U.S.A.
houseofrohl.com/support
1-800-777-9762
INS13857 - Rev. 01/24
I N S T R U C T I O N M A N U A L
M A N U A L D E I N S T R U C C I O N E S
PRE-RINSE PULL-DOWN KITCHEN FAUCET
ROBINET DE CUISINE DE PRÉRINÇAGE À BEC RÉTRACTABLE
LLAVE DE COCINA DE PREENJUAGUE RETRACTABLE
For warranty or additional information, contact:
QUEBEC / MARITIMES / WESTERN CANADA
QUÉBEC / MARITIMES / OUEST CANADIEN
QUEBEC / MARITIMOS / CANADA OCCIDENTAL
houseofrohl.ca/support
1-866-473-8442
M A N U E L D ' I N S T R U C T I O N S
HELPFUL TOOLS
For safety and ease of installation, the use of
these helpful tools is recommended.
OUTILS UTILES
Pour des raisons de sécurité et de facilité
d'installation, l'utilisation de ces outils utiles est
recommandée.
HERRAMIENTAS ÚTILES
Por seguridad y facilidad de instalación, se
recomienda el uso de estas útiles herramientas.
Adjustable Wrench
Adjustable Pliers
Clé ajustable
Alicate ajustable
Llave ajustable
Pinces réglables
Safety Glasses
Screwdriver
Lunettes de sécurité
Tournevis
Gafas de seguridad
Destornillador
ONTARIO
houseofrohl.ca/support
1-800-287-5354
Advertisement
Related Manuals for Rohl Riobel Authentica AU701SS
Summary of Contents for Rohl Riobel Authentica AU701SS
- Page 1 I N S T R U C T I O N M A N U A L M A N U E L D ’ I N S T R U C T I O N S M A N U A L D E I N S T R U C C I O N E S PRE-RINSE PULL-DOWN KITCHEN FAUCET ROBINET DE CUISINE DE PRÉRINÇAGE À...
-
Page 2: Parts List
Parts List Installation Tool Spray Wand Faucet Body Swing Arm Gasket Supply Line Hot Mounting Washer Supply Line Cold Mounting Nut M. Outlet Hose Hose Protector N. Pulldown Hose Hose Weight H. Spring Liste des pièces Outil d’installation Douchette Corps du robinet Bras pivotant Joint d’étanchéité... - Page 3 Align Aligner Alinee 1. Place Deck Gasket (C) onto base of Faucet Body (B) aligning ribs on faucet Slide Mounting Washer (D) up onto Faucet Body (B) under sink and secure with Mounting Nut (E). (if present) to slots on Deck Gasket. 2.
- Page 4 Secure Mounting Washer (D) with Mounting Nut (E). Tighten the Mounting Attach Swing Arm (J) onto Faucet Body (B). Nut (E) with Installation Tool (A).Thread the Hose Protector (F) onto the end Fixer bras pivotant (J) au corps de robinet (B). of the shank.Tighten the Hose Protector (F) manually.
- Page 5 Insert Pulldown Hose (N) through Spring (H). Insérer le tuyau rétractable (N) dans le ressort (H). Install Pulldown Hose (N) and Spring (H) through Faucet Body (B). Inserte la manguera retráctil (N) a través del resorte (H). Insérer le tuyau rétractable (N) et le ressort (H) dans le corps du robinet (B). Instale la manguera retráctil (N) y el resorte (H) a través de cuerpo de la mezcladora (B).
- Page 6 1. Remove and discard plastic cap from end of Pullout Hose (N). 1. Gently pull down on Pulldown Hose (N) hose to ensure Wand (I) is flush with 2. Install Pulldown Hose (N) to Outlet Hose (M). Push in as far as possible spring (H).
- Page 7 Cold Froide Frio Chaude Caliente more plus 1. Run hot and cold water for 5 seconds. 1. Attach hot & cold supply lines to shut off valves. Tighten by hand, then 1/4 1. Faire couler l’eau chaude et l’eau froide pendant 5 secondes. turn more with adjustable wrench.
- Page 8 For warranty or additional information, contact: QUEBEC / MARITIMES / WESTERN CANADA U.S.A. QUÉBEC / MARITIMES / OUEST CANADIEN ONTARIO houseofrohl.com/support QUEBEC / MARITIMOS / CANADA OCCIDENTAL houseofrohl.ca/support 1-800-777-9762 houseofrohl.ca/support 1-800-287-5354 1-866-473-8442 INS13857 - Rev. 01/24...
