H-11656
24" TILTING DRUM FAN
TOOL NEEDED
Phillips
Screwdriver
WARNING! To reduce the risk of injury,
disconnect from power supply before servicing.
• Do not use extension cords with this product.
• Do not expose fan to water or rain.
• To reduce risk of fire or electrical shock, do not use
the product with a solid state speed control device.
• Never move or rotate fan while running.
• To reduce the risk of electric shock, connect only
to an outlet provided with a ground fault circuit
interrupting device.
• Those who are not qualified electricians should not
disassemble, repair or rebuild the fan.
• Unplug the fan when it is not in use.
• Do not unplug the fan by holding the cable cord.
Unplug by holding the plug and pulling.
• Do not use the fan when there is damage to the
cable cord or plug.
• Do not use this fan outdoors. This fan is designed
for indoor use only.
PAGE 1 OF 12
1-800-295-5510
uline.com
SAFETY
• Do not use the fan close to a fire.
• Do not immerse the fan in water.
• Unplug the fan from the socket and clean it with a
soft cloth.
• If you have removed the guard for cleaning, fit the
guard back onto the fan before starting up the fan.
• Do not insert your hand or other objects into the
guard or the movable parts.
• This fan is not intended for use by people (including
children) with reduced physical, sensory or mental
capabilities or lack of experience and knowledge
unless they have been given supervision or
instruction concerning use of the fan by a person
responsible for their safety. Supervise children to
ensure they do not play with the fan.
• If the supply cord is damaged, contact Uline
Customer Service.
• To reduce risk of fire, electric shock or injury to
persons, do not use replacement parts that have
not been recommended by Uline Customer Service.
Para Español, vea páginas 5-8.
Pour le français, consulter les pages 9-12.
1224 IH-11656

Advertisement

loading
Need help?

Need help?

Do you have a question about the H-11656 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for U-Line H-11656

  • Page 1 Para Español, vea páginas 5-8. Pour le français, consulter les pages 9-12. H-11656 1-800-295-5510 uline.com 24" TILTING DRUM FAN TOOL NEEDED Phillips Screwdriver SAFETY WARNING! To reduce the risk of injury, • Do not use the fan close to a fire.
  • Page 2: Wheel Assembly

    PARTS Wheel Assembly x 2 Foot x 2 Screw x 8 Flat Washer x 4 Locking Washer x 8 ASSEMBLY WHEEL ASSEMBLY Figure 1 Insert wheel assembly into the horizontal tube frame. Ensure the frame holes are aligned with the threaded holes on the wheel assembly.
  • Page 3: Foot Assembly

    ASSEMBLY CONTINUED FOOT ASSEMBLY Figure 3 Insert foot into the vertical tube socket. Ensure the socket holes are aligned with the threaded holes on the foot. (See Figure 3) Foot 2. Secure with a Phillips screwdriver using two screws and two locking washers per foot. (See Figure 4) Screw Locking Washer...
  • Page 4: Maintenance

    MAINTENANCE • This fan contains a resettable thermal protector. CLEANING INSTRUCTIONS If the fan stops working as a result of the motor Unplug the fan before cleaning. Do not immerse overheating, wait for several minutes until the motor any portion of the fan in water. Slightly moisten a cools down, then restart the fan.
  • Page 5: Herramienta Necesaria

    H-11656 800-295-5510 uline.mx VENTILADOR OSCILANTE TIPO TAMBOR – 24" HERRAMIENTA NECESARIA Desarmador de Cruz SEGURIDAD ¡ADVERTENCIA! Para reducir el riesgo de • No utilice el ventilador cerca de un incendio. lesiones, desconéctelo de la fuente de poder • No lo sumerja en agua.
  • Page 6 PARTES 2 Ensambles de Llanta 2 Bases 8 Tornillos 4 Rondanas Planas 8 Rondanas de Bloqueo ENSAMBLE ENSAMBLE DE LA LLANTA Diagrama 1 Inserte el ensamble de la llanta en el armazón de tubo horizontal. Asegúrese de que los orificios del armazón estén alineados con los orificios con rosca en el ensamble de la llanta.
  • Page 7 CONTINUACIÓN DEL ENSAMBLE ENSAMBLE DE LA PATA Diagrama 3 Inserte la pata en el dado del tubo vertical. Asegúrese de que los orificios del dado estén alineados con los orificios con rosca en la pata. (Vea Diagrama 3) Pata 2. Asegure con un desarmador de cruz utilizando dos tornillos y dos rondanas de seguridad por pata.
  • Page 8: Mantenimiento

    MANTENIMIENTO • Este ventilador contiene un protector térmico INSTRUCCIONES DE LIMPIEZA reiniciable. Si el ventilador deja de funcionar como Desenchufe el ventilador antes de limpiarlo. No resultado del sobrecalentamiento del motor, espere sumerja ninguna parte del ventilador en agua. varios minutos hasta que el motor se enfríe, luego Humedezca ligeramente un paño y luego limpie las reinicie el ventilador.
  • Page 9 H-11656 H-11656 1 800 295-5510 uline.ca VENTILATEUR DE TYPE BARIL INCLINABLE – 24 po OUTIL REQUIS Tournevis cruciforme SÉCURITÉ AVERTISSEMENT! Pour minimiser le risque de • N'utilisez pas le ventilateur à proximité d'un feu. ARRÊT blessures, débranchez l'appareil de la prise •...
  • Page 10: Montage Des Roues

    H-11656 PIÈCES Ensemble de roue x 2 Pied x 2 Vis x 8 Rondelle plate x 4 Rondelle de blocage x 8 MONTAGE MONTAGE DES ROUES Figure 1 Insérez les ensembles de roue dans le cadre tubulaire horizontal. Alignez les trous du cadre sur les trous filetés des ensembles de roue.
  • Page 11: Réglage De L'inclinaison

    H-11656 MONTAGE SUITE MONTAGE DES PIEDS Figure 3 Insérez les pieds dans les emboîtures des tubes verticaux. Alignez les trous des emboîtures sur les trous filetés des pieds. (Voir Figure 3) Pied 2. Fixez chaque pied avec un tournevis cruciforme, deux vis et deux rondelles de blocage.
  • Page 12: Instructions De Nettoyage

    H-11656 ENTRETIEN • Ce ventilateur dispose d'un protecteur thermique INSTRUCTIONS DE NETTOYAGE réinitialisable. Si le ventilateur arrête de fonctionner Débranchez le ventilateur avant de le nettoyer. en raison d'une surchauffe de moteur, attendez N'immergez aucune partie du ventilateur dans l'eau.
