I N S T R U C T I O N M A N U A L
M A N U E L D ' I N S T R U C T I O N S
M A N U A L D E I N S T R U C C I O N E S
Widespread Lavatory Faucet
Robinet de lavabo 8"
Llave de Lavabo con dos Asas
HELPFUL TOOLS
For safety and ease of installation, the use of
these helpful tools is recommended.
OUTILS UTILES
Pour des raisons de sécurité et de facilité
d'installation, l'utilisation de ces outils utiles est
recommandée.
HERRAMIENTAS ÚTILES
Por seguridad y facilidad de instalación, se
recomienda el uso de estas útiles herramientas.
Adjustable Wrench
Hex Wrench
Safety Glasses
Clé adjustable
Clé Hexagonale
Lunettes de sécurité
Llave ajustable
Llave Hexagonal
Gafas de seguridad
For warranty or additional information, contact:
US Customers
Canadian Customers
QUEBEC / MARITIMES / WESTERN CANADA
U.S.A.
QUÉBEC / MARITIMES / OUEST CANADIEN
ONTARIO
houseofrohl.com/support
QUEBEC / MARITIMOS / CANADA OCCIDENTAL
houseofrohl.ca/support
1-800-777-9762
houseofrohl.ca/support
1-800-287-5354
1-866-473-8442
INS13829 - Rev. 12/23
