  • Page 1 ® UPER 1025C-UR UPER ERVER USER’S MANUAL...
  • Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. SUPER MICRO COMPUTER reserves the right to make changes to the product described in this manual at any time and without notice.

  • Page 3: About This Manual

    Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 1025C-UR. In- stallation and maintenance should be performed by experienced technicians only. Manual Organization Chapter 1: Introduction The fi...
  • Page 4 UPER ERVER 1025C-UR Manual Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X7DCU serverboard, including the locations and functions of connectors, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi guring the serverboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 1025C-UR Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 UIO ........................1-2 Serial ATA ....................... 1-2 Onboard Controllers/Ports ................1-2 Other Features ....................1-3 Server Chassis Features ................1-4 System Power ....................
  • Page 7 Table of Contents Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 UID ........................3-1 Control Panel LEDs ..................3-2 Universal Information LED ................3-2 NIC2 ........................ 3-3 NIC1 ........................ 3-3 HDD .........................
  • Page 8 UPER ERVER 1025C-UR Manual Supero Doctor III ................... 5-25 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices .................. 6-1 Precautions ..................... 6-1 Control Panel ....................6-2 System Cooling ....................6-2 System Fan Failure ..................6-3 Drive Bay Installation/Removal ............... 6-4 Accessing the Drive Bays ................6-4 Hard Drive Installation ..................

  • Page 9: Chapter 1 Introduction

    Overview Supermicro's SuperServer 1025C-UR is a dual processor, 1U rackmount server. The 1025C-UR is comprised of two main subsystems: the SC113TQ-R650 1U rackmount chassis and the X7DCU dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the 1025C-UR.

  • Page 10: Serverboard Features

    UIO card types to add SAS ports, additional LAN ports, etc. to the serverboard. This allows the user to tailor the serverboard to their own needs. Note: the 1025C-UR does not come with a UIO card installed.

  • Page 11: Other Features

    Chapter 1: Introduction ATI Graphics Controller The X7DCU features an integrated ATI video controller based on the ES1000 graph- ics chip. The ES1000 was designed specifi cally for servers, featuring low power consumption, high reliability and superior longevity. Other Features Other onboard features that promote system health include onboard voltage moni- tors, a chassis intrusion header, auto-switching voltage regulators, chassis and CPU overheat sensors, virus protection and BIOS rescue.

  • Page 12: Server Chassis Features

    2.5" hard drive bays and a high-effi ciency power supply. The following is a general outline of the main features of the SC113TQ-R650 chassis. System Power When confi gured as a SuperServer 1025C-UR, the SC113TQ-R650 chassis in- cludes a redundant 650W power supply. Control Panel The SC113TQ-R650 control panel provides important system monitoring and control information.

  • Page 13: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer, B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 14 UPER ERVER 1025C-UR Manual Notes...

  • Page 15: Chapter 2 Server Installation

    This quick setup assumes that your SuperServer 1025C-UR system has come to you with the proces- sors and memory preinstalled. If your system is not already fully integrated with a serverboard, processors, system memory etc., please turn to the chapter or section...

  • Page 16: Rack Precautions

    UPER ERVER 1025C-UR Manual installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units.

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    This section provides information on installing the SuperServer 1025C-UR into a rack. If the 1025C-UR has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. Note: This rail will fi t a rack between 26" and 33.5" deep.

  • Page 19: Inner Rails

    Chapter 2: Server Installation Inner Rails The SC113 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack. Attach the inner rail extension to stabilize the chassis within the rack.

  • Page 20: Outer Rails

    UPER ERVER 1025C-UR Manual Outer Rails Installing the Outer Rails to the Rack (Figures 2-3 and 2-4) Attach the short bracket to the outside of the long bracket. You must align the pins with the slides. Also, both bracket ends must face the same direction.
  • Page 21 Chapter 2: Server Installation Figure 2-4. Installing the Outer Rails to the Rack...
  • Page 22 UPER ERVER 1025C-UR Manual Installing the Chassis into a Rack (Figure 2-5) Confi rm that chassis includes the inner rails and rail extensions . Also, confi rm that the outer rails are installed on the rack. Line chassis rails with the front of the rack rails.

  • Page 23: Installing The Server Into A Telco Rack

    Chapter 2: Server Installation Installing the Server into a Telco Rack To install the SuperServer 1025C-UR into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back.

  • Page 24: Checking The Serverboard Setup

    UPER ERVER 1025C-UR Manual Checking the Serverboard Setup After you install the 1025C-UR in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Removing the Chassis Cover (Figure 2-5) Grasp the two handles on either side and pull the unit straight out until it locks (you will hear a "click").

