Appendix C: System Specifi cations
Appendix C
System Specifi cations
Processors
Single or dual Intel® Xeon® 5400/5300/5200/5100 Sequence processors at
a front side (system) bus speed of 1333/1066 MHz.
Note: Please refer to our web site for a complete listing of supported processors.
Chipset
Intel 5100/ICH9R chipset
BIOS
8 Mb Phoenix® Flash ROM
Memory Capacity
Six 240-pin DIMM sockets supporting up to 32 GB of registered ECC DDR2-
667/533 SDRAM.
See the memory section in Chapter 5 for details.
SATA Controller
Intel ICH9R on-chip controller for six-port Serial ATA (RAID 0, 1 5 and 10
supported)
Peripheral Drive Bays
Eight 2.5" drive bays
Expansion Slots
(see page 5-9 for details)
Right side: one low-profi le PCI-E x8 card
Left side: one PCI-E x8 card and one UIO card
Serverboard
X7DCU (Proprietary form factor)
Dimensions: 8 x 13 in (203 x 330 mm)
C-1
