- Page 1 MINI SHOCK ABSORBER USER MANUAL www.panther.tv...
- Page 2 To ensure that you will love working with your Panther Maxi Shock Absorber and that all re- quirements during shooting can be fulfilled considering utmost safety and reliability, please carefully read this user manual.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TOPIC PAGE Basic Knowledge Spring Adjustment Mounting Dampening Shock Absorber Adjustment Notes... -
Page 4: Basic Knowledge
BASIC KNOWLEDGE Mitchell Plate Shock Absorber Spring Mitchell Plate For use with gyro stabilized heads to reduce high and low frequency vibrations and hard impact shocks during high speed chases on rough and bumpy terrain. max. payload: 80 kg / 176 lbs Your gyro stabilized head / camera or whatever you use has always to be mounted on the upper side of the Maxi Shock Absorber. -
Page 5: Spring Adjustment
SPRING ADJUSTMENT The load capacity can be adjusted by the springs. The springs can be unscrewed counterclockwise. Payload Spring(s) 1x Spring 1 5-30 kg / 11-66 lb (313630) 2x Spring 1 30-40 kg / 66-88 lb (313630) 1x Spring 2 30-50 kg / 66-110 lb (313636) 2x Spring 2... -
Page 6: Mounting
MOUNTING Mitchell Plate (upper side) To change the direction of the Mitchell plate - for example from Underslung to Overslung - you just have to open the blue marked screws and reposition the complete unit in the required position. Then tighten the screws. Overslung Nose Mount Underslung... -
Page 7: Dampening
.80 kg In order for the shock absorber to fully dampen, the shock absorber must be at a right angle to the fixation when the weight is attached. For the damping to work, the Panther lettering must be on top. -
Page 8: Shock Absorber Adjustment
SHOCK ABSORBER ADJUSTMENT The Mini Shock Absorber comes with one dampener. If you want to improve your dampening, you can order a second dampener on top. -
Page 9: Notes
NOTES... - Page 10 If you have any problems with this instructions (or also other problems) please contact our service department. An employee will be very happy to help you until your problem is solved. SERVICE PHONE: SERVICE MAIL: (+49) 8095 71230 - 05 eric.suchetet@panther.tv ADDRESS PHONE / FAX ONLINE Phone: Am Bahnhof 19 (+49) 8095 71230 - 00 contact@panther.tv...
