DRUM FAN
COMMERCIAL | INDUSTRIAL USE
IMPORTANT SAFETY INSTRUCTIONS
NOTE: Read all safety rules and instructions
carefully before attempting to operate. Retain
for future reference.
DANGER!
Never operate this unit when flammable
materials or vapors are present because
electrical devices produce arcs or sparks that
can cause a fire or explosion.
WARNING!
To reduce the risk of fire, electric shock or injury:
• Do not expose to water or rain – store indoors. Do
not immerse the fan in water. This fan is designed for
indoor use only.
• Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
• Use only as described in this manual. Use only
manufacturer's recommended attachments.
• Do not operate any fan with damaged cord or plug.
Discard fan or return to Uline for examination and/
or repair. If appliance is not working as it should, has
been dropped, damaged, left outdoors or dropped in
water, contact Uline Customer Service for assistance.
• Do not pull or carry by cord, use cord as a handle,
close door on cord or pull cord around sharp edges
or corners. Do not run appliance over cord. Keep
cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp
the plug; not the cord.
• Do not handle plug or appliance with wet hands.
• Do not insert your hand or other objects into
openings. Do not use with any opening blocked;
keep free of dust, lint, hair and anything that may
reduce air flow.
READ AND SAVE THESE INSTRUCTIONS
WARNING!
Unplug unit when not in use.
PAGE 1 OF 12
1-800-295-5510
uline.com
• Keep hair, loose clothing, fingers and all parts of
body away from openings and moving parts.
• Turn off all controls before unplugging. Wait for fan
to stop before moving, storing and/or changing
operating locations.
• WARNING! To avoid injury or property damage: do not
use around explosive liquids or vapors, as electrical
devices produce arcs or sparks, which can cause a
fire or explosion.
• Do not store or use near flammable or combustible
liquids such as gasoline, toxic, carcinogenic,
combustible or hazardous materials such as asbestos,
arsenic, barium, beryllium, lead, pesticides or other
health endangering materials.
• Do not run cord under carpeting. Do not cover cord
with throw rugs, runners, or similar coverings. Arrange
cord away from traffic area and where it will not be
tripped over. Do not route cord under furniture or
appliances.
• Operation of this unit can result in foreign objects
being blown into eyes, which can result in eye
damage. Always wear safety goggles when
operating fan.
• Stay alert! Watch what you are doing and use
common sense.
• Do not use an extension cord with this fan.
• To guard against electric shock while operating, do
not allow fan to come in contact with other grounded
objects such as pipes, radiators, etc.
• Do not use high pressure water, or garden hose to
spray the fan for cleaning.
• Never use fan without safety grills attached.
• WARNING! To reduce the risk of fire or electric shock,
do not use fan with any solid-state speed control
device.
Para Español, vea páginas 5-8.
Pour le français, consulter les pages 9-12.
0220 IH-6984