  • Page 25: Checking The Drive Bay Setup

    Chapter 2: Server Installation Your 1025C-UR server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots. For details on adding system memory, refer to Chapter 5. If desired, you can install add-on cards to the system. See Chapter 5 for details on installing PCI add-on cards.
  • Page 26 UPER ERVER 1025C-UR Manual Notes 2-12...

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel to keep you constantly informed of the overall status of the system as well as the three buttons described below. Control Panel Buttons There are three buttons located on the front of the chassis: a reset button, a power on/off button and a UID button.

  • Page 28: Control Panel Leds

    UPER ERVER 1025C-UR Manual Control Panel LEDs The control panel located on the front of the SC113TQ-R650 chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 29: Nic2

    Chapter 3: System Interface NIC2 Indicates network activity on LAN2 when fl ashing. NIC1 Indicates network activity on LAN1 when fl ashing. Indicates IDE channel activity when fl ashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.

  • Page 30: Hard Drive Carrier Leds

    UPER ERVER 1025C-UR Manual Hard Drive Carrier LEDs Each hard drive carrier has two LEDs. • Green: When illuminated, the green LED on the front of the drive carrier in- dicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.

  • Page 31: Chapter 4 System Safety

    System Safety Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 1025C-UR from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 32: General Safety Precautions

    Keep the area around the 1025C-UR clean and free of clutter. • The 1025C-UR weighs approximately 33 lbs. (15 kg.) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight. Always keep your back straight and lift with your legs.

  • Page 33: Esd Precautions

    Chapter 4: System Safety • After accessing the inside of the system, close the system back up and secure it to the rack unit after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 34: Operating Precautions

    ERVER 1025C-UR Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 1025C-UR is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed.

  • Page 35: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install processors and heatsinks to the X7DCU serverboard, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 36: Processor And Heatsink Installation

    UPER ERVER 1025C-UR User's Manual Processor and Heatsink Installation When handling the processor, avoid placing direct pressure on the label area of the fan. Also, do not place the serverboard on a conductive sur- face, which can damage the BIOS battery and prevent the system from booting up.
  • Page 37 Chapter 5: Advanced Serverboard Setup 3. Use your thumb and your index fi nger to hold the CPU at opposite sides. 4. Align pin1 of the CPU (the cor- ner marked with a triangle) with the notched corner of the CPU socket. 5.
  • Page 38 UPER ERVER 1025C-UR User's Manual Installing the Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the (preinstalled) heatsink retention mechanism.

  • Page 39: Connecting Cables

    Chapter 5: Advanced Serverboard Setup Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 40: I/O Ports

    UPER ERVER 1025C-UR User's Manual All JF1 wires have been bundled into single keyed ribbon cable to simplify their connection. The red wire in the ribbon cable plugs into pin 1 of JF1. Connect the other end of the cable to the Control Panel printed circuit board, located just behind the system status LEDs in the chassis.

  • Page 41: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is inter- leaved to improve performance (see step 1).
  • Page 42 UPER ERVER 1025C-UR User's Manual Possible System Memory Allocation & Availability System Device Size Physical Memory Remaining (4 GB Total System Memory) Firmware Hub fl ash memory 1 MB 3.99 (System BIOS) Local APIC 4 KB 3.99 Area Reserved for the 2 MB 3.99...

  • Page 43: Pci Expansion Cards

    Chapter 5: Advanced Serverboard Setup PCI Expansion Cards Two riser cards are used to support add-on cards to the system. The SC113TQ- R650 chassis can accommodate one standard size (full height full length) and one low profi le PCI expansion card in addition to a UIO card. When viewed from the chassis front, the standard size card installs to the left and the low-profi...

  • Page 44: Serverboard Details

    UPER ERVER 1025C-UR User's Manual Serverboard Details Figure 5-4. SUPER X7DCU Layout (not drawn to scale) COM1 KB/MS LAN2 LAN1 USB0/1 JWOR1 JPG1 JBT1 I-SATA5 I-SATA4 I-SATA3 I-SATA2 JPEW1 I-SATA1 JPEW2 I-SATA0 Battery S I/O BANK2 BANK3 BANK1 X7DCU FAN7...

  • Page 45: X7Dcu Quick Reference

    Chapter 5: Advanced Serverboard Setup X7DCU Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-9) JCF1 Compact Flash Master/Slave Select Closed (Master) JIDE IDE Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 LAN1/2 Enable/Disable Pins 1-2 (Enabled) JWD1 Watch Dog...

