Summary of Contents for Pyle PDIW67
- Page 1 Visit Our Website SCAN ME PyleUSA.com PDIW67 6.5'' Home In-Wall / Ceiling Speakers USER GUIDE...
- Page 2 READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT. RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE. Features: • In-Wall / In-Ceiling System • 2-Way Stereo Sound Speakers • 6.5'' Long Throw Woofers • 1'' High Temperature Voice Coils • 1'' Titanium Dome Tweeters •...
- Page 3 It has been thoroughly tested to ensure consistent and reliable performance. If you have any questions regarding the installa- tion or operation of your PYLE in-wall/in-ceiling speaker system that are not covered in this manual, please contact your dealer for assistance.
- Page 4 REAR SPEAKERS 5-6FT WALL WALL WALL WALL IN-CEILING Proper placement of the speakers is important to achieve the most realistic soundstage possible. These recommendations are for optimum speaker placement. You can make slight adjustments without diminishing the listening experience. Front speakers should be placed the same distance from each other as from the listening position.
- Page 5 SPEAKER CONNECTIONS Connection Tips LEFT RIGHT Front or Rear Speaker Outputs LEFT RIGHT For optimal sound quality, ensure both speaker wires are the same length. If one speaker is closer to the ampli er than the other, hide the excess wire behind the wall.
- Page 6 Place the frame assembly in the wall. Connect the speaker wires to the Screw down each of the six Phillips speaker. Screw down each of the six head screws. The locking tabs will Phillips head screws. swivel into place and secure the unit to the rear surface of the drywall.
- Page 7 Thank you for choosing PyleUSA. By registering your product, you ensure that you receive the full bene ts of our exclusive warranty and personalized customer support. Complete the form to access expert support and to keep your Model Number: PyleUSA purchase in perfect condition. PDIW67 PyleUSA.com/pages/register www.PyleUSA.com...
- Page 8 Questions or Comments? We are here to help! Phone: 1.718.535.1800 PyleUSA.com/ContactUs...
