strainer (3). Remove
the nozzles (13, 14, 15, 16)
from the battery holster.
Set aside.
3
A
Next, slide the adjustable strap through the top tank loop.
Continue by sliding the strap under and over the buckle
fitting. Lightly tug to make sure the strap is secure. Repeat on
other side.
- 10 -
2
Lay the sprayer flat. Bring the backpack
straps (11) to the bottom of the tank and
insert through designated opening. Once
inserted, tilt the buckle upward, insert
on the underside of the buckle & pull
through. Next, insert through the top side
of the buckle and pull through.
B C
