SCHELL PURIS E²
HD-K
# 00 281 06 99
# 00 282 06 99
# 00 283 06 99
# 00 284 06 99
# 00 289 06 99 (140 mm)
# 00 292 06 99 (140 mm)
HD-M
# 00 285 06 99
# 00 286 06 99
# 00 287 06 99
# 00 288 06 99
# 00 290 06 99 (140 mm)
# 00 291 06 99 (140 mm)
# 00 293 06 99 (140 mm)
Installation manual
EN
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Schell PURIS E2 HD-K
Summary of Contents for Schell PURIS E2 HD-K
- Page 1 SCHELL PURIS E² Installation manual HD-K # 00 281 06 99 # 00 282 06 99 # 00 283 06 99 # 00 284 06 99 # 00 289 06 99 (140 mm) # 00 292 06 99 (140 mm)
- Page 2 / Do not swallow / Do not dispose in fire / Do not disassemble / Do not recharge / Battery can ex- plode or leak if shorted. Installation instructiones Please consult the SCHELL „General installation conditions“ available at www.schell.eu - > Service/Down- loads/Installation instructions. Dimensioning and protection of drinking water...
- Page 3 HD-M HD-K EN 1717 EN 1717 Optional 4 x AAA 1,5 V # 00 282 06 99 # 00 283 06 99 # 00 284 06 99 # 00 281 06 99 # 00 286 06 99 # 00 287 06 99 # 00 288 06 99 # 00 285 06 99 # 00 289 06 99...
- Page 4 30° 30° 30° Ø 56 Technical specifications Flow pressure 0,5 – 5,0 bar Flow rate max. 5 l/min, independant of pressure Resting pressure max. 8,0 bar Operating temperature max. 70 °C (HD-M) Thermal disinfection max. 80 °C (HD-M) WARNING: DANGER OF SCALDING!
- Page 5 Settings Factory settings Sensor setting Comfort Stagnation flush Thermal disinfection Continuous run Cleaning stop Settings are made with the SCHELL app. SCHELL App Google Play App Store...
- Page 6 Installation...
- Page 7 Installation # 00 283 06 99 # 00 287 06 99 # 00 291 06 99 # 00 281 06 99 # 00 284 06 99 # 00 285 06 99 # 00 288 06 99 # 00 292 06 99 # 00 293 06 99 #00 500 00 99 #00 505 00 99...
- Page 8 Installation ° C ° C ° C...
- Page 9 ° Setting the hot water limit ° C ° C ° C ° C ° C - °C +°C...
- Page 10 Reset the hot water limit max.
- Page 11 Reinigungsstopp Activate the cleaning stop via short range reflex...
- Page 12 Maintenance...
- Page 13 Maintenance 9-10 # 00 282 06 99 # 00 286 06 99 # 00 289 06 99 # 00 290 06 99 78 233 00 99...
- Page 14 For cleaning, use only soft cleaning cloths and standard, commercially-available cleaners and disinfectants withoutabrasive additives that are approved for the cleaning of chrome-plated plastic and brass. CAUTION - Risk of damage to the product! Do not clean with steam cleaners! For general care instructions, please see www.schell.eu.
- Page 15 Replacement parts 02 161 00 99 21 713 00 99 21 714 00 99 (134 mm) 00 94400 99 4 x AAA 1,5 V 00 942 00 99 HD-K, 26 006 00 99 HD-M, 00 946 00 99 00 912 00 99 01 315 00 99 HD-M, 00 947 00 99 PWH, 10 270 06 99...
- Page 16 SCHELL GmbH & Co. KG Raiffeisenstraße 31 57462 Olpe Germany Tel.: +49 2761 892-0 Fax: +49 2761 892-199 info@schell.eu www.schell.eu...
