QUICK START GUIDE
CY8CKIT-149 PSOC
TM
1) Connect the board to your PC using an USB Micro-B cable at connector (J8).
2) The user LED (LED1) will display the breathing e ect throughout the process.
3) Touch the CAPSENSE
buttons (BTN0, BTN1, BTN2). The
TM
corresponding LEDs (LED11, LED12, LED13) turn on.
4) Touch the CAPSENSE
sliders (SLD0, SLD1, SLD2, SLD3, SLD4, SLD5).
TM
The LEDs (LED5, LED6, LED7, LED8, LED9, LED10) up to the touch position
are turned ON.
1
USB Micro-B connector (J8)
2
KitProg3 status LED (LED3)
3
PSOC™ 5LP MCU with KitProg3 firmware (CY8C5868LTI-LP039 - U1)
4
Power LED (LED2)
5
User LED (LED1)
6
I/O expansion headers (J1, J2)**
7
CAPSENSE™ 6-segment sliders (SLD0, SLD1, SLD2, SLD3, SLD4, SLD5) and
corresponding LEDs (LED5, LED6, LED7, LED8, LED9, LED10)
8
PSOC™ 4100S MCU (CY8C4147AZI-S475 - U2)
9
User button (SW1)
10 Reset switch (SW2)
11 AIROC™ Bluetooth® LE module (CYBLE-022001-00 - U3)
12 User LED of AIROC™ Bluetooth® LE module (LED4)
13 Programming selection switch (SW4)*
14 CSX CAPSENSE™ buttons (BTN0, BTN1, BTN2) and corresponding LEDs (LED11, LED12, LED13)
15 Current measurement jumper (J3)**
16 KitProg3 mode switch (SW3)
* The programming selection switch (SW4) is used to program either the PSOC
**Footprints only, not populated on the board.
For more information, visit:
www.infineon.com/CY8CKIT-149
Published by Infineon Technologies AG 81726
Munich, Germany
© 2024 Infineon Technologies AG.
All Rights Reserved.
4100S Plus Prototyping Kit
TM
4100S device or the AIROC
TM
Bluetooth® LE module.
Document Number: 002-20564 Rev. *C
Date: 11/2024
