Service /Troubleshooting:
There are no servicable parts inside. Please use the following troubleshooting tip
in case of malfunction.
Problem:
Remedy:
No light output
Is the on/off switch set to "on"?
Is the connection to power source ok and the cable undamaged?
Is an appropriate power source used?
Is the battery in good condition and sufficiently charged?
Is the bulb ok and inserted correctly?
Technical specifications:
Construction
Portective class
Light output
(1m Distance)
Mechanical focussing range
Permissible ambient temperature
Max. housing temperature
Socket
Weight
Mounting
Warranty:
Warranty expires if
1. the luminaire was operated imporperly or not in accordance with the specified
technical data or
2. the housing was disassembled by unauthorized personnel.
We reserve the right to make changes based on technical advances.
Panther GmbH, Raiffeisenallee 3, 82041 Oberhaching/Munich, Germany
Tel: +49-89-61390010, Fax: +49-89-6131000
contact@panther.tv, www.panther.tv
According to EN 60 598-2-17
III protective low voltage
With 50 W bulb
1790 Lux spot /830 Lux flood
1 : 2
- 20°C (- 4°F) to 40°C (104°F)
with 20W 70°C (158°F), with 50W 100°C (212°F)
GY 6.35, LCL 30 mm, Max. 11,5 mm
275 g (9.6oz)
Integrated camera mount
I n s t r u c t i o n M a n u a l
Romy 20/50
Barndoor
Dichroic filter
Focusing Knob
Romy Light
BROADCAST
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panther Romy 20/50
Summary of Contents for Panther Romy 20/50
- Page 1 1. the luminaire was operated imporperly or not in accordance with the specified technical data or 2. the housing was disassembled by unauthorized personnel. We reserve the right to make changes based on technical advances. BROADCAST Panther GmbH, Raiffeisenallee 3, 82041 Oberhaching/Munich, Germany Tel: +49-89-61390010, Fax: +49-89-6131000 contact@panther.tv, www.panther.tv...
- Page 2 Properties: 4. First operation The Panther Romy 20/50 is designed for use on board of a TV camera. It is operated During the first operating hours you might notice a slight odour coming from the from low voltage and designed for continuous use up to 50W. The power cable comes luminaire which does not indicate any malfunction.
