M3 SONAR
1

INSTALL THE SOFTWARE

a.
Insert the USB flash drive into
your computer.
b.
Run the Setup file.
c.
Apply the default settings
during installation.
d.
Click Yes to install the
KML USB Converter when
prompted.
Power Supply
3

INSTALL YOUR SONAR

a.
Connect the M3 system units
as shown.
b.
Apply power to the Power
Supply.
Kongsberg Mesotech Ltd.
Tel: (604) 464 8144
QUICK START
®
M3 Cable
To download the M3 Sonar software or manuals, visit:
http://www.km.kongsberg.com/mesotechsoftware
http://www.km.kongsberg.com/mesotechdocumentation
Ethernet Cable
2

SET YOUR IP ADDRESS

a.
Open the Control Panel in
Windows.
Select Change adapter
b.
settings.
c.
Set your computer's network
IP address to 192.168.1.233.
d.
Set the Subnet Mask to
255.255.255.0.
→
