- Page 1 EN User Manual | Cooker LKS6000N0W...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5. BEFORE FIRST USE..................10 6. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. - Page 4 • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. • WARNING: Danger of fire: Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance. •...
-
Page 5: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation • Do not use multi-plug adapters and extension cables. • Do not let mains cables touch or come WARNING! near the appliance door or the niche below Only a qualified person must install this the appliance, especially when it operates appliance. -
Page 6: Care And Cleaning
• Do not use aluminum foil or other • Do not keep hot cookware on the control materials between the cooking surface panel. and the cookware, unless otherwise • Do not let cookware boil dry. specified by the manufacturer of this •... -
Page 7: Installation
• Concerning the lamp(s) inside this product • Use original spare parts only. and spare part lamps sold separately: 2.7 Disposal These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, WARNING! vibration, humidity, or are intended to Risk of injury or suffocation. -
Page 8: Levelling Of The Appliance
3.4 Levelling of the appliance Dimension Height 857 - 917 Width Depth 3.3 Changing the height and the depth of the cooker The cooker is supplied at 897 mm height and 500 mm depth. Use small feet on the bottom of appliance to 1. -
Page 9: Electrical Installation
larger than the width of the appliance, you must adjust the side measurement to centre the appliance. If you changed the dimensions of the cooker, you must align the non-tip device correctly. CAUTION! If the space between the bench 1. Install the anti-tilt protection B - 393 mm cupboards is larger than the width of the down from the top surface of the appliance, you must adjust the side... -
Page 10: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Knobs for the hob Temperature indicator / symbol Knob for the temperature Knob for the oven functions Hob lamp / symbol / indicator Heating element Lamp Shelf support, removable Shelf positions 4.2 Cooking surface layout Steam outlet - number and position depend on the model Cooking zone 1500 W... -
Page 11: Hob - Daily Use
5.1 Initial preheating and cleaning Preheat the empty appliance before the first Deactivating the appliance does not use and contact with food. The appliance can cancel the mechanical door lock. emit unpleasant smell and smoke. Ventilate the room during preheating. 5.3 Installing the steam outlet cover 1. -
Page 12: Hob - Hints And Tips
6.1 Heat setting The hob control indicator comes on. To complete the cooking process, turn the knob to the off position. Symbols Function If all cooking zones are deactivated, the hob control indicator goes out. Off position 6.2 Using the rapid hot plate 1 - 6 Heat settings A red dot in the middle of the plate shows a... -
Page 13: Oven - Daily Use
4. To keep the hotplates in good shape, rub in a sewing machine oil regularly. Polish off the oil with absorbent paper. 9. OVEN - DAILY USE WARNING! Grilling Refer to Safety chapters. To grill thin pieces of food and to toast bread. Bottom heat 9.1 Turning the oven on and off To bake cakes with crispy bottom and to pre‐... -
Page 14: Oven - Hints And Tips
Put the shelf between the guide bars of the shelf support. Do not push the baking tray or deep pan all the way to the back wall of the cavity. This prevents the heat from circulating around the tray. The food may be burnt, especially in the rear part of the tray. -
Page 15: Baking Cakes
11.2 Baking Leave the meat for approximately 15 minutes before carving so that the juice does not seep For the first baking, use the lower out. temperature. To prevent too much smoke in the oven You can extend the baking time by 10 – 15 during roasting, add some water into the minutes if you bake cakes on more than one deep pan. - Page 16 Food Tempera‐ Time Shelf po‐ Accessories ture (°C) (min) sition Buttered cake 180 - 200 15 - 30 baking tray Meringue 110 - 130 80 - 100 baking tray Swiss roll 150 - 170 15 - 30 baking tray Stuffed yeast cake 160 - 180 20 - 35 baking tray...
- Page 17 Food Tempera‐ Time (min) Shelf po‐ Accessories ture (°C) sition Fish in pouches 300 g 20 - 30 baking tray or grill- / roasting pan Whole fish 200 g 25 - 35 baking tray or grill- / roasting pan Fish fillet 300 g 30 - 40 pizza pan on wire shelf Meat...
-
Page 18: Information For Test Institutes
11.9 Information for test institutes Food Function Tempera‐ Accessories Shelf po‐ Time ture (°C) sition (min) Small cakes (16 per tray) Conventional cook‐ baking tray or grill- / 15 - 25 roasting pan Apple pie (2 tins Ø20 cm, Conventional cook‐ 2 round light tins 60 - 70 diagonally off set) -
Page 19: Cleaning The Oven Door
2. Carefully pull the heating element down. 2. Pull the rear end of the shelf support away from the side wall and remove it. 3. Clean the oven ceiling with a soft cloth with warm water and a cleaning agent, and let it dry. - Page 20 5. Release the locking system to remove the glass panels. 2. Lift and turn the levers fully on both hinges. 6. Turn the two fasteners by 90° and remove them from their seats. 90° 7. First lift carefully and then remove the 3.
-
Page 21: Replacing The Lamp
Make sure that you put the glass panels (A, B The drawer below the oven can be removed and C) back in the correct sequence. for cleaning. 1. Pull the drawer out until it stops. 2. Slowly lift the drawer. 3. -
Page 22: Service Data
Do not remove the rating plate from the appliance cavity. 14. ENERGY EFFICIENCY 14.1 Product Information according to EU Ecodesign Regulations for Hob Model identification LKS6000N0W Type of hob Hob inside Freestanding Cooker Number of cooking zones... -
Page 23: Hob - Energy Saving
14.3 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Oven Supplier's name Electrolux Model identification LKS6000N0W 943005278 Energy Efficiency Index 95.0 Energy efficiency class Energy consumption with a standard load, conventional mode 0.76 kWh/cycle... -
Page 24: Environmental Concerns
Help protect the environment and human health by recycling waste of electrical and Electrolux Appliances AB - Contact Address: electronic appliances. Do not dispose of Al. Powstancow Slaskich 26, 30-570 Krakow, appliances marked with the symbol... - Page 28 867354802-E-292024...