  • Page 46: Connector Defi Nitions

    UPER ERVER 1025C-UR User's Manual Connector Defi nitions ATX Power 20-pin Connector Pin Defi nitions (JPW1) ATX Power Connector Pin# Defi nition Pin # Defi nition The primary ATX power supply con- +3.3V +3.3V nector meets the SSI (Superset ATX) -12V +3.3V...
  • Page 47 Chapter 5: Advanced Serverboard Setup HDD LED The HDD (IDE Hard Disk Drive) LED HDD LED Pin Defi nitions (JF1) connection is located on pins 13 and Pin# Defi nition 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. HD Active Refer to the table on the right for pin defi...
  • Page 48 UPER ERVER 1025C-UR User's Manual Power Fail LED Power Fail LED Pin Defi nitions (JF1) The Power Fail LED connection is Pin# Defi nition located on pins 5 and 6 of JF1. Refer to the table on the right for pin defi ni- Ground tions.
  • Page 49 Chapter 5: Advanced Serverboard Setup Universal Serial Bus Headers Universal Serial Bus Headers Pin Defi nitions (USB2/3, USB4) Three additional USB headers (USB2/ USB2 USB3, USB4 USB3 and USB4) are included on the Pin # Defi nition Pin # Defi nition serverboard.
  • Page 50 UPER ERVER 1025C-UR User's Manual Power LED/Speaker Speaker Connector Pin Defi nitions (JD1) On the JD1 header, pins 1-3 are for Pin # Function Defi nition a power LED and pins 4-7 are for an Speaker data (red wire) external speaker. See the table on the No connection right for speaker pin defi...
  • Page 51 Chapter 5: Advanced Serverboard Setup Wake-On-LAN Wake-On-LAN The Wake-On-LAN header is desig- Pin Defi nitions nated JWOL1. See the table on the (JWOL1) right for pin definitions. You must Pin# Defi nition enable the LAN Wake-Up setting in +5V Standby BIOS to use this feature.
  • Page 52 UPER ERVER 1025C-UR User's Manual UID Switches There are two Unit Identifi cation (UID) switches on the motherboard. The Front Panel UID Switch connects to pin 13 of JF1. The Rear UID Switch (SW1) is located next to LAN2. Push-...

  • Page 53: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Explanation of Jumpers To modify the operation of the serverboard, jumpers can be used Connector to choose between optional settings. Pins Jumpers create shorts between two pins to change the function of the Jumper connector.
  • Page 54 UPER ERVER 1025C-UR User's Manual LAN Enable/Disable LAN Enable/Disable Change the setting of jumper JPL1 to Jumper Settings (JPL1) enable or disable the onboard Ether- Jumper Setting Defi nition net (RJ45) ports LAN1 and LAN2. See Pins 1-2 Enabled the table on the right for jumper set-...

  • Page 55: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators LAN1/LAN2 LEDs The Ethernet ports (located beside the LAN LED Connection Speed Indicator VGA port) have two LEDs. On each LED Color Defi nition Gigabit LAN port, one LED indicates No connection or 10 MHz activity when blinking while the other Green 100 MHz...

  • Page 56: 5-11 Floppy, Ide And Sata Drive Connections

    UPER ERVER 1025C-UR User's Manual 5-11 Floppy, IDE and SATA Drive Connections Note the following when connecting the fl oppy and hard disk drive cables: • The fl oppy disk drive cable has seven twisted wires. • A red mark on a wire typically designates the location of pin 1.
  • Page 57 Chapter 5: Advanced Serverboard Setup IDE Connector IDE Drive Connector Pin Defi nitions (IDE) There are no jumpers to con- Pin# Defi nition Pin # Defi nition fi gure the onboard IDE connec- Reset IDE Ground tor. See the table on the right Host Data 7 Host Data 8 for pin defi...

  • Page 58: 5-12 Installing Software

    5-12 Installing Software After the hardware has been installed, you should fi rst install the operating system and then the drivers. The necessary drivers are all included on the Supermicro CDs that came packaged with your motherboard. Driver/Tool Installation Display Screen Note: Click the icons showing a hand writing on paper to view the readme fi...

