SMC Networks SYJ3000 Series Operation Manual page 15

SYJ Series
Be sure to read this before handling
EX510 Gateway-type Serial Transmission System
Bracket
Caution
For bracket attached styles of SYJ3000 (Single) and
SYJ7000, do not use it without bracket.
Solenoid maunting
Caution
Mount it so that there is no slippage or deformation in
gasket, and tighten with the tightening torque as shown
below.
Model Thread size
SYJ3000 M1.7
SYJ5000 M2.5
SYJ7000 M3
/
Specific Product Precautions 6
Tightening torque
0.12N･m
0.45N･m
0.8N･m
- 14 -
Interface Regulator
No.SYJ3000-OMM0002-B
