Patriot Lighting DH7037 Manual

Outdoor sensor light
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

PACKAGE CONTENTS
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
Cross Bar Unit
X1
BB
Mounting Screw
X2
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
A
OUTDOOR SENSOR LIGHT
B
CC
Wire Nut
X3
DD
Ball Nut
X2
Sku Number: 356-3417
Model Number: DH7037
EE
Rubber Pad
X2
Page 1 of 5