  • Page 59: Supero Doctor Iii

    Chapter 5: Advanced Serverboard Setup Supero Doctor III The Supero Doctor III program is a Web base management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The Supero Doctor III program included on the CDROM that came with your motherboard allows you to monitor the environment and operations of your system.
  • Page 60 Supero Doctor III Interface Display Screen (Remote Control) Note: SD III Software Revision 1.0 can be downloaded from our Web Site at: ftp:// ftp.supermicro.com/utility/Supero_Doctor_III/. You can also download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend Supero Doctor II.

  • Page 61: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC113TQ-R650 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 62: Control Panel

    UPER ERVER 1025C-UR Manual Figure 6-1. Chassis: Front and Rear Views DVD-ROM Drive Control Panel Hot-Swap Drive Bays (8) Power Supplies Mouse/Keyboard COM Port VGA Port PCI Slots USB Ports LAN Ports Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.

  • Page 63: System Fan Failure

    Chapter 6: Advanced Chassis Setup Adding a System Fan Turn off the power to the system and unplug the power cord. Remove the chassis cover then remove the dummy fan from the fan tray. Place the new fan into the vacant space in the housing while making sure the arrows on the top of the fan (indicating air direction) point in the same direc- tion as the arrows on the other fans.

  • Page 64: Drive Bay Installation/Removal

    Proceed to the "DVD-ROM Drive Installation" section later in this chapter for instructions. Note: Only a "slim" DVD-ROM drive will fi t into the 1025C-UR. Hard Drive Installation The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis.
  • Page 65 Chapter 6: Advanced Chassis Setup Align the drive in the carrier so that the screw holes of both line up. Note that there are holes in the carrier marked “SATA” to aid in correct installation. Secure the drive to the carrier with four screws as illustrated below. Insert the drive carrier into its bay, keeping the carrier oriented so that the hard drive is on the top of the carrier and the release button is on the right side.

  • Page 66: Dvd Drive Installation

    UPER ERVER 1025C-UR Manual Figure 6-4. Removing a Hard Drive DVD Drive Installation The SC113 chassis includes a pre-installed DVD-ROM. Installing or Replacing a DVD-ROM Drive (Figure 6-5) Power down the system and if necessary, remove the server from the rack and the front bezel from the chassis.
  • Page 67 Chapter 6: Advanced Chassis Setup Insert the new drive unit in the slot until the tab locks in place. Reconnect the data and power cables. Replace the chassis cover (replace the server in the rack, if necessary) and power up the system. Figure 6-5.

  • Page 68: Power Supply

    ERVER 1025C-UR Manual Power Supply The SuperServer 1025C-UR has a 650 watt redundant power supply, which is auto-switching capable. This enables it to automatically sense and operate with a 100V to 240V input voltage. A power on/off switch is included on the back of the unit.

  • Page 69: Chapter 7 Bios

    Please refer to the Manual Download area of the Super Micro web site <http://www.supermicro.com> for any changes to the BIOS that may not be refl ected in this manual.

  • Page 70: Running Setup

    UPER ERVER 1025C-UR User's Manual Running Setup Default settings are in bold text unless otherwise noted. The BIOS setup options described in this section are selected by choosing the ap- propriate text from the main BIOS Setup screen. All displayed text is described in this section, although the screen display is often all you need to understand how to set the options (see the next page).

  • Page 71: Main Bios Setup Menu

    Chapter 7: BIOS Main BIOS Setup Menu Main Setup Features System Time To set the system date and time, key in the correct information in the appropriate fi elds. Then press the <Enter> key to save the data. System Date Using the arrow keys, highlight the month, day and year fi...
  • Page 72 UPER ERVER 1025C-UR User's Manual SATA Port1, SATA Port2, SATA Port3, SATA Port4, SATA Port5 and SATA Port6 These settings allow the user to set the parameters of SATA Port, SATA Port, SATA Port3 and SATA Port4. Hit <Enter> to activate the following sub-menu screen for detailed options of these items.
  • Page 73 Chapter 7: BIOS 32 Bit I/O This option allows the user to enable or disable the function of 32-bit data transfer. The options are Enabled and Disabled. Transfer Mode This option allows the user to set the transfer mode. The options are Standard, Fast PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.

