- Page 1 PRECISION ALUMINIUM TRACKS TRACKS USER MANUAL USER MANUAL www.panther.tv...
- Page 2 With our best wishes Andreas Fitz CEO | Executive President Panther GmbH A WORD TO THE GRIPS Very often the responsbilty of the grips is underestimated. By working conscientiously and carefully through well considered acting, he is the one who can avoid damages to property or even accidents with serious consequences for people involved, may it be crew members or even uninvolved persons.
- Page 3 TABLE OF CONTENTS TOPIC PAGE Technical Data Safety Instructions Installation Notes...
-
Page 4: Technical Data
62cm sleeper as standard. variable sleeper. The track width of the track can therefore be variably adjusted from 62cm to 100cm. Lenghts: Lenghts: 313232 313232 Precision Aluminium Track 0,5m Precision Aluminium Track 0,5m 313245 313248 Precision Aluminium Track 62, 1m... - Page 5 TECHNICAL DATA We off er our curved tracks in two diff erent versions. The fi rst variant has an inclination of 90° and four tracks can be laid to form a circle with an internal diameter of 3m. The second variant has an inclination of 45° and eight tracks can be laid to form a circle with an internal diameter of 4,8m.
- Page 6 TECHNICAL DATA The Precision Aluminium Track is manufactured of aluminium and off ers because of a specifi cally constructed Double-T-Design a lightweight construction with highest stability. That way only little substruction is necessary and track laying versatile and fast. 9 cm 4 cm The PAT is our lightest track.
-
Page 7: Safety Instructions
Please check the tracks every day with regard to function, damages and missing parts. Damaged or missing components have to be replaced by new ones immediately. Do only use Panther original accessories. Stop working immediately, even if only a part of the tracks is damaged or not mounted the correct way •... -
Page 8: Installation
INSTALLATION Lock: The tracks come in the length you ordered. To connect the tracks together, they must be pushed into each other and the metal fastener must be closed. • Make sure that the ground is levelled over its entire length •... - Page 9 INSTALLATION Vario Sleeper: 62 cm 100 cm 313239 Our Vario Sleeper enables variable track widths from 62cm to 100cm. To change the track width, simply loosen the locking screw and extend the sleeper to the desired width. • To avoid damaging the Vario Sleeper, we recommend that you do not place any weight on it when it is extended PVT,PAT Sleeper 62cm for Telescopic Tubes: 310183...
- Page 10 INSTALLATION Deinstall Sleeper: The sleeper can be removed from the tracks by loosening the screws on the outside. Sub-Base: The sub-base (e.g. PVC plates, boards etc) is the prolongation of the ground and must have the same loading capacity as the ground. Assemble sub-base carefully and without any slope. The tracks must be assembled carefully and without any slope.
- Page 11 INSTALLATION Variable Starter Track: The sleeper can be removed from the tracks by loosening the screws on the outside. Compatibility: All our tracks are compatible with each other. All you need is the right adapter. PAT & PLT PAT & PMT PLT/PMT/PT - PAT Track Adapter (Set) PLT/PMT/PT - PAT Track Adapter (Set) 300671...
-
Page 12: Operation
OPERATION Curves: During use of cranes on curves special attention has to be taken because of high tilting danger. Because of centrifugal forces in curves the highest possible speed of 0.1 m/sec. may not be exceeded. Additionally please pay attention to the respecitve instruction manual of the crane/ dolly. - Page 13 NOTES...
- Page 14 FURTHER ASSISTANCE If you need any further assistance with this instructions (or also other questions) please contact our service department. SERVICE PHONE: SERVICE MAIL: (+49) 8095 71230 - 05 eric.suchetet@panther.tv ADDRESS PHONE / FAX ONLINE Phone: Am Bahnhof 19 (+49) 8095 71230 - 00 contact@panther.tv...
