M3 Sonar
1
Install the Software
a.
Download the M3 software
onto your computer.
b.
Run the Setup file.
c.
Apply the default settings
during installation.
Click Yes to install the
d.
KML USB Converter when
prompted.
Power Supply
3
Install your Sonar
a.
Connect the M3 Sonar system
units as shown.
b.
Plug in the Power Supply.
Kongsberg Discovery Canada
Tel: (604) 464 8144
®
Quick Start
M3 Sonar Cable
Ethernet Cable
2
Set Your IP Address
a.
In Windows, open Settings.
Select Network & Internet,
b.
then Change adapter options.
c.
Right-click on your Ethernet
network and select Properties.
d.
Select Internet Protocol v4,
then select Properties.
e.
Set your IP address to
192.168.1.233.
f.
Set the Subnet Mask to
255.255.255.0.
To download Kongsberg Discovery manuals, visit:
kongsbergdiscovery.net
→