  • Page 74: Advanced Setup

    UPER ERVER 1025C-UR User's Manual SATA AHCI Enable Select Enable to enable the Serial ATA Advanced Host Interface. (Use caution when enabling. This feature is for advanced programmers only. The options are Enabled and Disabled.) System Memory This display informs you how much system memory is recognized as being present in the system.
  • Page 75 Chapter 7: BIOS Power Button Behavior If set to Instant-Off, the system will power off immediately as soon as the user hits the power button. If set to 4-sec., the system will power off when the user presses the power button for 4 seconds or longer. The options are Instant-Off and 4-sec override.
  • Page 76 UPER ERVER 1025C-UR User's Manual Memory Cache Cache System BIOS Area This setting allows you to designate a reserve area in the system memory to be used as a System BIOS buffer into which BIOS can write (cache) data. Select Write Protect to enable this function, and this area will be reserved for BIOS ROM ac- cess only.
  • Page 77 Chapter 7: BIOS Cache Extended Memory Area If enabled, this feature will allow the data stored in the extended memory area to be cached (written) into a buffer, a storage area in the Static DROM (SDROM) or written into the L1/L2/L3 cache inside the CPU to speed up CPU operations. Select Uncached to disable this function.

  • Page 78: Advanced Chipset Control

    UPER ERVER 1025C-UR User's Manual Latency Timer This setting allows you to set the clock rate for the Bus Master. A high-priority, high-throughout device may benefi t from a greater clock rate. The options are Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, 00E0h and Other. For Unix, Novell and other Operating Systems, please select "Other".
  • Page 79 Chapter 7: BIOS Channel 0 Rank Sparing/Channel 1 Rank Sparing Select Enable to enable the function of memory sparing for Memory Bus Branch 0 or Branch 1. The options are Enabled and Disabled. Enhanced x8 Detection Select Enabled to enable Enhanced x8 DRAM UC Error Detection. The options are Disabled and Enabled.
  • Page 80 UPER ERVER 1025C-UR User's Manual Advanced Processor Options Access the submenu to make changes to the following settings. CPU Speed This is a display that indicates the speed of the installed processor. Frequency Ratio (Available if supported by the CPU) The feature allows the user to set the internal frequency multiplier for the CPU.
  • Page 81 Chapter 7: BIOS Adjacent Cache Line Prefetch (Available when supported by the CPU) The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The CPU fetches both cache lines for 128 bytes as comprised if Enabled. The options are Disabled and Enabled.
  • Page 82 UPER ERVER 1025C-UR User's Manual I/O Device Confi guration Access the submenu to make changes to the following settings. KBC Clock Input This setting allows you to select clock frequency for KBC. The options are 6MHz, 8MHz, 12MHz and 16MHz.

  • Page 83: Dmi Event Logging

    Chapter 7: BIOS Base I/O Address This setting allows you to select the base I/O address for the Floppy port. The op- tions are Primary and Secondary. DMI Event Logging Access the submenu to make changes to the following settings. Event Log Validity This is a display to inform you of the event log validity.

  • Page 84: Hardware Monitor Logic

    UPER ERVER 1025C-UR User's Manual Console Type This item allows you to choose the console redirection type. The options are VT100, VT100/8bit, PC-ANSI/7bit, PC ANSI, VT100+ and VT-UTF8. Flow Control This item allows you to set the fl ow control for the console redirection. The options are None, XON/XOFF and CTS/RTS.
  • Page 85 Chapter 7: BIOS Voltage Monitoring The following items will be monitored and displayed: Vcore A, Vcore B, -12V, P1V5, +3.3V, +12V, 5Vsb, 5VDD, P_VTT, Vbat. Note: In the Windows OS environment, the Supero Doctor III settings take prece- dence over the BIOS settings. When fi rst installed, Supero Doctor III adopts the temperature threshold settings previously set in the BIOS.
  • Page 86 UPER ERVER 1025C-UR User's Manual IPMI (The option is available only when an IPMI card is installed in the system.) IPMI Specifi cation Version This item displays the current IPMI Version. BMC HW/Firmware Version This item displays the current Firmware Version.
  • Page 87 Chapter 7: BIOS BIOS POST Errors Enabling this function to log POST errors. The options are Enabled and Dis- abled. BIOS POST Watch Dog Set to Enabled to enable POST Watch Dog. The options are Enabled and Dis- abled. OS Boot Watch Dog Set to Enabled to enable OS Boot Watch Dog.

  • Page 88: Security

    UPER ERVER 1025C-UR User's Manual Realtime Sensor Data This feature display information from motherboard sensors, such as temperatures, fan speeds and voltages of various components. Security Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. Security setting options are displayed by highlighting the setting using the arrow keys and pressing <Enter>.
  • Page 89 Chapter 7: BIOS Supervisor Password Is: This indicates if a supervisor password has been entered for the system. Clear means such a password has not been used and Set means a supervisor password has been entered for the system. User Password Is: This indicates if a user password has been entered for the system.

