Summary of Contents for Fishman FLUENCE P90
- Page 1 INSTALL GUIDE FLUENCE P90 PICKUPS...
-
Page 2: System Requirements
TARILY ASSUME THE RISK OF DEATH OR OTHER PERSONAL INJURY SUSTAINED WHILE PARTICIPATING IN SUCH ACTIVITIES WHETHER OR NOT CAUSED BY THE NEGLIGENCE OR ANY OTHER FAULT of Fishman, including but not limited to equipment malfunction from whatever cause, or any other fault of Fishman. Additionally, you agree to indemnify, defend... -
Page 3: Getting Started
Fishman Fluence Pickups are low impedance and perform ideally with 25K audio taper potentiometers. - Page 4 The preamps on Fishman Fluence pickups are not suitable for use with other brands of guitar pickups. 4. Review your planned scheme for errors, complete the soldering, mount and secure all your components, and test your completed installation before assembly.
- Page 5 Fluence P-90 - Connection Points & Functions 1. Voice-2 Select Wire - To select Voice-2, connect this pin to ground through a switch contact or permanently by soldering it to any ground or by using one of the included jumpers across the pins. This pin is an electronically controlled switch and has no signal on it.
- Page 6 9V Battery P90 Set 1 x Volume, 1 x Tone Volume: Pull for Voice-3 Bridge/Neck Tone: Pull for Voice-2 Bridge/Neck Output Jack Ring Sleeve Bridge Ground P-90 BRIDGE P-90 BRIDGE NECK NECK Volume Pull Pull Tone Voice-3 Voice-2 Bridge Neck “224”...
- Page 7 9V Battery P90 Set 1 x Volume, 1 x Tone Volume: Pull for Voice-3 Bridge/Neck Tone: Pull for Voice-2 Bridge/Neck Output Jack Ring Sleeve Bridge Ground P-90 BRIDGE P-90 BRIDGE NECK NECK Volume Pull Tone Pull Voice-2 Voice-3 Neck “224” .22uF Neck Pickup Selector...
- Page 8 P90 Set 9V Battery 2 x Volume, 2 x Tone Bridge Tone: Pull for Voice-2 Bridge/Neck Neck Tone: Pull for Voice-3 Bridge/Neck Output Jack Ring Sleeve Bridge Ground P-90 BRIDGE P-90 BRIDGE NECK NECK Pull Voice-3 Neck Volume Neck Neck Pickup Tone .22uF...
- Page 9 * Reactive Tone Controls The Fluence Reactive Tone Control for active P90 Set pickups is designed to provide precise tone shaping Neck Volume: Pull for Neck Phase Reverse and enhanced resonance when fully rolled off, Bridge Volume Regulator/Charger compared to standard tone controls. Neck Reactive Tone: Pull for Voice-3 Bridge/Neck Battery Bridge ReactiveTone: Pull for Voice-2 Bridge/Neck...
- Page 10 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 514-300-247_r0 08/21 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 514-300-183_r0 01/24...
