- Page 1 RANGE RANGE EXTENDER EXTENDER USER MANUAL USER MANUAL www.panther.tv...
- Page 2 To ensure that you will love working with your Panther Range Extender and that all requirements during shooting can be fulfilled considering utmost safety and reliability, please carefully read this user manual.
- Page 3 TABLE OF CONTENTS TOPIC PAGE Technical Data Basic Knowledge Installation Range Extender on new Dolly Notes...
- Page 4 TECHNICAL DATA Length (Range Extender) 39 cm / 15.35“ Width (Range Extender) 20 cm / 7.87“ Height (Range Extender) 72 cm / 28.35“ Weight 15,3 kg / 33.73 lb Max. Height 197 cm / 77.56“ (with Range Extender) Min. Height 5 cm / 1.96“...
- Page 5 BASIC KNOWLEDGE Range Extender 197 cm / 77.56“ The patented Panther Range Extender doubles the lift range and speed without increasing the footprint of the Dolly. In this way, even lower and even higher positions can be reached. A 100% linear camera movement delights the focus puller.
- Page 6 BASIC KNOWLEDGE Height Adjustment Nose Mount The front section of the range extender can be mounted in a higher or lower position. First, the four marked screws must be Remove the nosemount and attach it in the loosened (5mm Allen Key).
- Page 7 Installation New Classic Plus & X-Type If you have a new Classic Plus or an X-Type Dolly, the installation is as follows. The 8mm Allen Key used is part of the Dolly! Unscrew the Euro Adapter. Remove camera bracket. Remove marked screw (8mm Allen Key). Remove the tube.
- Page 8 Protective cap in parking position of the Range Extender. Remove safty protection cap (8mm Allen Attach the Range Extender to the Dolly. Key). Insert the marked pin into the hole, but not Attach Ball locking pin with rope to the dolly‘s completely.
- Page 9 New Classic Plus & X-Type (1) Hold rope at knurled disc (2) Turn fi rmly at bottom, don‘t use a wrench Now push the Range Extender completely in Push the rope to the side at the front opening the specifi ed direction.
- Page 10 Installation New Classic Plus & X-Type After loosend screw, lower nose mount Place the locking screw into the park position. carefully by hand until rope is streched. Range Extender been Further components such as the tube successfully installed. connector (1), the 32cm tube (2), the camera mount (3) previously attached to the dolly and, for example, a 150mm bowl can now be mounted (4).
- Page 11 NOTES...
- Page 12 FURTHER ASSISTANCE If you need any further assistance with this instructions (or also other questions) please contact our service department. SERVICE PHONE: SERVICE MAIL: (+49) 8095 71230 - 05 eric.suchetet@panther.tv ADDRESS PHONE / FAX ONLINE Phone: Am Bahnhof 19 (+49) 8095 71230 - 00 contact@panther.tv...
