SMC Networks IR1200-A Operation Manual
Precision regulator
Hide thumbs
Also See for IR1200-A:
- Operation manual (16 pages) ,
- Operation manual (16 pages) ,
- Operation manual (17 pages)
Related Manuals for SMC Networks IR1200-A
Summary of Contents for SMC Networks IR1200-A
- Page 1 Document No.IR-OM00015-A PRODUCT NAME PRECISION REGULATOR MODEL / Series / Product Number ＩＲ３００(０,１,２)－Ａ ＩＲ３０１(０,１,２)－Ａ ＩＲ３０２(０,１,２)－Ａ...
- Page 2 Contents Safety Instructions 2 to 7 1. Application 2. Specifications 3. Construction and Operation Principles 4. How to order 5. Bracket, gauge and switch assembly (optional) 6. Panel mounting 7. Troubleshooting 8. Dimensions 14 to 15...
-
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act. - Page 5 Operating Environment Warning ① Do not use in an atmosphere having corrosive gases, chemicals, sea water, water, water steam, or where there is direct contact with any of these. ② Do not operate in locations where vibration or impact occurs. ③...
- Page 6 ⑫ When using the IR3000-A series in balancing applications, abnormal noises may occur depending on the pressure and circuit conditions. In such cases, the noise will often cease if changes are made to the pressure or piping conditions or if a high noise reduction type silencer (such as SMC’s ANA1 series, etc.) is installed.
- Page 7 Caution Preparation before piping ① Before piping is connected, it should be thoroughly blown out with air (flushing) or washed to remove chips, cutting oil and other debris from inside the pipe. ② Winding of sealant tape When screwing piping or fittings into ports, ensure that metal chips from the pipe threads or sealing material do not enter the piping.
- Page 8 Maintenance Warning ① When the product is removed for maintenance, reduce the set pressure to “0” and shut off the supply pressure completely beforehand. ② When a pressure gauge is to be mounted, remove the plug after reducing the set pressure to “0”. ③...
-
Page 9: Specifications
１． Application This instrument aims at controlling pressure of air lines. ２． Specifications Model IR300(0,1,2)-A IR301(0,1,2)-A IR302(0,1,2)-A Max. supply pressure [ MPa] Min. supply pressure Set pressure + 0.1 (Note 1) [MPa] Set pressure range 0.01 to 0.2 0.01 to 0.4 0.01 to 0.8 [MPa] (Note 2) - Page 10 ３． Construction and Operation Principles When the knob is rotated, the flapper is pushed through the spring, and a gap is generated between the nozzle and flapper. The supply pressure flows to the inlet passes through the path between the nozzle and flapper and acts on the supply / exhaust diaphragm as nozzle pressure. The force generated by the diaphragm pushes down the valve, and the supply pressure flows to the outlet.
-
Page 11: How To Order
４． How to order ― ― ― ・ Option/Semi-standard:Select one each for a to e. ・ Option/Semi-standard symble:When more than one specification is required, indicate in alphanumeric order. Symble Description 0.01～0.2MPa Set pressure range 0.01～0.4MPa 0.01～0.8MPa Bottom exhaust Exhaust direction Front exhaust Rear exhaust Pipe thread type... - Page 12 ５． Bracket, gauge and switch assembly (optional) 1. Bracket 1) Installation of bracket (Grooved) Set nut Mount the bracket to the regulator as shown on the picture. Assemble so that the regulator and rotation stopper of the bracket align properly. Bracket 2) Holding with the set nut (Knurled tool face)
-
Page 13: Panel Mounting
６．Panel mounting 1. Panel mounting 1) Handle removal Remove the handle from the regulator. Handle 2) Panel mounting Insert the regulator into the panel. 3) Nut tightening Hexagon panel nut Adjust the regulator position and tighten the attached hexagon panel nut. Recommended tightening torque Panel Wrench size [mm]... -
Page 14: Troubleshooting
7．Troubleshooting Problem Possible causes Countermeasures Set the pressure again. Fluctuation of flow rate at the downstream side Return the flow rate at the downstream side to the initial rate. Moisture, condensate and foreign matter stuck to the Install a filter and/or mist separator to clean the air supply. flapper. - Page 15 8.Dimensions 8-1. Dimensions of the regulator with the bottom exhaust direction［IR30*0-A］ 68.5 Ｍ12Ｘ1 MOUNTING HOLE Ｍ28Ｘ1.5 BRACKET (OPTION) BLEED PRESSURE GAUGE (OPTION) 2x1/8 PRESSURE GAUGE PORT 2Ｘ1/4～1/2 PORT SIZE EXH PORT 【With digital pressure switch】 69.2 Ｍ12Ｘ1 MOUNTING HOLE Ｍ28Ｘ1.5 BRACKET (OPTION) BLEED 2x1/8 ...
- Page 16 8-2. Dimensions of the regulator with the front or back exhaust direction［IR30*(1,2)-A］ 68.5 Ｍ12Ｘ1 MOUNTING HOLE BRACKET Ｍ28Ｘ1.5 (OPTION) BLEED PRESSURE GAUGE (OPTION) 2x1/8 PRESSURE GAUGE PORT 2Ｘ1/4～1/2 PORT SIZE EXH PORT 【With digital pressure switch】 69.2 MOUNTING HOLE Ｍ12Ｘ1 BRACKET Ｍ28Ｘ1.5 (OPTION) BLEED...
- Page 17 Revision history A Safety Instructions revised Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved -14-...
