PRODUCT DESCRIPTION
The Pyle PDIC speaker system delivers stereo
sound to any room in your home or o ce without
cluttering oor space. This pair of speakers can be
used for in-wall and in-ceiling applications as they
mount ush for a clean look. Perfect for custom
installations, the PDIC series speakers feature
polymer dome tweeters, impressive power
handling capability, high-temperature voice coils
and high-e ciency response rates – all to produce
more full and rich sound. Convenient speaker
terminals allow for quick and hassle-free speaker
wire connection. System includes cut-out template
for easy installation. Achieve wide-ranged sound
performance and add audio to any room with
the PDIC Speaker Systems.
• Features: - Directable 1/2" (1.27 cm)
Polymer Dome Tweeter - Perfect for
Custom Installations & Applications
• In-Wall / In-Ceiling System - 200 Watts Rated
Peak Power - Includes Cut-Out Template for
Easy Installation
• 2-Way Stereo Sound Speakers - Frequency
Response: 70Hz - 20kHz - Cut-Out Dimension:
6 1/2" (16.5 cm) Diameter x 2 5/8" (6.6 cm) Depth
• 6-1/2" (16.5 cm) Midbass Speaker - 4-8 Ohm
Impedance - Overall Dimensions: 9" Diameter x
2 3/4" (6.9 cm) Depth
• 1" (2.5 cm) High Temperature Voice Coil-
Mounts Flush on Walls or Ceilings
WHAT'S IN THE BOX:
•
One pair of speakers with grilles
•
Strips of adhesive
•
Template
www.PyleUSA.com
PDIC61RD - PDIC61RDBK
PDIC61WT - PDIC61RDSL
Home In-Wall/Ceiling
Speakers
USER GUIDE
ENG
For user guides in multiple languages,
SCAN THE QR CODE
and enter your model number
User Manuals available in
Italian l German l Polish l Turkish l Dutch
Questions or Comments?
We are here to help!
Phone: 1.718.535.1800
PyleUSA.com/ContactUs
