Summary of Contents for Clarke PSW3
- Page 1 PLASTIC STAPLER/WELDER KIT MODEL NO: PSW3 PART NO: 3400773 USER INSTRUCTIONS GC01/25 ORIGINAL INSTRUCTIONS...
- Page 2 CLARKE dealer. The PSW3 Stapler is ideal for plastic crack repairs and reinforcement with different staples used in various situations. Staples are supplied in different sizes (see page 9) and after implanting, the exposed staple parts can be easily broken off after the plastic areas are melted.
-
Page 3: Specification
SPECIFICATIONS Model Specification Dimensions (L x W x H) 200 x 50 x 30 mm - product 200 x 175 x 50mm - storage case Weight 163 g (device only) Charging voltage 5VDC - 2A Ingress protection IP20 Charging cable length 1.0 m Charging cable type USB to USB-C lead... -
Page 4: General Safety Warnings
GENERAL SAFETY WARNINGS WARNING: READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. FAILURE TO FOLLOW THE WARNINGS AND INSTRUCTIONS MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR INJURY. WORK AREA SAFETY 1. Keep the work area clean and well lit. Cluttered or dark areas invite accidents. 2. - Page 5 4. The staples used with this device are made of special materials, not ordinary steel wire. When the staples are used up, please contact your CLARKE dealer, otherwise any malfunction caused by the use of staples of other materials will not be covered by the warranty.
-
Page 6: Safety Symbols
SAFETY SYMBOLS The following safety symbols may be found on this product packaging. Read instruction manual WEEE Symbol (lithium ion before use batteries) Do not immerse battery Do not Incinerate in water. Harmful to batteries aquatic life. Indoor use only Hot surfaces Wear protective gloves ENVIRONMENTAL RECYCLING POLICY... - Page 7 CHARGING USING THE USB CABLE Charge the battery before using it for the first time. 1. Insert the charger lead into the USB type C charging jack socket and the other end into a suitable USB socket. • The LED will flash RED when the unit is charging.
-
Page 8: Operation
OPERATION 1. According to the shape of the damage to be repaired, select the corresponding staple from those supplied (or from the available selection on page 9) and insert into the tips of the device. 2. If the plastic to be repaired has a long crack which is likely to extend over time, drill a small hole at the end of the crack to prevent this... - Page 9 0.8 mm flat staples for repairing flat surfaces. Part No;-1800212 0.8 mm wave staples for repairing flat plastic areas that need extra reinforcement;- Part No;-1800214 Consumable items listed are available from your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 10: Care And Maintenance
5. Check the charging cable to ensure it is sound and free from cracks etc. NOTE: If the battery requires replacement or if any repairs are required take the unit to your CLARKE dealer. COMPONENT PARTS Left plastic shell... -
Page 11: Declarations Of Conformity
DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
