Foreword
The IR3000 precision regulator (hereinafter referred to as the "product") has excellent relief
characteristics, and is constructed to always keep a constant pressure even if used with a reverse flow.
The product has the following features.
(1) A sensitivity of 0.2%F.S. at max is achieved by the nozzle and flapper design.
(IR3000: F.S.
Note) "F.S." is the abbreviation of full span.
(2) Various characteristics such as flow rate, pressure characteristics and repeatability are
improved compared to general regulators.
(3) Relief characteristics are improved.
(4) The adjustment range is as wide as general regulators, which is 0.01~0.8MPa.
1. Specifications
The following specifications are for a single unit of precision regulator. They do not meet the
specifications of the actual system.
Model
Fluid
Max. supply pressure
Min. supply pressure
(Note 2)
Setting pressure
Setting sensitivity
(Note 5)
Repeatability
(Note 6)
Air consumption
Ambient and fluid
temperature
Port size
Port size of pressure gauge
Weight
0.2MPa, IR3010: F.S.
IR3000
(Note 1)
0.01~0.2MPa
(Note 3)
11.5L/min(ANR) or less ( at supply pressure of 1.0MPa)
0.4MPa, IR3020: F.S.
IR3010
Compressed air (dry air)
MAX. 1.0MPa
Setting pressure + 0.1MPa
0.01~0.4MPa
Within 0.2% F.S.
Within s0.5% F.S.
o
-5 to 60 C (No freezing)
Rc1/4,3/8,1/2
Rc1/8 [2 places]
0.64kg
-4-
0.8MPa)
IR3020
0.01~0.8MPa
(Note 4)
(Note 4)