  • Page 90: Boot

    UPER ERVER 1025C-UR User's Manual Password on Boot This setting allows you to determine if a password is required for a user to enter the system at bootup. The options are Enabled (password required) and Disabled (password not required). Boot Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.

  • Page 91: Exit

    Chapter 7: BIOS Exit Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys. You should see the following display. All Exit BIOS settings are described in this section. Exit Saving Changes Highlight this item and hit <Enter> to save any changes you made and to exit the BIOS Setup utility.
  • Page 92 UPER ERVER 1025C-UR User's Manual Save Changes Highlight this item and hit <Enter> to save any changes you made. You will remain in the Setup utility. 7-24...

  • Page 93: Appendix A Bios Post Messages

    Appendix A: BIOS POST Messages Appendix A BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a prob- lem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages. Failure Fixed Disk Fixed disk is not working or not confi...
  • Page 94 UPER ERVER 1025C-UR User's Manual System CMOS checksum bad - Default confi guration used System CMOS has been corrupted or modifi ed incorrectly, perhaps by an application program that changes data stored in CMOS. The BIOS installed Default Setup Values.
  • Page 95 Appendix A: BIOS POST Messages CPU ID: CPU socket number for Multi-Processor error. EISA CMOS not writeable ServerBIOS2 test error: Cannot write to EISA CMOS. DMA Test Failed ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access) registers. Software NMI Failed ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt).
  • Page 96 UPER ERVER 1025C-UR User's Manual I/O device IRQ confl ict I/O device IRQ confl ict error. PS/2 Mouse Boot Summary Screen: PS/2 Mouse installed. nnnn kB Extended RAM Passed Where nnnn is the amount of RAM in kilobytes successfully tested.
  • Page 97 Appendix A: BIOS POST Messages Press <F2> to enter Setup Optional message displayed during POST. Can be turned off in Setup. PS/2 Mouse: PS/2 mouse identifi ed. Run the I2O Confi guration Utility One or more unclaimed block storage devices have the Confi guration Request bit set in the LCT.
  • Page 98 UPER ERVER 1025C-UR User's Manual Notes...

  • Page 99: Appendix B Bios Post Codes

    Appendix B: BIOS POST Codes Appendix B BIOS POST Codes This section lists the POST (Power On Self Test) codes for the Phoenix BIOS. POST codes are divided into two categories: recoverable and terminal. Recoverable POST Errors When a recoverable type of error occurs during POST, the BIOS will display an POST code that describes the problem.
  • Page 100 UPER ERVER 1025C-UR User's Manual POST Code Description 1-2-2-3 BIOS ROM checksum Initialize cache before memory Auto size 8254 timer initialization 8237 DMA controller initialization Reset Programmable Interrupt Controller 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Set ES segment register to 4 GB...
  • Page 101 Appendix B: BIOS POST Codes POST Code Description Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1 Confi gure advanced cache registers Initialize Multi Processor APIC Enable external and CPU caches Setup System Management Mode (SMM) area Display external L2 cache size Load custom defaults (optional)
  • Page 102 UPER ERVER 1025C-UR User's Manual POST Code Description Set up Power Management Initialize security engine (optional) Enable hardware interrupts Determine number of ATA and SCSI drives Set time of day Check key lock Initialize typematic rate Erase <ESC> prompt Scan for <ESC> key stroke Enter SETUP Clear Boot fl...
  • Page 103 Appendix B: BIOS POST Codes The following are for boot block in Flash ROM POST Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM Go to BIOS Set Huge Segment Initialize Multi Processor Initialize OEM special code...
  • Page 104 UPER ERVER 1025C-UR User's Manual Notes...

  • Page 105: Appendix C System Specifi Cations

    Appendix C: System Specifi cations Appendix C System Specifi cations Processors Single or dual Intel® Xeon® 5400/5300/5200/5100 Sequence processors at a front side (system) bus speed of 1333/1066 MHz. Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel 5100/ICH9R chipset BIOS...
  • Page 106 UPER ERVER 1025C-UR User's Manual Chassis SC113TQ-R650 (1U rackmount form factor) Dimensions: (WxHxD) 17.2 x 1.7 x 23.5 in. (437 x 43 x 597 mm) Weight Gross (Bare Bone): 33 lbs. (15 kg.) System Cooling Four 4-cm counter-rotating fans System Input Requirements...
  • Page 107 See www.dtsc.ca.gov/hazardouswaste/perchlorate” (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
  • Page 108 UPER ERVER 1025C-UR User's Manual Notes...
