Doc. No. IR20-OM00004-F
PRODUCT NAME
PRECISION REGULATOR
MODEL/ Series
IR2120
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the IR2120 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks IR2120

  • Page 1 Doc. No. IR20-OM00004-F PRODUCT NAME PRECISION REGULATOR MODEL/ Series IR2120...
  • Page 2: Table Of Contents

    Contents Safety Instructions 2 to 3 1. Specifications 4 to 5 2. Construction and operation principle 3. How to order 4. Marking on product 5. Precautions for handling 8 to11 6. Warranty 7. Troubleshooting 8. Dimensions - 1 -...
  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
  • Page 5: Specifications

    Foreword The IR2120 precision regulator (hereinafter referred to as the “product”) has excellent relief characteristics, and is constructed to always keep a constant pressure even if used with a reverse flow. The product has the following features. (1) A sensitivity of 0.2%F.S. at max is achieved by the nozzle and flapper design.
  • Page 6 The downstream side flow rate is zero. (Note 4)The F.S. means the condition at the maximum setting pressure of the product. (F.S. ≒0.8MPa, IR2120) (Note 5) Repeatability: This is the reproducibility of the downstream pressure at every operation (ON/OFF) on the downstream side.
  • Page 7: Construction And Operation Principle

    2. Construction and operation principle When the input signal from regulator and instrument is risen, ②flapper closes the ③nozzle by the generated force of ①diaphragm(A), allowing the supply air that flows in from the upstream side to pass through the ④fixed orifice. It then acts on ⑤diaphragm(B) as nozzle back pressure, the ⑥main valve is pushed down by the generated force and the supply pressure flows out to the downstream side.The air pressure that flows in acts on ⑦diaphragm(C) and while opposing the force generated by ⑤diaphragm(B),it also acts on ①diaphragm(A ) and balances at the set pressure which is opposing...
  • Page 8: How To Order

    G: Pressure gauge Note2) Note3) Thread type when Rc and G. Thread type when NPT. Set pressure Thread type IR2120 : G43-10-01 G43-P10-N01-X30 2 : 0.01~0.8MPa NIL:Rc N:NPT (Note 1) The flow direction of the suffix is the direction when viewing with the name plate of the precision regulator in front.
  • Page 9: Precautions For Handling

    5. Precautions for handling Fluid Warning (1) Do not use compressed air which contains chemicals, synthetic oils containing organic solvents, salts or corrosive gases, etc., as this can cause damage or malfunction. (2) If the drain removal from air filter and mist separator is missed, drain will be flown out to the outlet side and may result in a malfunction of the pneumatic equipment.
  • Page 10 Maintenance Warning (1) When the valve guide (refer to construction drawing on page 6) is to be removed during maintenance, first reduce the set pressure to “0” and completely shut off the supply pressure. (2) When a pressure gauge is to be mounted, remove the plug after reducing the set pressure to “0”.
  • Page 11 (2) Do not apply torsion or bending moment other than the weight of the product itself. The external piping should be supported separately because it may cause breakage. (3) Non-flexible piping such as steel piping will be subject to excessive moment load and vibration from the piping side, so use a flexible tube for intermediate connection.
  • Page 12 Operation Warning (1) Do not use a precision regulator outside the range of its specifications as this can cause failure.(Refer to the specifications.) (2) When mounting is performed, make connections while confirming port indications. (3) Screw a panel nut with the recommended proper torque 21N・m when mounting onto a panel.
  • Page 13: Warranty

    6. Warranty (1) Period: The warranty period of the product is 1 year in service or 1.5 years after the product is delivered, whichever is first. (2) Scope: For any failure or damage reported within the warranty period which is clearly our responsibility, a replacement product or necessary parts will be provided.
  • Page 14: Troubleshooting

    7. Troubleshooting Trouble Possible cause Countermeasures Reset the pressure. Fluctuation of flow rate at the Return the flow rate at the downstream side downstream side to the initial rate. Clogging of fixed orifice due to moisture, Install a filter and mist separator and condensation or foreign matter use clean air.
  • Page 15: Dimensions

    8. Dimensions MOUNTING HOLE BRACKET (OPTION) M5×0.8 DEPTH7 BLEED BLEED 2×1/4 ≒60.5 PORT SIZE 2×1/8 PRESSURE GAUGE PRESSURE GAUGE PORT (OPTION) -14-...
  • Page 16 Revision history A Thread type deletion B Format change and content review C Sectional view filter deletion of P.5 D Name plate layout change E Content review F Safety Instructions revised Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
