- Page 1 OWNER’S MANUAL RENEW PAW’SDON ME LITTER BOX ENCLOSURE - WHITE MODEL # RDALWH-3403 IMPORTANT FOR 3D ASSEMBLY INSTRUCTIONS/ DOWNLOAD THE FREE APP Intelligent Instructions...
-
Page 2: Parts List
PARTS LIST Your RENEW Paw’don Me Litter Box Enclosure should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact RENEW Customer Service: 800.985.5506 or customerservice@renewbytrinity.com. - Page 3 ASSEMBLY INSTRUCTIONS STEP 1 Lay TOP (A) on a clean surface with screw holes facing up. Orient BACK FRAME (F) with feet facing up. Insert (2) DOWELS (N) into holes on BACK FRAME (F), connecting BACK FRAME (F) and TOP (A) as shown.
- Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Insert LONG SCREWS (J) through WASHERS (L) and RIGHT SIDE FRAME (C) and hand tighten onto TOP (A). Insert SHORT SCREWS (I) through WASHERS (L) and RIGHT SIDE FRAME (C) and hand tighten onto BACK FRAME (F). Only hand tighten STEP 4 Repeat STEP 2 and STEP 3 for LEFT SIDE FRAME (B).
- Page 5 ASSEMBLY INSTRUCTIONS STEP 5 Screw SMALL SCREW (K) through DRAWER STOPPER (M) into screw hole on FRONT FRAME (D) as shown, tighten with a screwdriver. STEP 6 Orient FRONT FRAME (D) with feet facing up and grooves facing inward. Insert DOWELS (N) into holes on FRONT FRAME inside (D).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 7 Insert SHORT SCREWS (I) through WASHERS (L) and LEFT SIDE FRAME (B) and fully fasten with a Phillips screwdriver onto FRONT FRAME (D). Repeat for RIGHT SIDE FRAME (C). Fully tighten all SCREWS from STEP 3 & STEP 4 with a Phillips screwdriver.
- Page 7 ASSEMBLY INSTRUCTIONS STEP 9 Users can choose to assemble FRONT DOOR (E) on left-hand side or right-hand side. Place FRONT DOOR (E) close to FRONT FRAME (D). Insert SMALL SCREWS (K) through hinge screw holes on FRONT DOOR (E), fully fasten with a Phillips screwdriver onto FRONT FRAME (D) as shown.
- Page 8 SERVICE PARTS LIST – RDALWH-3403 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description LWH-16-009-1620 Bottom Frame LNA-06-023-2024 Right Side Frame Left Side Frame LWH-14-049-2124 LWH-14-050-2124 Front Frame Short Screw LWH-15-021-1924 ZSV-01-004-0635 Small Screw Washer ZSV-01-007-0616 ZSV-01-047-0410 Drawer...
-
Page 9: Care And Maintenance
WARNING 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner. -
Page 10: Year Limited Warranty
1 YEAR LIMITED WARRANTY RENEW Paw’don Me Litter Box Enclosure Model # RDALWH-3403 Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the RENEW Paw’don Me Litter Box Enclosure (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. -
Page 11: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a RENEW product! In order to register your product and receive streamlined customer service, please fill out the Product Registration Form online at renewbytrinity.com/product-registration ABOUT RENEW RENEW is a planet-first housewares brand looking to set new standards for sustainability and is 100% committed to the creative reuse of single-use materials as the best way to conserve natural resources.
