Summary of Contents for Flowzone Monsoon 2V
- Page 1 ® OPERATION GUIDE Monsoon 2V ™ FZVABN-2...
- Page 2 Never fill the sprayer with hot liquids (max temp. = 176ºF) or • Do not try to make any modifications to the sprayer. Always gasoline. use FlowZone® branded replacement parts from the • The sprayer is susceptible to water damage if left in wet manufacturer.
- Page 3 Do not dispose of lithium-ion battery with household waste; recycle where facilities exist. The sprayer is susceptible to water damage if left in wet conditions. Always store it in a cool, dry place. Always use FlowZone® original replacement parts. Copyright © WESSOL, LLC...
- Page 4 REGISTER YOUR SPRAYER! To take advantage of the 1-year Limited Warranty from WESSOL, LLC. Register your sprayer at the website below: www.fzspray.com/register LET’S Please read and follow this manual carefully to ensure that you get the most out of your new sprayer. If you need assistance with the assembly or operation of your sprayer, please don’t hesitate to contact WESSOL via the support methods below: www.fzspray.com...
- Page 5 TABLE OF CONTENTS page 6-7 ABOUT 1.1 specifications...................page 6 what’s in the box..................page 7 page 8-10 SET UP sprayer assembly..................page 8 spraying....................page 9 aftercare....................page 10 page 11-15 TROUBLESHOOT common solutions..................page 11 replacement parts..................page 12 warranty....................page 14 Copyright © WESSOL, LLC...
- Page 6 3 hours and PRODUCT COULD RESULT IN INJURY. spray more than 76 gallons per battery charge at a distance of 30 feet. FlowZone® Monsoon 2V™ Specifications Model Number FZVABN-2 Pump Type Heavy-Duty Diaphragm Pump...
-
Page 7: What's In The Box
1. 9-GALLON TANK 2. TANK LID 3. INTAKE FILTER WHAT’S IN 4. TOP & BOTTOM HOLSTER / BOLTS 5. STAINLESS-STEEL SPRAY WAND THE BOX? 6. 18V/5.2Ah LITHIUM-ION BATTERY 7. 21V/2.5Ah BATTERY CHARGER 8. 20-FOOT VINYL HOSE 9. SPRAY GUN 10. ADJUSTABLE SPRAY NOZZLE 11. 0º JET NOZZLE 12. 25º FAN NOZZLE 13. ROLLER HANDLE 14. HOSE HOLSTER 15. WHEELS AND PINS Copyright © WESSOL, LLC... - Page 8 STEP 1. ASSEMBLING SPRAYER Required tools: Phillips head screwdriver Before you begin, open the tank lid and remove the nuts and bolts, holsters, and nozzles from inside the intake filter. Set aside. Insert roller handle (13) into the tank (1), and tighten Take the spray gun (9) and twist on to the threaded the black nuts until the handle is tightly secured.
-
Page 9: Preparing To Spray
STEP 2. PREPARING TO SPRAY Fully charge the battery before the first operation. Indicator lights will flash as the battery is charging. In a separate container, prepare the solution you Turn the pump on by rotating the power switch on want to spray according to the manufacturer’... - Page 10 STEP 3. AFTER YOU FINISH SPRAYING Dispose of extra product based on manufacturer’ s Store the sprayer in a clean, cool, shaded location instructions. Rinse out any residual solution in the to protect it from extreme heat or frost. spray tank with warm, soapy water. Then spray fresh water through the sprayer for 3 to 5 minutes to completely clear the tank of chemicals.
-
Page 11: Troubleshooting Your Sprayer
TROUBLESHOOTING YOUR SPRAYER Visit fzspray.com/troubleshoot for detailed troubleshooting instructions and videos. To contact Technical Support, message support@wessol.com or call 1 (803) 339-2500. PROBLEM POSSIBLE REASON(S) SOLUTION Dead battery Charge the battery. If the battery will not charge, test the charger or call Support at (803) 339-2500 for a replacement if applicable. - Page 12 ACCESSORY & REPLACEMENT PARTS FZAAGD FZRABW ComfortStraps™ Intake filter FZAAEM 18V/5.2A battery pack FZRABN FZRAEJ Quick-connect Top wand holster spray gun FZAAAV FZRAAS FZRAFJ 20’ tank-to-gun Stainless steel High/Variable-Pressure connection hose high-pressure wand Pump Circuit Board FZAAAQ FZAAEK FZAAEL Quick-connect Bottom wand holster 21V/3A quick-charger 25º...
-
Page 13: Accessory & Replacement Parts
ACCESSORY & REPLACEMENT PARTS FZRADJ FZRAFF Trolley wheels High/Variable-Pressure Pump Assembly FZRACK FZRADX FZRACM Viton™ tank lid gasket Gran angular nozzle Pump inlet filter FZRAFF FZAACL FZAAFM High/Variable-Pressure Viton™ pump inlet gasket Dual head fan nozzle Pump FZRAFP FZRAEA FZRAEG Viton™... - Page 14 LIMITED WARRANTY WARRANTY COVERAGE WESSOL, LLC warrants to the original purchaser that the FlowZone® product will function as intended under normal use and consistent maintenance, subject to certain limitations and exclusions. At the discretion of WESSOL, LLC, we will repair or replace any parts found to be defective in material or workmanship without charge, apart from shipping and handling costs, during the covered warranty period.
- Page 15 EXCLUSIONS AND LIMITATIONS WESSOL, LLC only warrants products purchased from authorized distributors. Products purchased from unauthorized resellers or distributors are not subject to warranty services. The limited warranty does not cover damages, loss, or injury resulting from transportation, storage, accident, improper use, neglect, modifications, normal wear, or operation not in accordance with the instruction manual.
- Page 16 fzspray.com +1 (803) 339-2500 spraysquad@fzspray.com © WESSOL, LLC...
