INVERTER
INSTRUCTION MANUAL
FR-A8CW
FR-A8SR
FR-A8CU
Option Installation Manual
Thank you for choosing this Mitsubishi Electric inverter option unit.
This manual provides handling information and precautions for use of the this product. Incorrect handling might
cause an unexpected fault. Before using this product, always read this manual carefully to use this product
correctly.
In addition to this manual, refer to the Overview Manual enclosed with the product to ensure proper use. Do not
use this product until you have full knowledge of the product's workings, safety information and instructions.
Please forward this manual to the end user.
